P
4
T
D
K
P
4
T
D
K
P
4
T
D
K
FCC Statement and Copyright
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in a
particular installation.
The vendor makes no representations or warranties with respect to the
contents here of and specially disclaims any implied warranties of
merchantability or fitness for any purpose. Further the vendor reserves the
right to revise this publication and to make changes to the contents here of
without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole is not allowed without
first obtaining the vendor's approval in writing.
The content of this user's is subject to be changed without notice and we
will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P4TDK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Biostar P4TDK

  • Page 1 FCC Statement and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    ENGLISH....................1 P4TDK Features..................... 1 Package contents....................1 Layout of P4TDK ....................2 CPU Installation..................... 3 DDR DIMM Modules: DDR1-4 ................4 Jumpers, Headers, Connectors & Slots .............. 5 SPANISH ....................9 Características del P4TDK..................9 Contenido del Paquete ..................9 Disposición del P4TDK ..................
  • Page 3: English

    English P4TDK Features Use Intel 82845E/ 82801DB Chipset, Winbond W83627HF, LAN Chip (optional), 1394 Chip (optional). Contains on board I/O facilities, which include two serial port, a parallel port, a PS/2 mouse port, a PS/2 keyboard port, audio ports, USB ports, a LAN port (optional) and a game port.
  • Page 4: Layout Of P4Tdk

    Layout of P4TDK JKBMS1 & Mouse JATXPWR2 JCFAN1 Socket 478 USB & LAN JRJ45USB1 JCOM1 JPRNT1 JAUXPWR1 JCOM2 INTEL 82845E AGP1 JATXPWR1 JGAME_USB1 CHIP PCI1 JDIMMVOLT JAUDIO1 BAT1 PCI2 IDE2 INTEL JCDIN1 82801DB (ICH4) PCI3 JCDIN2 IDE1 PCI4 JTAD1 FDD1...
  • Page 5: Cpu Installation

    CPU Installation Pull the lever sideways away from the socket then raise the lever up to 90-degree angle. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU. Match Pin A with the white dot/cut edge then insert the CPU.
  • Page 6: Ddr Dimm Modules: Ddr1-4

    DDR memory. However, in the market, there are so many single-sided modules occuping half bank. BIOSTAR would like to utilize the modules as many as possible. So we divide each bank into 2 sockets. That means any bank just can support one double-sided or two single-sided modules only.
  • Page 7: Jumpers, Headers, Connectors & Slots

    Jumpers, Headers, Connectors & Slots Hard Disk Connectors: IDE1/ IDE2 The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA / 33/ 66/ 100 functionality. It has two HDD connectors IDE1 (primary) and IDE2 (secondary).
  • Page 8 Power Connectors: JATXPWR1/ JATXPWR2/ JAUXPWR1 JATXPWR2 JATXPWR1 JAUXPWR1 (ATX 12V Power Conn.) (ATX Main Power Conn.) (AUX Power Conn.) DIMM Power Selection Connector: JDIMMVOLT(Optional) Pin 1-2 off ==> 2.6V Pin 1-2 on ==> 2.6V Pin 3-4 off ==> 2.7V Pin 3-4 on ==> 2.7V JDIMMVOLT JDIMMVOLT Pin 5-6 off ==>...
  • Page 9 Front Panel Connector: JPANEL1 ==> Speaker Conn. HLED ==> Hard Driver LED PWR_LED ==> Reset Button HLED ==> Infrared Conn. ON/OFF ==> Sleep Button PWR_LED ==> Power LED ON/ OFF ==> Power-on Button Memory Stick Header: JMS1 (optional) Pin1 ==> Ground , Pin2 ==> MS1 Pin3 ==>...
  • Page 10 Smart Card Header: JSC1 (optional) Pin1 ==> 5V , Pin2 ==> Ground Pin3 ==> SCAPWRCTL# Pin4 ==> SCAR5# Pin5 ==> SCAC4 , Pin6 ==> SCALED Pin7 ==> SCAIO , Pin8 ==> SCAC8 JSC1 Pin9 ==> SCACLK Pin10 ==> SCAPSNT Audio Subsystem: JAUDIO1/ JTAD1(Optional)/ JCDIN1/ JCDIN2(Optional) JAUDIO1 JTAD1 =>...
  • Page 11: Spanish

