10800 — 15,000 RPM
10810 — Versatility Kit
Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air tools (ANSI B186.1) and any other applicable safety codes
WARNING
!
and regulations. Please refer to Dynabrade's Warning/Safety Operating Instructions for more complete safety information.
02679 Shield
02696 Bearing
01546 Housing
Left Hand Threads
01548 Gasket
L
4
01461 Lock Nut
95523 O-Ring
01470 Insert
Right Hand Threads
01488 Housing
Please indicate:
Model #, Serial #,
and RPM
when ordering
replacement parts.
01558 Collar
01449 Valve Stem
95730 O-Ring
01024 O-Ring
01469 Regulator
(incl. O-rings)
O
Oil
Loctite/Hernon: L
L
L
= Loctite #609, L
3
Torque: N•m x 8.85 = In. - lbs.
T
T
= 10 N•m, T
2
T
= 45 N•m
5
50767 Pin
01476 Cylinder
01480 Blades (4) (4 pkg.)
02673 Rear Bearing Plate
T
5
95558 Retaining Ring
L
4
01472 Tip Valve
01464 Seal
Shaded parts represent 94520 Muffler Assembly.
See inside for Important Operating, Maintenance and Safety Instructions.
KEY
G
Grease
= Loctite #271,
2
= Hernon #940
4
= 23 N•m, T
= 28 N•m,
3
4
50777 Rotor
40544 Bearing
01560 Exhaust Cover
L
57961 Cam Assembly
O
53161 Front Bearing Plate
*01448 Throttle Lever
12132 Pin
95711 Retaining Ring
96065 O-Ring
95438 O-Ring
01468 Spring
57970 Air Control Ring
T
57976 Boot Assembly
4
G
2
T
2
95884 Hose Clamp Assy.
94521 Muffler Base
94525 Felt Muffler
94524 Sintered Muffler
AUTOMOTIVE
Parts Page Reorder No. APD97•08
Effective April, 1997
DynaFine
Air Powered Detail Sander.
57953 Hook-Face Pad
11016 Bearing
L
96258 Screw (2)
3
95735 O-Ring
94526 Spacer
94522 Muffler Cap
94523 Inlet Adapter
T
L
O
3
4
*Optional 01462 Safety-Lock Lever available.
