Product Description; Overview; Feature Summary - Intel BLKD945GCLF2D Technical Product Specification

1

Product Description

1.1

Overview

This document covers Intel Desktop Boards D945GCLF2 and D945GCLF2D. For
readability, the document references the board product name as D945GCLF2 in all
instances.
1.1.1

Feature Summary

Table 1 summarizes the major features of the Intel Desktop Board D945GCLF2.
Table 1. Feature Summary
Form Factor
Processor
Memory
Chipset
Audio
Video
Legacy I/O Control
Peripheral
Interfaces
LAN Support
BIOS
Mini-ITX, compatible with microATX (6.75 inches by 6.75 inches
[171.45 millimeters by 171.45 millimeters])
Support for the following:
• Soldered-down Dual-Core Intel
• One 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) socket
• Support for DDR2 533 MHz and DDR2 400 MHz DIMMs (DDR2 800 MHz and
DDR 667 MHz validated to run at 533 MHz only)
• Support for up to 2 GB of system memory
®
Intel 945GC Chipset, consisting of:
®
• Intel 82945GC Graphics Memory Controller Hub (GMCH)
®
• Intel 82801GB I/O Controller Hub (ICH7)
5.1-channel audio subsystem using the Realtek* ALC662 high definition audio
codec
®
Intel GMA950 onboard graphics subsystem
SMSC LPC47M997 based Legacy I/O controller for hardware management, serial,
parallel, and PS/2* ports
• Eight USB 2.0 ports
• Two Serial ATA (SATA) headers
• One serial port
• One parallel port
• One Parallel ATA IDE interface with UDMA 33, ATA-66/100 support
• PS/2 keyboard and mouse ports
• One S-Video output port (not available on the D945GCLF2D desktop board)
10/100/1000 Mbits/sec LAN subsystem using Realtek 8111C GbE LAN adapter
device
®
• Intel BIOS (resident in the SPI Flash device)
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
® Atom ® processor
continued
9
