T860 Flat Panel Monitor
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9494HB0 - T 860 - 18.1" LCD Monitor and is the answer not in the manual?

Questions and answers

Related Manuals for IBM 9494HB0 - T 860 - 18.1" LCD Monitor

Summary of Contents for IBM 9494HB0 - T 860 - 18.1" LCD Monitor

  • Page 1 T860 Flat Panel Monitor User Guide...
  • Page 2 References in this publication to IBM products, programs, or services do not imply that IBM intends to make these available in all countries in which IBM operates. Any reference to an IBM product, program or service is not intended to state or imply that only IBM’s product, program, or service may be used.

  • Page 3: Table Of Contents

    T860 Flat Panel Monitor User Guide Contents Setting up the monitor ....................2 Product Description....................2 System Hardware Requirements .................2 Handling Instructions ...................2 Desk Top Use.......................3 Arm or Wall Mount Use ..................3 Monitor Installation ....................4 Connecting your Monitor..................4 Switching on your Monitor..................5 Monitor Driver Installation ..................6 Driver installation for Windows 95 or Windows 98..........6 Driver installation for Windows 2000 or Windows Me..........7...

  • Page 4: Setting Up The Monitor

    Setting up the monitor The IBM T860 Flat Panel Monitor comes in models with a stand for desktop use and models without a stand for arm or wall Mounting. Please refer to the appropriate sections on your model. Monitor installation is the same for ether model.

  • Page 5: Desk Top Use

    Desk Top Use - Remove the clip on stand models Before adjusting your monitor for the first time, remove the locking clip on rear of the stand. Carefully hold the screen of the monitor and then sqeeze at arrows shown to remove(figure A). Arm or Wall Mount Use Arm or Wall Mounting (VESA) Connected to a wall or arm monuting device using the VESA standard...

  • Page 6: Monitor Installation

    Monitor Installation Connecting your Monitor 1. Turn off your computer and all attached devices. Next, unplug the power cord(s) to your computer and all attached devices. 2. Connect the signal cable. The ac adapter and the analog signal cable are already connected to your monitor.

  • Page 7: Switching On Your Monitor

    3. Connect the power cord to the power adapter and then plug the power cord into a properly grounded outlet. Next, reconnect the power cord(s) to your computer and all attached devices. Switching on your Monitor 1. Switch on the adapter power source by pushing the power switch on the top rear panel of the monitor.

  • Page 8: Monitor Driver Installation

    8. Click OK. 9. Ensure that the CD drive letter is selected. 10.Choose IBM T860 monitor and Click OK. The files will be copied from the CD to your hard disk drive. 11.Close all open windows and remove the CD.

  • Page 9: Driver Installation For Windows 2000 Or Windows Me

    HAVE DISK 13.Click OK. 14.Ensure that the CD drive letter is selected. 15.Choose IBM T860 monitor and Click OK. The files will be copied from the CD to your hard disk drive. 16.Close all open windows and remove the CD.

  • Page 10: Driver Installation For Windows Xp

    HAVE DISK 13.Click OK. 14.Ensure that the CD drive letter is selected. 15.Choose IBM T860 monitor and Click OK. The files will be copied from the CD to your hard disk drive. 16.Close all open windows and remove the CD.

  • Page 11: Image Setup For Analog Input

    In order to optimize the displayed image a set-up utility is provided on the replace or modify the display drivers. IBM Monitor CD. Operation of this utility is dependent on the operating system on your computer. You may choose to run AUTO SETUP for each The Auto Setup operating system that you use.

  • Page 12: Autosetup For Windows 3.1, Windows 95, Windows 98, Windows 2000, Windows Me, Windows Xp Or Windows Nt

    3. Ensure that the icon bar and tool bar, if displayed are at the bottom of the screen. 4. Insert the CD labelled ‘IBM Monitor CD’ into the CD drive. 5. Check the operating system installed on your computer and follow the The size and diversity of the instructions from the table below.
  • Page 13 10. Press the ESC key on your keyboard to return to Windows. You have completed the monitor setup for Windows. If you use other operating systems, perform the appropriate AUTO SETUP for those systems and also see Adjusting the image settings in DOS on page 12.

