EAW FR122e Technical Specifications

DESCRIPTION

A 2-way full range system (passive LF/HF crossover) in a
compact vented rectangular enclosure. Includes a 12-in
woofer and a 1-in exit compression driver on a 90 x 45 con-
stant directivity horn.

APPLICATIONS

The FR122e provides high output full range response in a
versatile, compact system. Effective for both permanent and
portable applications, it comes with handles, a pole mount
cup and 3/8"-16 threaded mounting/suspension points. Six
Year Warranty.
Application include:
Band PA
Ballroom Events
Corporate Events
Small HOW's
Dance CLubs
Live Music Clubs

DESCRIPTIVE DATA

Part Number 999005
Product Group I
LF Subsystem & Loading 1x 12-in, Vented
HF Subsystem & Loading 1x 1-in Exit Compression Driver on
Constant Directivity Horn
System Configuration 2-way, Full Range
Powering Configuration(s) Passive LF/HF Crossover
Controls (switches, knobs) Midrange Presence Control
Recommended High-Pass
Frequency (24 dB/Octave) 45Hz
Cabinet Type (shape) Rectangular
Enclosure Materials Baltic Birch Plywood
Finish Black Catalyzed Polyurethane
Connectors 2x Neutrik NL4 Speakon
Suspension Hardware (3) 3/8"-16 Threaded Mounting/
Suspension Points, 2 Top, 1 Rear
Grill Vinyl Coated Perforated Steel
EASTERN ACOUSTIC WORKS
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email info@eaw.com • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# FR122e 999005 (A)/2p/3/14/97 • Printed In USA
TECHNICAL SPECIFICATIONS FR122e

NOMINAL DATA

Frequency Response (Hz)
Axial Sensitivity (dB SPL/1 Watt/1m)
Impedance (Ohms)
Power Handling (Watts)
Calculated Maximum Output (dB SPL, @ 1m)
Nominal Coverage Angle / -6 dB points (degrees)
Recommended Systems
Dimensions
Weights
Shipping Weight
3 db 79Hz to 15kHz
-10 dB 49Hz
98
8
AES Standard 500
Peak 131.0
Long Term 125.0
Horizontal 90
Vertical 45
Sub SB150 / SB250
inches millimeters
Height 23 584
Width 15.13 384
Depth 11.63 295
pounds kilograms
Net Weight 44 20.0
53.9 24.5
