Intel Desktop Board D945GCLF2 Technical Product Specification

1.11 LAN Subsystem

The LAN subsystem consists of the following:
• Intel 82801GB ICH7
• Realtek 8111C GbE device for 10/100/1000 Mbits/sec Ethernet LAN connectivity
• RJ-45 LAN connector with integrated status LEDs
Additional features of the LAN subsystem include:
• CSMA/CD protocol engine
• LAN connect interface that supports the 82562G
• PCI Conventional bus power management
⎯ Supports ACPI technology
⎯ Supports LAN wake capabilities
1.11.1

LAN Subsystem Software

LAN software and drivers are available from Intel's World Wide Web site.
For information about
Obtaining LAN software and drivers
24
Refer to
Section 1.2, page 14
