2. Geometry

1).Set cross-hatch pattern and preset timing as timing table listed.
2).Change to each mode in turn and wait for the monitor finish auto-alignment and save
press before change to next mode.
3).Until all of modes are adjusted, exit OSD menu and press POWER OFF to exit factory
mode.

5.4 Factory Defaults

Item
Contrast
Brightness
Color Temperature
Sharpness
OSD H. Position
OSD V. Position
720x400 / 640x400
Resolution Notice

5.5 Function Test

1 Product: 22" LCD Monitor
2 Test Equipment: Color Video Signal & Pattern (or PC with SXGA resolution)
3 Test Condition: Before function test and alignment, each LCD Monitor should be
warmed up for at least 30 minutes with the following conditions:
(a)In room temperature,
(b) With full-white screen, RGB, and Black
(c) With cycled display modes,
640*480 (H=43.27kHz, V=75Hz)
800*600 (H=53.7kHz, V=75Hz)
1024*768 (H=68.67kHz, V=60Hz)
1280*1024 (H=79.97kHz, V=60Hz)
1440*900 (H=55.9kHz, V=60Hz)
1680 x 1050 (H=5.3kHz, V=60Hz)
4 Test Display Modes & Pattern

Compatible Modes

Item
1 640 x 480 @ 60Hz, 31.5kHz
2 640 x 480 @ 75Hz, 31.5kHz
3 720 x 400 @ 70Hz, 31.5kHz
4 800 x 600 @ 56Hz, 35.1kHz
5 800 x 600 @ 60Hz, 37.9kHz
6 800 x 600 @ 72Hz, 48.1kHz
7 800 x 600 @ 75Hz, 46.9kHz
8 1024 x 768 @ 60Hz, 48.4kHz
9 1024 x 768 @ 70Hz, 56.5kHz
10 1024 x 768 @ 72Hz, 58.1kHz
ViewSonic Corporation
Defaults
70%
100%
6500K
50%
50%
50%
720x400
On
Timing
Confidential - Do Not Cop
Item
OSD Time Out
OSD Background
Volume
Treble
Bass
Input Priority
Dynamic Contrast
Aspect Ratio
Response Time
- 27 –
Defaults
15 Sec
On
70%
N/A
N/A
Auto Search
Off
Full screen
Advanced
Analog
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
