Lexmark™ T64x

Clearing Jams

Guide

Avoiding jams

The following hints can help you avoid jams:
• Use only recommended print media.
•
Do not overload the print media sources. Make
sure the stack height does not exceed the
maximum height indicated by the stack line on
the labels in the sources.
• Do not load wrinkled, creased, damp, or curled
print media.
• Flex, fan, and straighten print media before you
load it. If jams do occur with print media, try
feeding one sheet at a time through the
multipurpose feeder.
•
Do not use print media that you have cut or
trimmed yourself.
•
Do not mix print media sizes, weights, or types
in the same print media source.
•
Make sure the recommended print side is
loaded in the source according to your simplex
or duplex needs.
•
Keep print media stored in an acceptable
environment.
•
Do not remove trays during a print job.
• Push all trays in firmly after loading them.
•
Make sure the guides in the trays are properly
positioned for the size of print media you have
loaded. Make sure the guides are not placed
too tightly against the stack of print media.
Clearing jams

Understanding jam messages

Message What to do*
200 and 201
Open the top front cover, remove
Paper jams
the print cartridge, and remove the
jam.
202 Paper Jam
Open the rear door on the printer,
Open Rear
and remove the jam.
Door
23x Paper Jam Remove the duplex tray from the
Check Duplex duplex unit, raise duplex deflector,
and remove the jam. Open rear
duplex door, and remove the jam.
24x Paper Jam Open each tray, and remove any
Check Tray <x> jammed media.
250 Paper Jam
Remove all media from the
Check MP
multipurpose feeder, flex and stack
Feeder
the media, reload the multipurpose
feeder, and adjust the guide.
260 Paper Jam
Lift the envelope weight, remove all
Check Env
envelopes, flex and stack the
Feeder
envelopes, reload the envelope
feeder, and adjust the guide.
27x Paper Jam Open the output bin rear doors and
Check Bin x
then remove the jam.
28x Paper Jam
Open the finisher top cover and
Check Finisher
then remove the jam. Open the
finisher rear door, then remove the
jam.
28x Staple Jam Open the stapler door, remove the
staple holder, remove the staple
sheet, clear the jam, reinsert the
staples and staple holder, and then
close the stapler door.
* After clearing the jam, press
printing.
200 and 201 Paper Jam Remove
Cartridge
1
Push the release latch, and lower the
multipurpose feeder.
2
Push the release latch, and open the top front
cover.
CAUTION:
3
Lift and pull the print cartridge out of the printer.
to resume
Warning:
4
Place the print cartridge aside.
The inside of the printer may be hot.
Do not touch the photoconductor
drum on the underside of the
cartridge. Use the cartridge handle
whenever you are holding the
cartridge.
