BenQ MX810ST Datasheet

MX810ST
DESIGNED
FOR
EDUCATION
Future Proof
Features
Native XGA (1024 x 768) Resolution
2500 ANSI Lumens, 4600:1 Contrast Ratio
0.6 Ultra Short-Throw Ratio
LAN Control/Display, USB Reader/Display
Wireless Display (Optional), 20W Speaker
Top / Front-Left View
Input and Output Terminals
1 2 3 4
RJ45 x1 (Control/Display)
1
USB Mini B x1
2
USB Type A x1
3
RS-232 x1
4
RGB Out x1
5
BenQ America Corp.
15375 Barranca Parkway. Suite A-205. Irvine, CA 92618
BenQ is a registered trademark of BenQ Corp. DLP
Corporate and trademarks are the property of their respective companies. Specifications subject to change without notice.
Excellent Image Quality
5 6 7 8 9
10
RGB In/Component x2
6
S-Video/Video
7
8 Audio R/L
Audio In/Out/Mic
9
12V Trigger x1
10
is a registered trademark of Texas Instruments. All rights reserved.
®
Affordable
Specifications
Native Resolution XGA (1024 x 768)
Brightness 2500 ANSI Lumens
Contrast Ratio 4600:1 (Full on/Full off)
Keystone Auto Keystone / Manual Vertical +/- 90 Degrees
Aspect Ratio 4:3 Native (5 Aspect Ratio Selectable)
Color Full 1.07 Billion Colors Palette
Lens F = 2.6
Zoom Ratio Fixed
Image Size (Diagonal) 41" - 300"
Throw Ratio 0.6:1 (81"@ 3.2 Feet)
Lamp Life 210W, 3500/5000 Hours (Normal/Economical Mode)
PC Compatibility
VGA (640x480) to UXGA (1600x1200)
HDTV Compatibility 480i, 480p, 576, 576p, 720p, 1080i, 1080p
Video Compatibility NTSC, PAL, SECAM
Horizontal Frequency 31-99 kHz
Vertical Scan Rate 48-120 Hz
Analog RGB/Component: D-Sub 15 Pin x2
LAN Networking: RJ45 x1 (LAN Display)
USB Type A x1 (Reader)
USB Type Mini-B x1(Display)
Input Terminals PC/AV S-Video: Mini Din 4 Pin x1
Composite Video: RCA x1
Microphone-In: Stereo Min-Jack x1
Audio L/R: RCA x2
Stereo Mini-Jack x1
Analog RGB: D-Sub 15 pin x1
Output Terminals PC/AV Variable Audio Out: Stereo Mini-Jack x1
Speaker: 10W x2, 12V Trigger x1
Serial Connector: RS-232 9 Pin (Male)
Control Terminals RJ45 x1 (LAN Control)
USB Connector: Type Mini-B x1 (page up/down)
Dimensions (WxHxD) 11.4" x 5.03" x 9.9"
Weight 7.5 lbs (3.4 kg)
Power Supply 100 to 240 VAC, 50/60 Hz
Power Consumption 296W (Typical), Standby <1W
Noise Level 32/27 dBA (Normal/Economical Mode)
Bulgarian/Croatian/Czech/Danish/Dutch/English/Finnish/
Display Languages French/German/Hungarian/Italian/Japanese/Korean/
Norwegian/Polish/Romanian/Russian/Simplified Chinese/
Spanish/Swedish/Turkish/Thai
Picture Mode Dynamic Mode/Presentation Mode/sRGB Mode/Cinema
Mode/User 1 Mode/ User 2 Mode
0.6 Throw Ratio/3D-Ready/LAN Control & Display/USB
Functions Display & Reader/Built-In 20W Speaker/Microphone-In/
Digital Zoom 2x/Closed Captioning/Quick Cooling/Panel
Key Lock/Window 7 Compatible/Wireless Display (Optional)
Accessories (Standard) Soft Carrying Case/User Manual (CD)/Quick Start Guide/
VGA Cable/Power Cord/ Remote Control with battery
Accessories (Optional) Presentation Plus/Spare Lamp Kit/Wall Mount/Wireless
Dongle/Universal Ceiling Mount
Lamp P/N 5J.J3L05.001
Limited Warranty 3-Years Parts/Labor / 1-Year or 2000 hours of lamp life
Tel: (949) 255-9500 www.BenQ.us
EDUCATION
MX810ST-DM-BQus-5/11
