Table of contents Safety Precautions Purpose and function Design and construction Features Rear panel view Rear panel description Level controls Inputs Outputs Control Muting System installation Making the connection Troubleshooting Care and cleaning Specifications Warranty Accessories included: Manual and Power cord Page 1 page 2 page 3...
Turn amplifier ‘off’ when plugging in or unplugging input and speaker cables!!! The AV6125 is equipped with raised feet so that continuous ventilation can be maintained. They help to maintain acoustic feedback into the amplifier at a minimum.
The AV6125's purpose and function The AV6125 is a compact, very efficient, six channel power amplifier. It is designed to be used in all types of audio or audio/video systems. The AV6125 utilizes high quality electronic circuitry to achieve an environment wherein a detailed, transparent, and highly musical sound can be realized.
1. AC fuse holder 2. AC Input receptacle 3. Speaker outputs 1. AC fuse holder - 2. AC Input receptacle - For attaching the supplied AC power cord to the 3. Speaker outputs - 4. Amplifier control muting input/output - Rear Panel View 4.
5. Level controls - 6. Inputs - When using the level controls, first start with them turned all the way up (clockwise). Then adjust them according to your system requirements to match the sound level coming from each speaker. This is a rough adjustment for matching different driver impedances.
Here is a typical preamplifier to amplifier setup: Outputs Five way binding posts are provided. One pair for each channel. They are designed to accept a banana-type plug or spade lug connector (shown below) and are color coded for easy identification. The red (+) post should always be connected to the speakers (+) jack.
There will most likely be a number of cables involved in the installation of your home entertainment system. Pre-planning is essential in order to maximize system efficiency. We recommend the following as a means of helping you reach that goal: Make a diagram of your proposed system by laying out the relative location of each component in the system.
The preamplifier’s control output, such as is provided with B&K series preamplifiers, can be utilized to provide a control signal to the AV6125. If more than one amplifier is being controlled, the control signal can be extended to include each successive unit by simply running a 3.5mm mini-jack cable from the CTRL OUT connector of the first amplifier to...
Page 11
If a source other than a B&K series preamplifier is used to control multiple amplifiers, only the control output voltage from the source is critical. It must be within the range, as indicated on the rear panel, 5-24 volts DC is required. The amplifier will provide each successive amplifier with a control voltage of 12 volts DC for reliable operation.
PROBLEM No sound (‘on’ LED not illuminated) No sound on some or all selected channels (‘on’ LED illuminated) Sound lacks direction, bass weak Loud hum or buzz on one or more channels Channel sounds distorted and low in output ** Note : If unit continues to blow power inlet fuses, FUSE!! have it serviced...
AV6125 SPECIFICATIONS Power rating: 8 ohms 4 ohms Frequency response Input sensitivity THD (S+N) Input impedance Damping factor Current (peak to peak) Slew rate Dynamic headroom S/N (A-weighted) Voltage gain Line voltage Dimensions (O.A.) Weight Power consumption Replacement fuses 125 watts @ 1 kHz...
B&K Components Ltd., referred to herein as B&K, warrants your B&K equipment against all defects in material and workmanship for a period of five years from the date of purchase. This warranty applies only to the original purchaser and only to equipment in normal residential use and service. Defective equipment must be returned to B&K, prepaid, accompanied by sufficient payment to cover the cost of return shipping and handling, and will be repaired or replaced at the discretion of B&K whose decision as to the method of reparation will be final.
Page 15
B&K Components, Ltd 2100 Old Union Road Buffalo, New York 14227 13002 rev 0004...
