EAW FR129z Specifications

FEATURES
• Entry-level access to truly professional
loudspeaker systems
• 12-in woofer in optimally vented enclosure,
1-in HF on 90 horn
• Handles, rubber footpads, threaded mounting
points and pole mount cup standard
• Works with FR250z subwoofer/pole mount base to
create an instant PA
DESCRIPTION
A 2-way full range system (passive LF/HF crossover) in a
compact vented trapezoidal enclosure. It incorporates a 12-
in woofer and a 1-in exit/2-in voice coil compression driver
mounted on a 90 x 45 constant directivity horn. Designed
primarily for portable applications, the FR129z offers entry-
level access to high quality, truly professional loudspeaker
systems for musicians and DJ's servicing small to medium
venues.
The system's full range passive powering is accomplished via
EAW's internal passive crossover/filter network. This com-
plex design goes beyond merely dividing the signal by per-
forming critical equalization functions.
APPLICATIONS
The FR129ze provides high output full range response in a
versatile, compact system. Effective for both permanent and
portable applications, it comes with handles, rubber foot-
pads, a pole mount cup and three (3) 3/8"-16 threaded
mounting/suspension points.
The FR129z is optimized for use with the FR250z dual 15-in
subwoofer system which also serves as a pole mount base.
In such a configuration, a standard 5-ft mounting pole posi-
tions the FR129z's HF horn above the heads of audience
members for maximum coverage. Six Year Warranty.
Application include:
Band PA
Ballroom Events
Small HOW's
Dance Clubs
Live Music Clubs
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email info@eaw.com • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# FR129z-888161 (A)/2 pp/4/1/00 • Printed In USA
SPECIFICATIONS FR129z
PERFORMANCE
Frequency Response (1 W @ 1m)
3 dB 80 Hz to 18 kHz
-10 dB 60 Hz
Axial Sensitivity (dB SPL, 1 Watt @ 1m)
Full Range 97
Impedance (Ohms)
Full Range 8
Power Handling, AES Standard (Watts)
Full Range 500
Calculated Maximum Output (dB SPL)
Full Range Peak 130.0
Full Range Long Term 124.0
Nominal Coverage Angle, -6 dB Points (degrees)
Horizontal 90
Vertical 45
Recommended High-Pass Frequency
24 dB/Octave 60
