- Page 1 OWNER’S INSTRUCTIONS AZ09F1KE WINDOW-TYPE ROOM AIR CONDITIONER (Cool and Heat) DB68-02037A(1)
-
Page 2: Safety Precautions
The following safety precautions must be taken when installing and using your air conditioner. 1 The air conditioner must be plugged into its own specific power source, which must be installed in compliance with national wiring, earthing and safety regulations. -
Page 3: Table Of Contents
PERATING ONDITIONER Cooling Your Room ... Heating Your Room ... Airing Your Room ... Switching the Air Conditioner Off ... Adjusting the Air Flow Direction Horizontally ... Adjusting the Air Flow Direction Vertically ... ECOMMENDATIONS Operating Recommendations ... 10 Temperature and Humidity Ranges ... 10 Cleaning Your Air Conditioner ... -
Page 4: Air Conditioning Unit - Main Parts And Control Panel
Air Conditioning Unit - Main Parts and Control Panel The design and shape are subject to change according to the model. Inner air flow blades (right/left orientation) Outer air flow blades (up/down orientation) Air inlet (Inside) Air filter (The air filter is located in inside ) Operating mode selection dial Power plug... -
Page 5: Getting Started
Getting Started You have just purchased a window-type room air conditioner and it has been installed by your installation specialist. Your Owner’s Instructions contain much valuable information on using your air conditioner. Please take the time to read them as they will help you take full advantage of the unit’s features. -
Page 6: Cooling Your Room
Possible temperatures: Between 18°C and 25°C inclusive. Result: The air conditioner starts cooling if the room temperature is higher than the selected temperature. To control the direction of the air flow, refer to page 9. -
Page 7: Heating Your Room
Possible temperatures: Between 25°C and 29°C inclusive. Result: The air conditioner starts heating if the room temperature is lower than the selected temperature. To control the direction of the air flow, refer to page 9. -
Page 8: Airing Your Room
The air conditioner starts up in Fan mode. To control the direction of the air flow, refer to page 9. You can switch the air conditioner off whenever you want. To switch the unit off, simply set the operating mode selection dial to the OFF position. -
Page 9: Adjusting The Air Flow Direction Horizontally
Depending on the position of the unit in your room, you can adjust the orientation of the inner air flow blades on the right-hand side of the unit, thus increasing the efficiency of the air conditioner. Set the air flow blade swing switch to the Result: The inner blades swing automatically left and right. -
Page 10: Operating Recommendations
The heat pump inside the air conditioner absorbs heat from performances outside air and brings it indoors. If the temperature of the outside air drops, the air conditioner will heat less. If you find that the room is not warm enough, use an additional heating appliance. Warm air The air conditioner circulates warm air to heat your room;... -
Page 11: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner Be sure to clean the air filter periodically to maintain the air conditioner in the best condition for a long period of time. When cleaning the air conditioner, turn it off and pull out IMPORTANT the power plug. -
Page 12: Solving Common Problems
Odours are permeated in the room during air conditioning EXPLANATION / SOLUTION Check that the circuit breaker used for the air conditioner has not been triggered. Check that the power cable is plugged into a wall socket and the socket is switched on, if necessary. -
Page 13: Technical Specifications
Technical Specifications Design and specifications are subject to change without notice. Model Power Supply AZ09F1KE 220-240V~, 50Hz... -
Page 14: Method Of Installation
If it is weak, reinforcement work should be performed separately. It is advisable to install the air conditioner in the north or west side to prevent the effect of direct sunlight. When installing it in the south or east side due to unavoidable circumstances, it is advisable to install the sunshade to prevent the direct sunlight. - Page 15 In the case of an area where the drain pan can not be directly installed on the rear side of the unit after installing the air conditioner. Example: High storage Open the front grille ; refer to page 11.
- Page 16 THIS AIR CONDITIONER IS MANUFACTURED BY: ELECTRONICS Printed in Korea...
