Adjusting The Top-Of-Form Position - Epson C11C560111 - PLQ 20 B/W Dot-matrix Printer User Manual

When you use paper that is shorter than 110.0 mm, set the paper
eject direction to front. The factory set default is front. Refer to the
Programming Guide for details.
When you print a multipart form that is glued at the top, load the
glued part first.
Be sure your multipart forms do not exceed 0.53 mm (0.021 inch)
in thickness.
Always close the printer cover before printing. The printer does not
print when the printer cover is open.

Adjusting the top-of-form position

The top-of-form position is the vertical position on the page where
the printer starts printing. If the printout appears too high or low
on the page, you can use this function to adjust the top-of-form
position.
Follow these steps to adjust the top-of-form position:
Note:
The factory set default for the top-of-form position is set as shown
below.
PR2: 4.2 mm
ESC/P and IBM PPDS: 8.5 mm
This mode can be used even when the printer cover is open.
If you wish to change the top-of-form position in PR40+, make sure
that you set the TOF position for PR40+ to Off.
Your top-of-form position setting remains in effect until you change
it, even if you turn off the printer.
20
Paper Handling
