Dacor RO230 Planning Manual

Document # PG01-010
Product tolerances: ±1/16" (±1.6 mm) unless otherwise stated
K
J
C
A
Control panel
front
Control panel
side view
(A) Overall (B) Chassis
Width Width
29 7/8" 28 3/8"
(75.9 cm) (72.1 cm)
(F) Utility (G) Utility
Cutout Width Cutout Height
6 1/4" 4 3/4"
(15.9 cm) (12.1 cm)
Specifications subject to change without notice.
RO230, ROV230
30 Inch, Double,
Renaissance
Top of
chassis
B
Utility
cutout
60" (152 cm)
Top of
E
chassis
(C) Overall (D) Chassis
Height Height
49 7/8" 49"
(126.7 cm) (124.5 cm)
(H) Utility (J) Control
Cutout Depth Panel Depth
7 3/4" 1 3/16"
(19.7 cm) (3.0 cm)
Wall Oven
®
• Observe all governing codes and ordinances during planning
and installation. Contact your local building department for
further information.
• This appliance must be installed in accordance with the
accompanying installation instructions.
F
G
H
D
Conduit:
Long
(E) Control
Panel
Overlay
7/8"
(2.2 cm)
(K) Chassis
Depth
23 5/8"
(60.0 cm)
* Two 120 Vac hot (L1 and L2), one neutral, one ground.
Fuse/circuit breaker on both L1 and L2.
The above specifications are for reference only. See the
product data plate for exact specifications.
www.dacor.com
PLANNING

WARNING

1 1/8"
(2.9 cm)
3 1/2" 3 3/16"
(8.9 cm) (8.1 cm)
Epicure Millennia (Order kit #AMOH30))

HANDLE DIMENSIONS

ELECTRICAL SPECIFICATIONS

Dedicated Circuit
Total Connected Load
Requirements
240 Vac 60 Hz.,
4-wire,* 60 Amp.
Revised 10/01/11 Page 1/2
GUIDE
21 1/8"
1 1/8"
(2.9 cm)
11.6 kW (48.6 Amp.)
1.15
Phone: (800) 793-0093
