- Page 1 OWNER’S INSTRUCTIONS MANUEL D’UTILISATION AZ09F7KE AZ09A7KE AZ09F8KE AZ09A8KE Window-type Room Air Conditioner ( Cool and Heat ) Climatiseur de type Fenêtre ( Refroidissement et Chauffage ) E F A DB98-05458A(1)
-
Page 2: Safety Precautions
Safety Precautions The following safety precautions must be taken when installing and using your air conditioner. The air conditioner must be plugged into its own specific power source, which must be installed in compliance with national wiring, earthing and safety regulations. Depending on national regulations and your specific installation, you may need to install: A circuit breaker For further information on electrical requirements, contact a professional electrician. -
Page 3: Table Of Contents
Contents REPARING ONDITIONER Safety Precautions ..................Air Conditioning Unit - Main Parts, Buttons and Display ....... Remote Control Buttons ................. Getting Started ....................Inserting the Remote Control Batteries ............PERATING ONDITIONER Cooling Your Room ..................Heating Your Room ..................Airing Your Room ................... 10 Adjusting the Air Flow Direction Horizontally .......... -
Page 4: Air Conditioning Unit - Main Parts, Buttons And Display
Air Conditioning Unit - Main Parts, Buttons and Display The design and shape are subject to change according to the model. Inner air flow blades (right/left orientation) Air outlet Air inlet (inside) Outer air flow blades (up/down orientation) Air filter (The air filter is Air inlet (Outside) located inside) -
Page 5: Remote Control Buttons
Remote Control - Buttons Timer setting buttons Operating mode selection buttons (FAN, HEAT, COOL) Temperature adjustment buttons ON/OFF Button Fan speed adjustment buttons Air flow blade swing button... -
Page 6: Getting Started
Getting Started You have just purchased a window-type room air conditioner and it has been installed by your installation specialist. Your Owner’s Instructions contain valuable information on using your air conditioner. Please take the time to read them as they will help you take full advantage of the unit’s functions. The booklet is organized as follows. -
Page 7: Inserting The Remote Control Batteries
Inserting the Remote Control Batteries You must insert or replace the remote control batteries when: You purchase the air conditioner The remote control does not work correctly Use two LR03 (R03) 1.5 V batteries. Do not use old batteries or different kinds of batteries together. Batteries may be completely discharged after 12 months, even if they have not actually been used. -
Page 8: Cooling Your Room
Cooling Your Room You must select the Cool mode if you wish to lower the temperature in your room. You can also set the fan speed. Remote Control Control Panel If necessary, press the (On/Off) button. Result: The operating mode indicator (COOL, HEAT or FAN) on the unit comes on. -
Page 9: Heating Your Room
Heating Your Room You must select the Heat mode if you wish to heat your room to a specific temperature. You can also set the fan speed. Remote Control Control Panel If necessary, press the (On/Off) button. Result: The operating mode indicator (COOL, HEAT or FAN) on the unit comes on. -
Page 10: Airing Your Room
Airing Your Room If the atmosphere in your room is stale, you can air it using the Fan feature and if necessary, evacuate the stale air outside. If you wish to evacuate stale air outside, pull the ventilation lever on the front of the unit and the open position ( Result: The air inside the room circulates and stale air is evacuated... -
Page 11: Adjusting The Air Flow Direction Horizontally
Adjusting the Air Flow Direction Horizontally Depending on the position of the unit in your room, you can adjust the orientation of the inner air flow blades on the right-hand side of the unit, thus increasing the efficiency of the air conditioner. Remote Control Control Panel Press the... -
Page 12: Switching The Unit Off Automatically (Off Timer)
Switching the Unit Off Automatically (Off Timer) You can set the timer to switch the air conditioner off automatically at a given time. Example: You wish to switch the unit off two hours after you have gone to bed. Remote Control Control Panel If necessary, press the (On/Off) button. -
Page 13: Operating Recommendation
Operating Recommendation Here are a few recommendations that you should follow when using your air conditioner. Topic Recommendation Heating performances The heat pump inside the air conditioner absorbs heat from outside air and brings it indoors. If the temperature of the outside air drops, the air conditioner will heat less. -
Page 14: Temperature And Humidity Ranges
Temperature and Humidity Ranges The following table indicates the temperature and humidity ranges within which the air conditioner can be used. Mode Indoor Temperature Outdoor Temperature Indoor Humidity Cooling 21°C to 32°C approx. 21°C to 43°C approx. 80% or less Heating 28°C or less 0°C to 21°C approx. -
Page 15: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner F7/F8 models) Be sure to clean the air filter periodically to maintain the air conditioner in the best condition for a long period of time. When cleaning the air conditioner, turn it off and pull out the power plug. -
Page 16: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner A7/A8 models) Be sure to clean the air filter periodically to maintain the air conditioner in the best condition for a long period of time. When cleaning the air conditioner, turn it off and pull out the power plug. -
Page 17: Solving Common Problems
Solving Common Problems Before contacting the after-sales service, perform the following simple checks. They may save you the time and expense of an unnecessary service call. Problem Explanation/Solution The air conditioner does not Check that the circuit breaker used for the air conditioner has not operate at all been triggered. -
Page 18: Method Of Installation
Method of Installation Before installation, be sure to check the installation area or the air conditioner, and drain hose. Checkpoints prior to installation Check the cabinet and front grille of the unit for any harmful defects such as scratches. Be sure to check the power supply. - Refer to the specifications on the label attached to the unit. - Page 19 Installation of the Drain Tube Rear Fix the drain tube as shown in the figure. Rubber cap Gasket Drain Tube Screws(2EA) Installation of the Drain Pan The procedure for installing the drain pan should be determined by the condition of the installing area. In the case of an area where the drain pan can not be directly installed on the rear side of the unit after installing the air conditioner.
- Page 20 THIS AIR CONDITIONER IS MANUFACTURED BY: CE CLIMATISEUR EST FABRIQUE PAR: ELECTRONICS Printed in Korea...
