3.2 Setup Procedure
3.2.1 Connect P2 and monitor of Fixture with VGA ports of Monitor (TSUM Series) by
VGA Cable.
3.2.2 Connect P1 of Fixture with
3.2.3 Plug Power Adapter to Fixture.
3.2.4 Connect Power Cord to Monitor (TSUM Series).
3.2.5 Connect PC to the additional monitor.
P1： to LTP Cable
3.3 DDC Key In Procedure
Sep1.Select and execute DDC Key In program
ViewSonic Corporation
Printer port
of PC by LPT Cable.
- 36 –
Confidential - Do Not Cop
JP1： Power Adapter
P2： VGA Cable
VX2262wm/wmp
