EAW SB48 Technical Specifications

DESCRIPTION
A dedicated subwoofer with dual 8-in transducers in a rect-
angular enclosure. Each driver is in its own optimally vented
subenclosure.
APPLICATIONS
The SB48 provides high definiton sub bass response in an
exceptionally compact enclosure. Tuned enclosure venting
extends LF response and minimizes driver strain. Compre-
hensive mounting/suspension points. Six year warranty.
Applications include:
Ballroom Events
MultiMedia
Boardrooms
Restaurants
Small Retail Spaces
DESCRIPTIVE DATA
Part Number 999050
Product Group L
Components & Loading 2x 8-in Vented
System Configuration Dedicated Subwoofer
Recommended High-Pass
Frequency (24 dB/Octave) 28Hz
Cabinet Type (shape) Rectangular
Enclosure Materials Baltic Birch Plywood
Finish Black Catalyzed Polyurethane
Connectors 2x Neutrik NL4 Speakon
2-Terminal Barrier Strip
Suspension Hardware (13) 3/8"-16 threaded mounting/
suspension points (4 each top and
right side, 2 each botton and left
side, 1 back)
Grill Vinyl Coated Perforated Steel
EASTERN ACOUSTIC WORKS
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email info@eaw.com • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# SB48 999050(A)/2p/3/14/97 • Printed In USA
TECHNICAL SPECIFICATIONS SB48
NOMINAL DATA
Frequency Response (Hz)
Axial Sensitivity (dB SPL/1 Watt/1m)
Impedance (Ohms)
Power Handling (Watts)
AES Standard
Calculated Maximum Output (dB SPL, @ 1m)
Dimensions
Weights
Net Weight
Shipping Weight
3 db 38Hz to 200Hz
-10 dB 28Hz
92
8 (2x 4)
400
Peak 124.0
Long Term 118.0
inches millimeters
Height 12.5 318
Width 22.5 572
Depth 19.75 502
pounds kilograms
52 23.7
57 25.9
