Dynacord D15-3 Architects And Engineers Specifications

Features:
.
High-Power Light-Weight Fullrange
Cabinet, 24kg only
.
Polypropylene Enclosure
.
90° x 50° Constant-Q HF Horn
.
Neodymium DND 15400 Woofer
.
Voice Coil Tracking Protection
Wir weisen ausdrücklich darauf hin, dass bei
gehängten Lautsprecherboxen die einschlägigen
Sicherheitsbestimmungen zu beachten sind. Es
muss unbedingt qualifizierte Fachberatung in
Anspruch genommen werden!
We expressly point out that the relevant safety
regulations must be observed for "flying"
loudspeaker systems. It is imperative that quali-
fied expert advice is sought.
Technische Informationen
Architects and engineers

specifications

D15-3
15", 500 Watt
3-Way Compact
Speaker System
Specifications
TYPE / NAME
Order No.
Cabinet
Configuration
Nominal impedance
Rated power RMS
Program power
Peak power
SPL 2,83 V / 1m 1W / 8 Ohm
Max. SPL 1m
(calculated with peak power)
Frequency range ( -10dB )
Full range
Frequency range ( -10dB )
measured with DSP 244 preset
Coverage angle 1 kHz -6dB
Coverage angle 10kHz -6dB
Passive crossover frequency
Active crossover frequency
Voice coil tracking protection
Component HIGH
Order No.
Component MID DYNACORD DND 6120 Neodymium
Order No.
Component LOW DYNACORD DND 15400 Neodymium
Order No.
Connectors Full-Range
Wired through
Connector model
Dimensions (WxHxD)
Net weight
Shipping weight
Enclosure material
Handles
Grille Powder coated steel, Acoustic Foam
Warranty
Optional Accessories
SH-D15 Dust-Cover for D15-3
MB500 UMH-U-Bracket
FB-D15 flying Bracket
TMA Tilt angle for UMH
RMA Rotatable Mounting Kit
TC-02 Truss clamp
PCL M10
D 15-3
D113084
Full-Range
Passive 3-Way
8 Ohms
500 Watts
1000 Watts
2000 Watts
100 dB
133 dB
50 Hz - 20kHz
120° Conical
90° * 50°
700Hz, 4kHz
Yes
Electro-Voice DH-3
D353 078
D366 302
D366 303
1+, 1-
2+, 2-
Speakon 2x NL4 MPR
447mm x 686mm x 413mm
(17.575" x 27.128" x 16.260")
24 kg (52.91 Ibs)
26 kg (57.31 Ibs)
Heavy Duty Polypropylene
1
36 Month
D113097
D113099
D113100
D112815
D112807
D112808
D113116
