EAW VRS12 Specifications

THAT WAS THEN. THIS IS EAW.
FEATURES
• Companion subwoofer for all full range VR Series loudspeakers
• Dual 12 inch woofers in rigid, vented enclosure
• Fits under low stages
• Optional array brackets for attractive flown arrays with VR21
and VR51 full range loudspeakers
DESCRIPTION
The VRS12 is engineered to provide high output, authoritative
bass response wherever maximum LF impact is required. When
upright, the VRS12 is the same height as the VR21 and VR51:
optional array brackets make it easy to build attractive flown
arrays with these VR Series full range loudspeakers. On its side,
the VRS12 is just 15.5 inches (394 mm) high, allowing it to be
installed easily under low platforms or stages.
The cross-ply laminated birch enclosure is available in either black
or white finish. It includes a number of threaded inserts for use
with forged shoulder eyebolts. A foam-backed powder-coated steel
grill protects the driver. The entire loudspeaker is fully tested at
the time of manufacture and is warranted to be free from defects
in materials and workmanship for a period of five years from the
date of purchase.
SPECIFICATIONS
PRODUCT DATA
Model Name VRS12
Part Number Black: 0010166 White: 0011352
File creation date 8/03/2004
SPECIFICATION SHEET TABULAR DATA
Descriptive Data
Ways Type
N/A Subwoofer
CONFIGURATION
Subsystem Transducer Loading
Sub Bass 2x12 in cone — Vented
|
EAW One Main Street, Whitinsville, MA 01588 USA
VRS12
www.eaw.com
PERFORMANCE
Operating Range*
Axial Sensitivity (whole space SPL)
Peak Sensitivity (whole space SPL)
Input Impedance (ohms)
Recommended High-Pass Filter
Mode
Single Amp
Power Handling
Calculated Maximum SPL
* With 100 Hz / 24 dB / octave Butterworth low pass filter. Highest recommended
low pass = 200 Hz
|
tel toll free within US/Canada 888.337.7404
DUAL 12-INCH SUBWOOFER
APPLICATIONS
• Houses of Worship
• Audiovisual Presentation
• Distributed Systems
• Theme Parks
32 Hz to 150 Hz
92 dB 32 Hz to 150 Hz
101 dB 20 Hz to 20 kHz
Nominal
4
High Pass => 25 Hz, 24 dB/octave Butterworth
500 W 45 V @ 4 ohms
Average
119 dB
|
tel outside US 425.485.1152
• Nightclubs
• Retail Environments
• Theaters
Minimum
4.4 @ 150 Hz
Peak
125 dB
|
Part No. 0012704 Rev. B