    Spanish Características del P4TDK Usa Chipset Intel 82845E/ 82801DB, Winbond W83627HF, Chip LAN (opcional), Chip 1394 (opcional). Contiene facilidades I/O integrados en la placa madre en el que incluye dos puertos en series, un puerto paralelo, un puerto para ratón PS/2, un puerto para teclado PS/2, puertos de audio, puertos USB, puerto LAN (opcional) y un puerto para juego.
  • Page 12: Disposición Del P4Tdk

    Disposición del P4TDK JKBMS1 & Mouse JATXPWR2 JCFAN1 Socket 478 USB & LAN JRJ45USB1 JCOM1 JPRNT1 JAUXPWR1 JCOM2 INTEL 82845E AGP1 JATXPWR1 JGAME_USB1 CHIP PCI1 JDIMMVOLT JAUDIO1 BAT1 PCI2 IDE2 INTEL JCDIN1 82801DB (ICH4) PCI3 JCDIN2 IDE1 PCI4 JTAD1 FDD1...
  • Page 13: Instalación De La Cpu

    Instalación de la CPU Tire de la palanca del lado del zócalo, luego levante la palanca hasta un ángulo de 90 grados. Sitúe el contacto A del zócalo y busque el punto blanco o corte el borde en la CPU. Empareje el contacto A con el punto blanco/ corte del borde, luego inserte la CPU.
  • Page 14: Módulos Ddr Dimm: Ddr1-4

    2 bancos de memoria DDR. Sin embargo, en el mercado hay muchos módulos single-sided ocupando el banco medio. BIOSTAR desearía utilizar los módulos tantos como sea posible. Debido a ésto, hemos dividido a cada banco en 2 zócalos. Ésto quiere decir que cualquier banco solamente puede apoyar un modulo double-sided o dos modulos single-sided.
  • Page 15: Puentes, Cabezales, Conectores Y Ranuras

    Puentes, Cabezales, Conectores y Ranuras Conectores del Disco Duro: IDE1/ IDE2 La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO 0~4, Bus Master, y funcionalidad Ultra DMA / 33/ 66/ 100. Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario). Los conectores IDE pueden conectarse a un master y a un esclavo drive para así...
  • Page 16 Conectores de Corriente: JATXPWR1/ JATXPWR2/ JAUXPWR1 JATXPWR2 JATXPWR1 JAUXPWR1 (ATX 12V Conector de Corriente.) (ATX Conector de Corriente Principal.) (AUX Conector de Corriente.) Conector de Selección de la Corriente DIMM: JDIMMVOLT(Opcional) Pin 1-2 off ==> 2.6V Contacto 1-2 encendido ==> 2.6V Pin 3-4 off ==>...
  • Page 17 Conector del Panel Frontal: JPANEL1 ==> Conector del Altavoz HLED ==> LED del Disco Duro PWR_LED ==> Boton de Reinicio HLED ==> Conexion Infrarojo ON/OFF ==> Boton de Suspension PWR_LED ==> Corriente LED ON/ OFF ==> Boton de Encendido Cabezal Memory Stick: JMS1 (opcional) Contacto1 ==>...
  • Page 18 Cabezal Smart Card: JSC1 (opcional) Contacto1 ==> 5V , Contacto2 ==> Tierra Contacto3 ==> SCAPWRCTL# Contacto4 ==> SCAR5# Contacto5 ==> SCAC4 , Contacto6 ==> SCALED Contacto7 ==> SCAIO , Contacto8 ==> SCAC8 JSC1 Contacto9 ==> SCACLK Contacto10 ==> SCAPSNT Subsistema de Audio: JAUDIO1/ JTAD1(Opcional)/ JCDIN1/ JCDIN2(Opcional) JAUDIO1 JTAD1 =>...
  • Page 19: Trouble Shooting

    Trouble Shooting PROBABLE SOLUTION No power to the system at all Power light don’t * Make sure power cable is securely plugged in illuminate, fan inside power supply does not turn * Replace cable on. Indicator light on keyboard does not turn on * Contact technical support PROBABLE SOLUTION...
  • Page 20: Solución De Problemas

    Solución de Problemas CAUSA PROBABLE SOLUCIÓN No hay corriente en el sistema. La luz de * Asegúrese que el cable de transmisión esté corriente no ilumina, ventilador dentro de la seguramente enchufado. fuente de alimentación apagada. Indicador de * Reemplace el cable. luz del teclado apagado.
  • Page 21 04/30/2002...
