Lexmark CX410 Fax Manual

Fax guide

Sending a fax using the printer control panel

1
Load an original document faceup, short edge first into the ADF tray or facedown on the scanner glass.
Notes:
•
Do not load postcards, photos, small items, transparencies, photo paper, or thin media (such as magazine clippings)
into the ADF tray. Place these items on the scanner glass.
•
The ADF indicator light comes on when the paper is loaded properly.
2
If you are loading a document into the ADF tray, then adjust the paper guides.
3
From the home screen, touch Fax.
4
From the printer control panel keypad, enter the fax number or the shortcut number.
Note: To add recipients, touch
address book.
5
Touch Fax It.

Sending a fax using the computer

The printer driver fax option lets you send a print job to the printer, which sends the job as a fax. The fax option works as a normal
fax machine, but is controlled through the printer driver instead of the printer control panel.
1
With a document open, click File > Print.
2
Select the printer, and then navigate to:
Properties > Fax tab > Enable fax
3
Enter the recipient fax number or numbers in the "Fax number(s)" field.
Note: Fax numbers can be entered manually or by using the Phone Book feature
4
If necessary, enter a prefix in the "Dialing prefix" field.
5
Select the appropriate paper size and page orientation.
6
If you want to include a cover page with the fax, then select Include cover page with fax, and then enter the appropriate
information.
7
Click OK.
Notes:
• The Fax option is available for use only with the PostScript driver or the Universal Fax Driver. For information on installing
these drivers, see the Software and Documentation CD.
•
The Fax option must be configured and enabled in the PostScript driver under the Configuration tab before it can be used.
•
If the Always display settings prior to faxing check box is selected, then you are prompted to verify the recipient
information before the fax is sent. If this check box is cleared, then the queued document is sent automatically as a fax
when you click OK on the Fax tab.
, and then enter the recipient's telephone number or shortcut number, or search the
Fax guide
Page 1 of 4
