Epson Stylus Photo 900 Quick Start

EPSON Stylus ® Photo 900
Start
Start
Here
Here
1
1
Unpack
Unpack
1
Remove everything from the box.
Paper support Ink cartridges
Printer
Roll paper holders CD tray CD check disk
2
Remove all the blue tape and packing materials inside and around the printer.
3
Open the printer cover and
remove the plastic piece
from the ink cartridge holder.
2
2
Attach the
Attach the
Paper Support
Paper Support
Insert the paper support into its slots
on the back of the sheet feeder.
(To install the roll paper holders,
see your Printer Basics book.)
3
3
Connect the Printer
Connect the Printer
Connection cables are not included with your printer. You need only one of the following cables:
• USB cable (PC and Mac ® ) or
• Parallel cable (PC only)
USB Cable Users (PC and Mac)
1
Shut down your computer. In Windows
or Turn Off option.
Leave your computer turned off until section 7.
2
Plug the square
3
Plug the flat end of the cable into your computer's USB port until it stops.
CPD-15860R1
(You can use any open USB port.)
Square end
Printer Software
CD-ROM
Parallel Cable Users (PC only)
1
Shut down your computer. In Windows, click Start and select your Shut Down
or Turn Off option.
Leave your computer turned off until section 7.
Printer Basics
2
Plug the end of the cable with the slotted connector into your printer's parallel port,
then secure it with the wire clips.
3
Plug the other end of the cable into your computer's parallel port and secure it
with the screws.
Remove
® , click Start and select your Shut Down
end of the cable into your printer's USB port until it stops.
Flat end
Slotted end End with screws
4
4
Turn On the Printer
Turn On the Printer
1
Plug the printer's power cord into a grounded electrical outlet.
power button
2
Press and release the power button to turn it on.
CAUTION: Never use an external switch, such as a wall switch
or power strip switch, to turn the printer on or off.
5
5
Install Ink Cartridges
Install Ink Cartridges
1
Open the output tray and the printer cover. Then lift up both ink cartridge clamps.
2
Unwrap the ink cartridges and remove the yellow tape.
3
Lower each cartridge into the holder.
Make sure the tabs rest on the hooks
in the back.
CAUTION: You must install both
cartridges or the printer won't work.
4
Press down on the ink cartridge clamps until they click into place.
5
Close the printer cover.
6
Press the ink button.
The green power light flashes as your
printer charges ink for about 2 minutes.
CAUTION: Don't turn off the printer or
interrupt charging while the power
light is flashing or you'll waste ink.
Turn over
Don't touch the
green part
Ink button
