EAW FR250z Technical Specifications

FEATURES
• Entry-level access to truly professional loudspeaker
systems
• Dual 15-in woofers in an tuned vented enclosure
• Doubles as a pole mount base for use with other FRz
Series systems
DESCRIPTION
A dedicated subwoofer system with 2x 15-in transducers in a
compact vented rectangular enclosure. The FR250z's enclo-
sure also doubles as a stable pole mount base for use with
any of the FRz Series full range systems.
Tuned enclosure venting extends LF response and minimizes
driver strain. An appropriately configured external processor
can extend LF response and safeguard against cone excur-
sion damage while integrating the subwoofer with FRz Se-
ries full range systems.
APPLICATIONS
The FR250z provides high output sub bass response in a com-
pact, portable enclosure. Intended primarily for portable
applications, the system includes recessed handles, rubber
footpads and optional rear mounted casters.
For increased stability, the systems pole mount base reaches
to the bottom of the enclosure to leverage the system's en-
tire weight. Furthermore, since it uses the enclosure's widest
dimensions, the FR250z provides a remarkably solid pole
mount base. Six year warranty.
Applications include:
Band PA
Ballroom Events
Dance Clubs
Live Music Clubs
EASTERN ACOUSTIC WORKS
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email info@eaw.com • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# FR250z-888164 (A)/2 pp/4/1/00 • Printed In USA
TECHNICAL SPECIFICATIONS FR250z
DESCRIPTIVE DATA
Sub Bass Subsystem
Cabinet Type (shape)
Enclosure Materials
Suspension Hardware
Dimensions
Weights
Shipping Weight
Companion Systems
Configuration Subwoofer
Powering Passive
2x15-in, Vented
Rectangular
Baltic Birch Plywood
Finish Black Catalyzed Polyurethane
Connectors 2x Neutrik NL4 Speakon
Pole Mount Cup for 1 3/8-in
Diameter Pole (5-ft length
recommended)
Grill Powder Coated Perforated Steel
inches millimeters
Height 19.75 502
Width 33.25 845
Depth 29.75 756
pounds kilograms
Net Weight 125 56.9
130 59.2
Full Range FR129z, FR159z, FR153z
