Display Screen Settings
1
2
3
Version Number
1. Display Settings
2. Car Settings
3. Back/Return
4. Day Theme Setting (Override)
SETTINGS MENU
Press the "Set" button (Fig. 1, #8) on the control panel to access the user controlled features and set-
tings. The "Settings" Home Screen will appear (Fig. 3) above.
DISPLAY TAB (Default Settings Screen)
Touch the "Display" Tab (Fig. 3, #1) to access various settings for the Touch Screen.
CAR TAB
Touch the "Car" Tab (Fig. 3, #2) to go the second settings menu for access to vehicle comfort and
convenience features. See next section "Vehicle Feature Settings".
RETURN BUTTON
Touch the return button (Fig. 3, #3) to exit settings mode.
DAY THEME
Touch the "DAY" button (Fig. 3, #4) to assign Daytime color theme for the Color TFT touch screen.
This setting will keep the display with light colored background regardless of outside environment
(overrides Factory control).
NIGHT THEME
Touch the "NIGHT" button (Fig. 3, #5) to assign Nighttime color theme for the Color TFT touch
screen. This setting will keep the display with dark colored background regardless of outside envi-
ronment (overrides Factory control).
AUTO THEME (Default)
Touch the "AUTO" button (Fig. 3, #6) to assign Automatic (Factory) control of the TFT color theme.
This setting will keep Data-controlled switching color theme according to the outside environment.
(Light for Daytime / Dark for Nighttime).
BRIGHTNESS
Touch the"+"/"-" Brightness buttons (Fig. 3, #7) to adjust the Brightness of the Color TFT touch
screen.
PREVIEW WINDOW
Provides a quick preview of DAY/NIGHT setting changes.
Settings Home Screen Layout
DISPLAY
CAR
Brightness
DAY
io: 48 sw:68
Figure 3
-
NIGHT
4
5
5. Night Theme Setting (Override)
6. Auto Theme Setting (Vehicle-controlled)
7. Brightness Control (TFT Screen)
8. Overview Window
Other: Software version number appears
on lower left corner of set screen
6
8
+
7
AUTO
6