  • Page 14: Adjusting The Image Settings In Dos

    2. Wait approximately 15 minutes, until the monitor warms up. If you are using PC-DOS/V, change to U.S. mode by 3. Insert the CD labelled ‘IBM Monitor CD’ into the CD drive. typing ‘CHEV US’ and pressing 4. Display the command prompt screen of the DOS full-screen display.

  • Page 15: Manually Adjusting The Image Settings

    Manually adjusting the image settings Normally, you can complete the setup procedure using Image S , however, If the monitor is in standby etup mode (STANDBY ON), it if your screen image is still distorted after you perform Image S or the setup etup might automatically turn off...

  • Page 16: Ergonomic Considerations

    Ergonomic Considerations Workplace Preparation Height This section gives advice on what you should Position the monitor so that the top of the screen is slightly below your eye consider before you set up level when you sit at your workstation. your monitor.

  • Page 17: Adjusting The Monitor Position

    • Gently wipe the covers and the screen with a soft cloth. • Remove finger marks and grease with a damp cloth and mild detergent. • Never use flammable cleaning materials to clean your IBM monitor or any other electrical apparatus.

  • Page 18: Adjusting Your Lcd Monitor

    Adjusting Your LCD Monitor User controls USER CONTROL FEATURES Icon Monitor controls Switches the monitors on and off. Display main OSD menu and selects highlighted menu item. If the monitor is in DPM mode(Active off/off), this button is shown the INPUT SELECT menu. Moved the cursor to highlight icons or make adjustments.

  • Page 19: On-Screen Display (Osd) Controls

    On-screen display (OSD) controls The settings adjustable with the user controls are viewed through the On - The LCD monitor needs Screen Display (OSD). Press the enter button [ ] to display the main OSD time to become thermally menu. stable the first time you turn it on each day.
  • Page 20 Controls and OSD Icon Description Sub-menu(s) Adjustments If manual is selected, the user will go To adjust the focus of the MANUAL to the manual adjustment screen. display. This item allows • Fine you to remove any • Coarse horizontal noise and clear IMAGE SET-UP or sharpen the image of CONT...
  • Page 21 Controls and Description Sub-menu(S) OSD Icon Adjustments Reset should return all available functions • YES (apart from language which should not change unless adjusted via the • NO LANGUAGE menu) fo their factory RESET presets. Moves the screen left and right . Is not availible with a digital input H-POSITION Moves the screen up and down.

  • Page 22: Further Information

    Further Information Display modes The display mode the monitor uses is controlled by the computer. Therefore, If your computer has previously been used with you should refer to your computer documentation for details on how to a CRT monitor and is currently change display modes.

  • Page 23: Power Management

    NERGY STAR 2000 ® guidelines for energy efficiency. IBM recommends that you switch off your monitor at the end of each working day, or whenever you expect to leave it unused for long periods during the day. Restoring...

  • Page 24: Arm Or Wall Mounting

    Arm or Wall Mounting Removing the stand and cables Alternative stands for your IBM Flat Panel Monitor may be available from specialist suppliers. Be sure to read the Monitor Safety and This product is equipped with mounting facilities that conform to the VESA Warranty Information manual Flat Panel Monitor Physical Mounting Interface Standard (FPMPMI).

  • Page 25: Troubleshooting

    Troubleshooting If you have a problem setting up or using your monitor, you may be able to solve it yourself. Before calling your retailer or IBM, try the suggested actions that are appropriate to your problem. Possible Problem Suggested Action...
  • Page 26 Possible Suggested Action Reference Problem Cause Screen is blank Display mode of Reconfigure key on the Further and power the computer is computer to use a supported Information indicator is outside the display mode. section on flashing green range of the page 20.

  • Page 27: Specifications

    Analog - Separate, Composite, Sync Input Type Digital-DVI 1.0 Communications VESA DDC: E-DDC Supported Display Standard modes : IBM, VESA, MAC Modes Horiz / Vert Freq: See Factory Set Display Modes on page 20. See Display Mode Ranges on page 26. Environment Temperature: Operating: 10 to 35°...
  • Page 28 Display Mode Ranges Refresh Rate / Horizontal Frequency / Addressabillty Range ( + / - 3%) Range ( + / - 3%) 640 x 480 60 Hz 31.5 kHz 640 x 480 75 Hz 37.5 kHz 640 x 480 85 Hz 43.3 kHz 640 x 350 70 Hz...
