Dynacord VL 212 Specifications

Features:
.
High-Power Multi-Functional 2-Way
Cabinet
.
800W 4 Ohms
.
Rotatable CAD-optimized 90° x 45°
Constant Directivity Horn
.
Switchable to Biamped Mode
.
Neodymium 1.4" ND6 Driver
.
2 x DND 12350 Neodymium Woofers
.
Voice Coil Tracking Protection
Wir weisen ausdrücklich darauf hin, dass bei
gehängten Lautsprecherboxen die einschlägigen
Sicherheitsbestimmungen zu beachten sind. Es
muss unbedingt qualifizierte Fachberatung in
Anspruch genommen werden!
We expressly point out that the relevant safety
regulations must be observed for „flying"
loudspeaker systems. It is imperative that quali-
fied expert advice is sought.
Technische Informationen
Architects and engineers

specifications

VL 212
2 x 12" / 1.4"
2-Way Professional
Speaker System
Specifications
TYPE / NAME
Order No.
Cabinet
Configuration
Nominal impedance
Rated power RMS
Program power
Peak power
SPL 2,83 V / 1m 2W / 4 Ohm
Max. SPL 1m
(calculated with peak power)
Frequency range ( -10dB )
Full range
Frequency range ( -10dB )
measured with H5000-RCM26 preset
Coverage angle 1 kHz -6dB
Passive crossover frequency
1.5kHz 24dB/Oct. Linkwitz-Riley,
Active crossover frequency
Voice coil tracking protection
Component HIGH Electro-Voice ND6-8 Neodymium
Order No.
Component LOW
Order No.
Connectors Full-Range
Wired through
Connectors Biamped
Wired through
Connector model
Dimensions (WxHxD)
Net weight
Shipping weight
Enclosure material
Finish
Grille Powder coated steel, acoustic foam
Handles
Warranty
Optional Accessories
SH-VL212 Dust-Cover
MB-VL212
TC-02 Truss clamp
FB-VL212 Flying Bracket
TC-TV Truss Clamp > TV Spigot
PM-TV Pole Mount > TV Spigot
VL212
D 113 133
Full-Range
Passive 2-Way
Switchable to biamped mode
4 Ohms
800 Watts
1600 Watts
3200 Watts
105 dB
137dB
80Hz - 19kHz
50Hz - 19kHz
90° * 45°
1.5kHz
1,5kHz Linear-Phase FIR
Yes
D361493
2 x DND 12350
D366559
1+, 1-
2+, 2-
Lo 1+, 1- Hi 2+, 2-
1+, 1-, 2+, 2-
Speakon 2x NL4 MPR
385x1035x374mm
34kg
38.5kg
Birch plywood
Black, 2-component paint
2
36 Month
D113147
D113153
D112808
D113152
D112941
D112942
