Left-side components
NOTE:
Refer to the illustration that most closely matches your computer.
Component
(1)
Power connector
(2)
RJ-11 (modem) jack
(3)
Powered USB port*
(4)
USB port*
(5)
Vent
*To view the status of the USB ports, use the USB Storage Options utility. Refer to the "Securing USB ports" section in this
guide for additional information.
Component
(1)
Power connector
(2)
RJ-11 (modem) jack
(3)
USB port*
(4)
Vent
8
Chapter 1 Notebook tour
Description
Connects an AC adapter.
Connects a modem cable.
Provides power to an external device if used with a
powered USB cable.
Connects an optional USB device.
Enables airflow to cool internal components.
Description
Connects an AC adapter.
Connects a modem cable.
Connects an optional USB device.
Enables airflow to cool internal components.
