Epson C107001 - LQ 570+ B/W Dot-matrix Printer Product Support Bulletin
Product support bulletin(s)
Hide thumbs
Also See for C107001 - LQ 570+ B/W Dot-matrix Printer:
- User manual (153 pages) ,
- Product information manual (8 pages) ,
- Assembly manual (8 pages)
Advertisement
Quick Links
EPSON AMeRIc& INC.
Product Support Bulletin
Subject:
Understanding and Using
Date: 12/4/91
Page(s): 1 of 14
This bulletin provides detailed explainations and illustrations for some of the more
commonly used printer commands used in ESC/P2 Listed below are the
commands discussed in this bulletin.
Command
ESC X m n1 n2
ESC ( C m1 m2 n1 n1
ESC(v m1 m2 n1 n2
ESC(V m1 m2 n1 n2
ESCtn
ESC ( t n1 n2 d1 d2 d3
ESC( A nln2d,. . .& Print Data as Characters
Commands and Syntax
ESCP/2
Command Name
Select Pitch and Point Size
Set Page Length in Defined Units
Set Relative Vertical Position
Set Absolute Vertical Position
Select Character Table
Assign Character Table
PSB No: P-0082
Originator: JW
PSB Page
2
5
6
8
9
10
14
