Oki B4300 Installation Instructions
Oki B4300 Installation Instructions

Oki B4300 Installation Instructions

Internal print server
Hide thumbs Also See for B4300:

Advertisement

1. Unpack the print server and
remove any shipping materials.
2. Turn off the printer, and remove
the power cord and interface
cable.
3. Remove the access panel screw.
4. Lift off the access panel.
5. Install the print server:
a. Align the connector at the
bottom of the print server with
OkiLAN 8100e

Internal Print Server

Installation Instructions
Print Server Part Number: 70042101
the connector on the main
board.
b. Press down until connectors are
fully engaged.
c. Make sure the print server is
securely installed.
6. Tighten the 2 screws at each end
of the metal plate.
7. Snap off the access panel tab.
Oki Data Americas, Inc., Mt. Laurel, NJ 08054
http://www.okidata.com
8. Replace the access panel:
a. Align panel tabs at bottom.
b. Swing panel up and in place.
c. Tighten the screw.
9. To perform a test, press the test
button for 3 seconds. The self
diagnostic test and configuration
settings are printed.
To install the printer software and
view the SoftNIC User's Guide, see
the CD-ROM included with your
printer.
58366101
