Cleaning Machine Save these instructions for future reference Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and ful ll your needs for many years to come. Scandinavian design combines clean lines, everyday functionality, and high quality.
Important safety instructions Grounding instructions Grounding instructions Service and guarantee Transport/Winter storage Warranty Disposal How to contact the ASKO Front panel Appliances Inc. Operating instructions Sort your garments. Turn on the main power switch. Open the Door and load the...
Before using your machine for the first time Transport protection Remove any transport protection devices before installing the machine. See the “Transport Protection Devices” chapter. Packing material Please sort waste materials in accordance with local guidelines. Door • The door cannot be opened until the machine is connected to the electricity supply.
Important safety instructions Save these instructions for future reference WARNING! WARNING - To reduce the risk of fire, electric This appliance must be properly grounded. shock, or injury to persons when using your This manual does not cover every possible appliance, follow basic precautions, including the condition and situation that may occur.
Important safety instructions B) Grounding instructions for a Transport/Winter storage permanently connected appliance: If the machine is to be transported or stored in This appliance must be connected to a grounded unheated premises where the temperature can metal, permanent wiring system, or an fall below freezing, do as follows: equipment-grounding conductor must be run with •...
Operating instructions 5. Rinse cold (low extraction) WARNING - To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT Program for: SAFETY INSTRUCTIONS before operating this • All fabrics applience. Sort your garments. 6. Extraction low Empty pockets.
Operating instructions Close the door and press the Once the program has finished Start/Stop button Once a program has finished, "End" appears on the display. Time remaining The door opens automatically once the program The time remaining is shown in hours and has finished.
Settings You can change the following settings: • Automatic Door Opening • Language • Temperature °C/°F Do as follows to open the settings menu: 1. Turn off the machine using the main power switch. 2. Press and hold Start/Stop and the Door Open button and switch on the machine with the main power switch.
Care and maintenance instructions Cleaning the outside of the machine Clean the outside of the machine and the program panel with a mild cleaner. Do not use any solvents, as these can damage the machine. NOTE! Do not hose down or spray the machine with water.
Care and maintenance instructions Rinse holes under the paddle If you think that objects such as nails or paper clips may have fallen into the drum, check the container under the agitator. Such objects can rust and cause spots on clothing. Nails and other sharp objects can cause holes in fabrics.
Troubleshooting The door will not open The machine will not start 1. Check that the main power switch is on. 1. Is the door properly closed? Push it firmly. 2. Is there power? Check your fuses (circuit 2. Is there power? Check the house fuses. breakers).
Troubleshooting Water intake error Error messages If the display indicates a Water inlet fault, The display indicates whether an error has check: occurred during the program. After taking the Fault with water supply. Check: measures described below, turn off the machine •...
Technical information Technical data Height: 33 1/2'' (850mm) Width: 23 1/2'' (597mm) Depth: 23,0" (585mm) Weight: 161lb (73kg) Cylinder volume: 15,9gal (60l) Spin speed (rpm) 1300 Rated power: See serial number tag and rating plate. Heater output: See serial number tag and rating plate. Water pressure: 14-145 psi Drum and liquid compartment material:...
Transport protection Before the machine is used, the three transport NOTE! screws should be removed as shown below. If the machine is to be moved and transported, the transport screws must be refitted to prevent damage to the machine through shaking. If the transport screws or plastic plugs have been lost, you can order new ones from your retailer.
Water supply connection Read these instructions carefully and completely before you install the machine. The installation Since ASKO Cleaning machines have a built-in should be carried out by a qualified person who heating element, you only need a cold water inlet.
Installation instructions Electrical Connections The machine is delivered ready-fitted with a plug. As supplied: 208-240V, 60Hz, 3000W heating element, 1-Phase 15A fuse required. WARNING! Connection to a permanently wired supply point must be made only by a qualified electrician Grounding instructions This machine must be grounded.
• Pickup and delivery. ASKO cleaning machines are designed to be repaired at place of business. In no event shall ASKO Appliances Inc. be responsible for any incidental or consequential damages.
