2.2 INTERFACE DESCRIPTION

D-SUB 15 PIN CONNECTOR

1
6
11
Pin Number
1 Red video input
2 Green video input
3 Blue video input
4 No Connection
5 Ground
6 Red video ground
7 Green video ground
8 Blue video ground
9 +5V
10 H/V sync ground
11 No connection
12 (SDA)
13 Horizontal sync (Composite sync)
14 Vertical sync
15 (SCL)
ViewSonic Corporation
5
10
15
Pin Function
- 8 –
