EAW BH822e Technical Specifications

DESCRIPTION
The BH822e bent bass horn subwoofer represents the next
step forward in large format subbass reproduction. Widely
known as the SuperSub™, the system in designed for use in
arrays of four or more which produce extremely high output
sub bass response to the very bottom of the audible
spectrum.
The 13-ft bent horn loads 2x 12-in woofers specially
designed to endure the extreme conditions the SuperSub
imposes. An array of four BH822e's will produce a maximum
output of 146.0 dB at 28 Hz and features -3 dB and -10 dB
points of 24 Hz and 21 Hz, respectively.
APPLICATIONS
The BH822e subwoofer system is engineered for use in
arrays of four or more modules and are appropriate in any
application requiring extremely high output levels of sub
bass information.
Relatively small SuperSub arrays will fill the largest domed
stadiums, arenas, houses of worship, theaters and perform-
ing arts centers with high impact sub bass information.
The BH822e is optimized for permanent installation only.
Six year warranty.
Applications include:
Stadiums
Large Nightclubs
Large Houses of Worship
Performing Arts Center
Large Theater
Acoustic Performance Partnership
EASTERN ACOUSTIC WORKS
One Main Street, Whitinsville MA, 01588 USA • Phone 508/234-6158 • Toll Free 800/992-5013 • Fax 508/234-8251 • Web http://www.eaw.com • email info@eaw.com
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email info@eaw.com • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# BH822e/2 pp/4/15/99 • Printed In USA
TECHNICAL SPECIFICATIONS BH822e
Portable version shown
DESCRIPTIVE DATA
Sub Bass Subsystem
Cabinet Type (shape)
Enclosure Materials
Dimensions
Weights
Companion Systems
Eastern Acoustic Works
Configuration Sub Bass
2x 12-in Woofer, Bent Horn
Rectangular
Baltic Birch Plywood
Finish Black Polyurethane
Connectors 4-Terminal Barrier Strip
inches millimeters
Height 32 813
Width 36 914
Depth 51 1295
pounds kilograms
Net Weight 360 163.8
Shipping Weight 400 182.0
LF MQ1312, MQ2412, KF930
MF KF920
HF KF910, KF911, KF913
Mid/High MQ1364, MQ1366, MQ1394,
MQ2364, MQ2394, KF853D
Full Range KF750, KF850, KF860, KF861
Downfill KF755, KF855
BH822e
