Product Diagram; Lcd Status Display; Setup Routine And Procedures - RCA RCU811 - Learning Remote User Manual

RCU811US_IB_REVB 9/26/03
RCU811 Product Diagram
LEARN keys
(L1, L2, L3)
BACKLIGHT key
ENTER key

LCD Status Display

The LCD (Liquid Crystal Display) status display on your RCU811 provides a visual interface
between the user and the remote. This display makes it easy to program and use your remote
with many components.
The LCD status display remains blank when the remote is not in use. Pressing any key displays
the time and the current component mode. The status display turns off after approximately
15 seconds from the last keypress, except when an Event Timer is set. In this case, the display
remains on until the event has occurred.

Setup Routine and Procedures

The SETUP (S) key is located towards the upper right-hand side of the RCU811 unit. The
SETUP (S) key is used to walk you through the steps in setting up the remote. To enter the Setup
Mode, press and hold the SETUP (S) key for 2-3 seconds until the Setup Mode? Screen is shown.
Successive presses of the SETUP (S) key walk you through all the available setup routines.
