Edelbrock Russell 651105 Modification Instructions

Please study these instructions carefully before installing your new Fuel Hose Kit. If you have any questions, please call
our Technical Hotline at: 1-800-416-8628, 7:00 am to 5:00 pm, Monday - Friday, Pacific Standard Time or e-mail us
at Edelbrock@Edelbrock.com.
Proper installation is the responsibility of the installer. Improper installation will void warranty and may
NOTE: Due to a difference in engine fuel inlet location, it is necessary to shorten the Russell Fuel Hose 1" for proper
fitment on 2005-2006 (6.0L LS2) models. Please follow the steps below to accomplish this:
1. Hold red socket feature of either hose end in a
vise (with soft jaws or a rag) and unscrew blue
nipple assembly from socket (counter-clockwise)
using a proper-sized chrome SAE wrench.
2. Remove socket from vise and then remove socket
from hose by pulling and twisting clockwise.
© 2006 Edelbrock Corporation
Brochure No. 63-651105

IMPORTANT NOTE:

result in poor performance and engine or vehicle damage.
MODICATION PROCEDURE
MODIFICATION INSTRUCTIONS
Required for 2005-2006 Pontiac GTO (6.0L LS2)
3. Mark hose 1" from end and wrap masking or
strapping tape tightly around hose at cut point to
minimize fraying. Hold hose in vise to cut. Hose
can be cut with a pneumatic cutoff wheel or
hacksaw. Cut as straight and square as possible.
Remove tape after cutting hose .
4. Hold socket in vise and push hose into socket
while turning counter-clockwise.
socket is seated against end of hose.
Russell Fuel Hose Kit
Catalog #651105
Make sure
Catalog #651105
Rev. 6/06 - BC/mc
