Compaq dc5750 - Microtower PC Utility Manual page 12

Table 3 Computer Setup—Storage (continued)
DPS Self-Test
Boot Order
6 Computer Setup (F10) Utility
NOTE Advanced operating systems like Windows may reenable the channel.
SATA 1 and 3
Allows you to enable or disable DOS and boot accesses to the Secondary channel of the first SATA
controller. This feature only applies when SATA Emulation = IDE.
NOTE Advanced operating systems like Windows may reenable the channel.
SATA 4 (some models)
Allows you to enable or disable DOS and boot accesses to the Primary channel of the second SATA
controller. This feature only applies when SATA Emulation = IDE.
NOTE Advanced operating systems like Windows may reenable the channel.
SATA 5 (some models)
Allows you to enable or disable DOS and boot accesses to the Secondary channel of the second
SATA controller. This feature only applies when SATA Emulation = IDE.
NOTE Advanced operating systems like Windows may reenable the channel.
Allows you to execute self-tests on ATA hard drives capable of performing the Drive Protection
System (DPS) self-tests.
NOTE This selection will only appear when at least one drive capable of performing the
DPS self-tests is attached to the system.
Allows you to:
● Specify the order in which attached devices (such as a USB flash media device, diskette drive,
hard drive, optical drive, or network interface card) are checked for a bootable operating system
image. Each device on the list may be individually excluded from or included for consideration
as a bootable operating system source.
● Specify the order of attached hard drives. The first hard drive in the order will have priority in
the boot sequence and will be recognized as drive C (if any devices are attached).
NOTE MS-DOS drive lettering assignments may not apply after a non-MS-DOS operating
system has started.
Shortcut to Temporarily Override Boot Order
To boot one time from a device other than the default device specified in Boot Order, restart the
computer and press F9 when the monitor light turns green. After POST is completed, a list of bootable
devices is displayed. Use the arrow keys to select the preferred bootable device and press Enter.
The computer then boots from the selected non-default device for this one time.
ENWW
