Exploded View Parts List - Compaq CRT Monitor s7500 Service Manual

Color monitor.
Hide thumbs

Advertisement

Table of Contents
Part No.
Ref. No.
CABINET ASSEMBLY, CQ771G COMPAQ C072 TCO99 S7500 (PE1165T)
3091TKC078A
1
3091TKC078B
CABINET ASSEMBLY, CQ771G COMPAQ 072 MPR-II S7500(PE1165), CV7500(PE1165U), MV7500(PE1165U, PE1165)
6318L17006A
CDT(CIRC), M41LFQ803X 55NLUD LG-PHILIPS 70KHZ 29.1MM FST TCO S7500 (PE1165T); Northern Hemisphere
6318E17002A
CDT(CIRC), M41LRS102XX112 (Z) TECO 70KHZ 29.1MM FST MPR-II S7500 (PE1165); Northern Hemisphere
6318E17002B
CDT(CIRC), M41LRS102XX112 (EZ) TECO 70KHZ 29.1MM FST TCO S7500 (PE1165T); Northern Hemisphere
CDT(CIRC), M41LRS102XX112 (NS)(Z) TECO 70KHZ 29.1MM CV7500, MV7500(PE1165U); Northern Hemisphere
6318E17002C
6318E17002D
CDT(CIRC), M41LRS102XX112 (QZ) TECO 70KHZ 29.1MM FST MPR-II S7500 (PE1165); Equatorial
CDT(CIRC), M41LRS102XX112 (NS)(QZ) TECO 70KHZ 29.1MM FST- MV7500(PE1165U); Equatorial
6318E17002E
2
6318E17002F
CDT(CIRC), M41LRS102XX112 (SZ) TECO 70KHZ 29.1MM FST MPR-II MV7500, S7500(PE1165); Southern Hemisphere
6318L17005A
CDT(CIRC), M41LFQ803X55NLAA LG-PHILIPS 70KHZ 29.1MM FST MPR-II S7500(PE1165); Northern Hemisphere
6318L17005B
CDT(CIRC), M41LFQ803X 55QLAA LG-PHILIPS 70KHZ 29.1MM FST MPR-II S7500(PE1165); Equatorial
6318L17005C
CDT(CIRC), M41LFQ803X 55SLAA LG-PHILIPS 70KHZ 29.1MM FST MPR-II S7500, MV7500(PE1165); Southern Hemisphere
CDT(CIRC), M41LFQ503X 55NLLD LG-PHILIPS 70KHZ 29.1MM FST CV7500, MV7500(PE1165U); Northern Hemisphere
6318L17007A
6318L17007B
CDT(CIRC), M41LFQ503X 55QLLD LG-PHILIPS 70KHZ 29.1MM FST MV7500(PE1165U);Equatorial
BACK COVER ASSEMBLY, CQ771G C043 TCO99 COMPAQ S7500 (PE1165T)
3809TKC044A
3
3809TKC044B
BACK COVER ASSEMBLY, CQ771G C043 MPR-II COMPAQ S7500(PE1165), CV7500(PE1165U), MV7500(PE1165U, PE1165)
TILT SWIVEL ASSEMBLY, CQ771G T062 B054 HF350U
3043TKK093C
4
339-002K
SCREW ASSEMBLY, TAPTITE P TYPE D5.0 L25.0 MSWR/FZMY
5
6140TC3004A
COIL,DEGAUSSING, 1090MM 16.5OHM 0.4MM 110T 17" WITH EARTH
6
FBT (FLY BACK TRANSFORMER), 1054A,CB777G LG-PHILIPS 17" T701
6174T11003E
7
6620TKB002B
SOCKET(CIRC),POWER, SA-4S HUA JIE AC UNIVERSAL 3PIN BLACK SC901
8
CABLE,D-SUB, UL 2990-9C(7.5) AT 1870MM COMPAQ BK EQ770G DM
6850TA9004C
9
4950TKS196A
METAL, FRAME BOTTOM CQ77XG
10
BRACKET, CQ77XG SUPPORTER CDT
4810TKK195A
11
6871TST292B
PWB(PCB) ASSEMBLY,SUB, CQ771G(NT) CONTROL TOTAL COMPAQ CA-110
12
6401TZZ022B
SPEAKER ASSEMBLY, CQ771G FOR COMPAQ(259139-001) SPK ASSY(L/R) BLACK MV7500(PE1165U)
13
3313T17258B
MAIN TOTAL ASSEMBLY, CQ771G(NT,LG) COMPAQ CA-110 LG-PHILIPS CDT
A
3313T17258D
MAIN TOTAL ASSEMBLY, CQ771G(NT,TECO) COMPAQ CA-110 TECO CDT
PWB(PCB) ASSEMBLY,MAIN, CQ771G(NT) KXLGMT(LG) COMPAQ CA-110 TOTAL LG-PHILIPS CDT
6871TMT300B
B
6871TMT300D
PWB(PCB) ASSEMBLY,MAIN, CQ771G(NT) KXLBNT(TECO) COMPAQ CA-110 TOTAL TECO CDT

EXPLODED VIEW PARTS LIST

- 23 -
Description
