Left-side components

NOTE: Refer to the illustration that most closely matches your computer.
Component
(1) Power connector
(2) RJ-11 (modem) jack
(3) Powered USB port*
(4) USB port*
(5) Vent
*For information regarding the status of the USB ports, contact your network administrator.
Component
(1) Power connector
(2) RJ-11 (modem) jack
(3) USB port*
(4) Vent
8 Chapter 1 Notebook tour
Description
Connects an AC adapter.
Connects a modem cable.
Provides power to an external device if used with a
powered USB cable.
Connects an optional USB device.
Enables airflow to cool internal components.
Description
Connects an AC adapter.
Connects a modem cable.
Connects an optional USB device.
Enables airflow to cool internal components.
