Dacor Renaissance RO130 Planning Manual

Document # PG01-009
Product tolerances: ±1/16" (±1.6 mm) unless otherwise stated
K
J
C
A
Control panel
front
Control panel
side view
(A) Overall (B) Chassis
Width Width
29 7/8" 28 3/8"
(75.9 cm) (72.1 cm)
(F) Utility (G) Utility
Cutout Width Cutout Height
6 1/4" 4 3/4"
(15.9 cm) (12.1 cm)
3 1/2"
(8.9 cm)
Epicure
Specifications subject to change without notice.
RO130, ROV130
30 Inch, Single,
Renaissance
Top of
chassis
B
Utility
cutout
Conduit:
60" (152 cm)
long
Top of
E
chassis
(C) Overall (D) Chassis
Height Height
28 5/8" 26 5/8"
(70.2 cm) (67.6 cm)
(H) Utility (J) Control
Cutout Depth Panel Depth
7 3/4" 1 3/16"
(19.7 cm) (3.0 cm)
1 1/8"
1 1/8"
(2.9 cm)
(2.9 cm)
3 3/16"
(8.1 cm)
Millennia (Order kit #AMOH30))
Wall Oven
®
• Observe all governing codes and ordinances during
planning and installation. Contact your local building
department for further information.
• This appliance must be installed in accordance with the
F
accompanying installation instructions.
G
H
D
(E) Control
Panel
Overlay
1"
240 Vac 60 Hz., 4-wire,*
(2.5 cm)
* Two 120 Vac hot (L1 and L2), one neutral, one ground.
(K) Chassis
Fuse/circuit breaker on both L1 and L2.
Depth
The above specifications are for reference only. See the
23 5/8"
product data plate for exact specifications.
(60.0 cm)
HANDLE
DIMENSIONS
www.dacor.com
Revised 10/01/11 Page 1/2
PLANNING
WARNING
ELECTRICAL SPECIFICATIONS
Dedicated Circuit
Total Connected Load
Requirements
6.0 kW (25.0 Amp.)
30 Amp.
GUIDE
21 1/8"
1.13
Phone: (800) 793-0093
