Characteristics of the pan base
The characteristics of the pan base may affect the uniformity of
the cooking results. Pans made from materials which help
diffuse heat, such as stainless steel sandwich pans, distribute
heat uniformly, saving time and energy.
Absence of pan or unsuitable size
If no pan is placed on the selected hotplate, or if it is made of
unsuitable material or is not the correct size, the power level
displayed on the hotplate indicator will flash. Place a suitable
pan on the hotplate to stop the flashing. If this takes more than
90 seconds, the hotplate will switch off automatically.

Familiarise yourself with the appliance

These instructions for use are applicable to other hobs. On
page 2 an overview of the models is provided, along with
information on measurements.

The control panel

Control surfaces
Pressing a symbol activates its corresponding function.

The hotplates

Hotplate
Single hotplate
$
Grill plate
æ
Resistive plate-warming zone
q
* The residual heat indicator lights up.
Only use pans suitable for induction cooking, see the "Appropriate cookware" section.
,QGLFDWLRQV IRU
SRZHU OHYHO³É
IXQFWLRQDOLW\ ¯
UHVLGXDO KHDW ¤‡
SRZHUERRVW IXQFWLRQ °
&RQWURO SDQHOV IRU
PDLQ VZLWFK
! ' FOHDQLQJ SURWHFWLRQ
DQG FKLOGSURRI ORFN
 WLPH SURJUDP IXQFWLRQ
Activating and deactivating
Use a correctly sized pan.
The hotplate turns on automatically when a pan the same size as its outer
edges is placed on it.
To activate: press the
shows
To deactivate: press the
Empty pans or those with a thin base
Do not heat empty pans, nor use pans with a thin base. The
hob is equipped with an internal safety system. However, an
empty pan may heat up so quickly that the "automatic switch
off" function may not have time to react and the pan may reach
very high temperatures. The base of the pan could melt and
damage the glass on the hob. In this case, do not touch the
pan and switch the hotplate off. If it fails to work after it has
cooled down, please contact the Technical Assistance Service.
Pan detection
Each hotplate has a minimum limit for detecting pans, which
varies depending on the material of the pan being used. You
should therefore use the hotplate that is most suitable for the
diameter of your pan.
&RQWURO
SDQHOV IRU
VHOHFWLQJ
WKH KRWSODWH
&RQWURO
SDQHO IRU
ERRVW*
SRZHUERRVW
IXQFWLRQ
Notes
The settings will not change if several symbols are pressed at
■
the same time. This enables the programming zone to be
cleaned when food is spilt.
Always keep the control surfaces dry. Moisture can affect
■
proper functioning.
symbol for the plate-warming zone and the display
$
Ž
$ symbol again and
,QGLFDWLRQV IRU
SODWHZDUPLQJ ]RQH
SRZHU OHYHO Ü
IXQFWLRQDOLW\ ¯
UHVLGXDO KHDW ¤‡
&RQWURO SDQHOV IRU
VHOHFWLQJ WKH
SRZHU OHYHO
‹ appears in the display.*
