Lexmark CX310 Service Manual
Hide thumbs
Also See for CX310:
- Service manual (430 pages) ,
- User manual (256 pages) ,
- Compatibility manual (179 pages)
Subscribe to Our Youtube Channel
Related Manuals for Lexmark CX310
Summary of Contents for Lexmark CX310
-
Page 1: Service Manual
CX310, CX410, CX510, XC2132, and XC2130 MFP Machine Type 7527-2xx, -4xx, -63x, 697 Service Manual • Start diagnostics • Maintenance • Safety and notices • Trademarks • Index March 17, 2016 www.lexmark.com P/N 12G3313... -
Page 2: Parts Catalog
7527 Parts catalog • “Legend” on page 392 • “Assembly 1: Covers” on page 393 • “Assembly 2: Scanner” on page 395 • “Assembly 3: Paper path” on page 397 • “Assembly 4: Operator panels” on page 401 • “Assembly 5: Electronics” on page 405 •... -
Page 3: Assembly 1: Covers
7527 Assembly 1: Covers Parts catalog... - Page 4 Output bin tray “Output bin tray and exit bail removal” on page 347 40X7810 Back AIO cable cover 40X7845 Rear cover (CX310) “Rear cover removal” on page 336 40X7846 Rear cover (CX410, “Rear cover removal” on page 336 XC2130) 40X7814 Rear cover (CX510, “Rear cover removal”...
-
Page 5: Assembly 2: Scanner
7527 Assembly 2: Scanner Parts catalog... - Page 6 7527 Assembly 2: Scanner Asm-index Units/mach Units/FRU Description Removal procedure 40X9054 ADF input tray “ADF input tray removal” on page 359 40X5872 Bin full flag “Bin‑full flag removal” on page 352 40X7833 Redrive assembly “Redrive unit removal” on page 355 40X7829 Flatbed scanner “Flatbed scanner assembly removal”...
-
Page 7: Assembly 3: Paper Path
7527 Assembly 3: Paper path Parts catalog... - Page 8 7527 Assembly 3: Paper path Asm-index Units/mach Units/FRU Description Removal procedure 40X7627 Printhead “Printhead removal” on page 355 40X7629 Fuser drive motor assembly “Fuser drive motor assembly removal” on page 281 40X7646 Lower left frame and lower right “Lower left frame removal” on frame with cable cover page 318,...
- Page 9 7527 Asm-index Units/mach Units/FRU Description Removal procedure 41X0580 ITU guide “ITU guide removal” on page 329 41X0001 Drive unit motor “Drive unit motor removal” on page 267 41X0826 Developer drive coupling “Developer drive coupling removal” on page 273 40X7628 Main gear drive assembly with “EP drive assembly removal”...
- Page 10 7527 Assembly 4: Operator panels Parts catalog...
- Page 11 UICC to controller “UICC to controller board cable board cable (CX510, removal” on page 311 XC2132) 40X7836 USB cable (CX410, “Operator panel removal (for CX310 XC2130) and CX410 models only)” on page 40X5480 USB cable (CX510, “Operator panel removal (for CX510 XC2132) models only)”...
- Page 12 7527 Asm-index Units/mach Units/FRU Description Removal procedure 40X7817 Operator panel bezel “Operator panel bezel removal” on (CX310) page 302 40X6517 Speaker “Speaker removal” on page 280 Parts catalog...
-
Page 13: Assembly 5: Electronics
7527 Assembly 5: Electronics Parts catalog... - Page 14 7527 Assembly 5: Electronics Asm-index Units/mach Units/FRU Description Removal procedure 40X7804 Controller board (CX310) “Controller board removal” on page 338 40X7805 Controller board (CX410, XC2130) “Controller board removal” on page 338 40X7806 Controller board (CX510, XC2132) “Controller board removal” on page 338...
- Page 15 7527 Asm-index Units/mach Units/FRU Description Removal procedure 40X1792 Power cord, 2.5 m (straight): Korea 40X3141 Power cord, 2.5 m (straight): Paraguay, Europe, Middle East, Indonesia, Africa (HV) 40X0303 Power cord, 2.5 m (straight): PRC N/A 40X1773 Power cord, 2.5 m (straight): South Africa 40X1772 Power cord, 2.5 m (straight):...
- Page 16 7527 Assembly 6: Cables and sensors Parts catalog...
- Page 17 Toner density sensors, left or right (one in package) 40X7046 Waste toner bottle sensor 40X7636 Toner cartridge contacts (Pogo pin) 40X7835 UICC to controller board cable (CX310, CX410, XC2130) 40X7837 UICC to controller board cable (CX510, XC2132) 40X8670 Printhead‑to‑controller board cable...
- Page 18 7527 Assembly 7: Media drawers and trays Parts catalog...
- Page 19 7527 Assembly 7: Media drawers and trays Asm-index Units/mach Units/FRU Description Removal procedure 40X8089 Optional 650‑sheet duo “650‑sheet duo drawer assembly drawer (complete) removal” on page 375 (includes 100‑sheet MPF) 40X5168 Pick tires “Pick tire removal” on page 377 40X8091 650‑sheet Duo Drawer tray “650‑sheet duo drawer tray assembly...
- Page 20 Japanese font card assembly 40X8570 Arabic font card assembly 40X8571 Hebrew font card assembly 40X8659 Forms and Bar Code Card (CX310) 40X8660 Forms and Bar Code Card (CX410, XC2130) 40X8664 Forms and Bar Code Card (CX510, XC2132) 40X8666 Card for PRESCRIBE (CX310)
