- Page 1 B&K Components, Ltd. AV 30.2 / 60.2 / 100.2 Two Channel Digital Amplifier User Manual 14224 101607...
- Page 2 USER MANUAL - AV 30.2 / 60.2 / 100.2 © 2007 B&K Components, Ltd. All rights reserved. The information in this manual is copyright protected. No part of this manual may be copied or reproduced in any form without prior written consent from B&K Components, Ltd. B&K Components, Ltd.
-
Page 3: Features And Benefits
Features and Benefits The AV 30.2, 60.2 and 100.2 two channel amplifiers utilize high quality electronic circuitry to achieve an environment wherein a detailed, transparent, and highly musical sound can be realized. With limited spatial requirements and minimal heat, the AV amplifiers produce great audio with minimal constraints. - Page 4 AV 30.2 / 60.2 / 100.2 Front and Back Panel...
- Page 5 Front and Back Panel Explanation 1. Model—Label of the model of amplifier. Lists the watts per channel of the amplifier. 2. AC Input Receptacle - For attaching the supplied AC power cord to the amplifier. 3. Power Switch - Power switch for hard powering the amplifier. 4.
-
Page 6: Level Control
Input Connections through RCA The AV Brick Amplifiers have inputs that are designed to accept line level audio from preamplifier or receiver RCA output connections. There are two RCA inputs from the preamplifier’s line level outputs, one left (white) and one right (red) which correspond to the left and right outputs on the preamplifier. -
Page 7: Output Connections
Output Connections The AV brick amplifiers connect to speakers using a 4-position Phoenix con- nector. Speaker connections are run from the amplifier to the speakers. Unplug the connector from the rear of the receiver, strip the speaker wire approxi- mately 1/4” and insert the bare end into the gate on the connector. Use a small, flat blade screwdriver to tighten the connection to each conductor. -
Page 8: Control Triggers
Control Triggers A control (trigger) system is provided on the AV brick amplifiers to allow re- mote switching of the amplifier’s standby on/off feature. The control input is designed to operate with a source (trigger) of at least 4VDC (less than 1mA). The signal sent from the control output is +5VDC (up to 50 mA) to trigger other devices. -
Page 9: Mono Usage
Power and Amp Status LED The “Power” LED on the back of the AV amplifier shows whether or not the unit has power. If the LED is not lit, please check AC power connections, the Main AC fuse and the Power Switch. The “Amp”... - Page 10 Input and Output Connections through RJ-45 The AV Brick Amplifiers have RJ-45 inputs that are designed to connect mul- tiple AV amplifiers. A straight through CAT-5 cable is needed to send signal and a optional control output from one AV amplifier to another. When using the RJ-45 input from one to another, signal is always sent.
-
Page 11: Dip Switches
DIP Switches Each amplifier has a set of DIP Switches used for configuration purposes. The function of each is described below: RJ-45 I/O - When using the RJ-45 Inputs and Outputs, the DIP switch would be enabled as shown to send a trigger signal. Also, when using the control trigger through RJ-45, the CTRL I/O DIP switch would have to be enabled as shown. -
Page 12: Specifications
Specifications Unit AV 30.2 AV 60.2 AV 100.2 Power Rating: 8 ohms 30 Watts 60 Watts 100 Watts Power Rating: 4 ohms 60 Watts 120 Watts 200 Watts Number of Channels Current (Peak to Peak) 10 Amps 15 Amps 20 Amps Dynamic Headroom .5dB .5dB...
