FCC Statement and Copyright
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in a
particular installation.
The vendor makes no representations or warranties with respect to the
contents here of and specially disclaims any implied warranties of
merchantability or fitness for any purpose. Further the vendor reserves the
right to revise this publication and to make changes to the contents here of
without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole is not allowed without
first obtaining the vendor's approval in writing.
The content of this user's is subject to be changed without notice and we
will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P4TDH and is the answer not in the manual?

Questions and answers

Summary of Contents for Biostar P4TDH

  • Page 1 FCC Statement and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    ENGLISH..................... 1 P4TDH Features........................1 Package contents ........................ 2 Layout of P4TDH ......................... 2 CPU Installation........................3 DDR DIMM Modules: DDR1-3..................... 4 Jumpers, Headers, Connectors & Slots ................5 ESPAÑOL ....................11 Características del P4TDH ....................11 Contenido del Paquete ...................... 12 Disposición del P4TDH......................
  • Page 3 TROUBLE SHOOTING................52 SOLUCIÓN DE PROBLEMAS ..............53 PROBLEMLÖSUNG ................. 54 トラブルシューティング ..................55...
  • Page 4: English

    English P4TDH Features Use Intel 82845G/ 82801DB Chipset, Winbond W83627HF, LAN Chip (optional), Serials ATA Controller (optional), IEEE 1394 chip (optional) and H/W sound chip CMI 8738 (optional). Contains on board I/O facilities, which include a serial port, a parallel port, a...
  • Page 5: Package Contents

    Flash Memory Writer for BIOS update X 1 USB Cable X 2 (Optional) Rear I/O Panel for ATX Case X 1 (Optional) Fully Setup Driver CD X 1 IEEE 1394 Cable X 1 (Optional) Layout of P4TDH JKBMS1 JKBV1 & Mouse...
  • Page 6: Cpu Installation

    CPU Installation Pull the lever sideways away from the socket then raise the lever up to 90-degree angle. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU. Match Pin A with the white dot/cut edge then insert the CPU.
  • Page 7: Ddr Dimm Modules: Ddr1-3

    DDR memory. However, in the market, there are so many single-sided modules occuping half bank. BIOSTAR would like to utilize the modules as many as possible. So we divide one bank into 2 sockets. That means the bank just can support one double-sided or two single-sided modules only.
  • Page 8: Jumpers, Headers, Connectors & Slots

    Jumpers, Headers, Connectors & Slots Hard Disk Connectors: IDE1/ IDE2/ (IDE3=>optional) The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA / 33/ 66/ 100 functionality. It has three HDD connectors IDE1 (primary), IDE2 (secondary) and IDE3 (optional).
  • Page 9 Power Connectors: JATXPWR1/ JATXPWR2 JATXPWR2 (ATX 12V Power Conn.) JATXPWR1 (ATX Main Power Conn.) DIMM Power Selection Header: JDIMMVOLT (Optional) Jump open ==> 2.5V Pin 1-2 off ==> 2.6V Pin 1-2 on ==> 2.6V Pin 3-4 off ==> 2.7V Pin 3-4 on ==> 2.7V JDIMMVOLT JDIMMVOLT Pin 5-6 off ==>...
  • Page 10 Front USB Header: JUSB3/ JUSB4 Pin1,2 ==> +5V Pin3,4 ==> Data(-) Pin5,6 ==> Data(+) Pin7,8 ==> Ground Pin9 ==> KEY JUSB3/4 Pin10 ==> NA 5V/ 5VSB Selection for USB: JUSBV1/ (JUSBV2/3_4=> Optional) Pin 1-2 on ==> 5V Pin 2-3 on ==> 5V_SB JUSBV1/2/3_4 5V/ 5VSB Selection for Keyboard: JKBV1 Pin 1-2 on ==>...
  • Page 11 Memory Stick Header: JMS1 (optional) Pin1 ==> Ground , Pin2 ==> MS1 Pin3 ==> 3.3V , Pin4 ==> MS2 Pin5 ==> MS3 , Pin6 ==> MS4 Pin7 ==> MS5 , Pin8 ==> MSCLK JMS1 Pin9 ==> MSPWCTL# Pin10 ==> MSLED SD Memory Card Header: JSD1 (optional) Pin1 ==>...
  • Page 12 Front Panel Connector: JPANEL1 PWR_LED ON/OFF HLED ==> Speaker Conn. HLED ==> Hard Driver LED ==> Reset Button ==> Infrared Conn. ==> Sleep Button PWR_LED ==> Power LED ON/ OFF ==> Power-on Button Audio Subsystem: JAUDIO1/ JCDIN1 JAUDIO1 JCDIN1 (Front Audio Header) (CD-ROM Audio-In Header)
  • Page 13: Back Panel Connectors

    Front Panel Audio Connector/ Jumper Block Pin 5 and 6 Audio line out signals are routed ==> to the back panel audio line out connector. Pin 9 and 10 Audio line out and mic in signals are available for front panel audio connectors. Back Panel Connectors RJ45USB1 JKBMS1...
  • Page 14: Español

    Español Características del P4TDH Usa Chipset Intel 82845G/ 82801DB, Winbond W83627HF, Chip LAN (opcional), Controlador Serials ATA (opcional), Chip IEEE 1394 (opcional) y chip de audio H/W CMI 8738 (opcional). Contiene facilidades I/O integrados en la placa madre, en el que incluye un puerto en serie, un puerto paralelo, un puerto VGA, un puerto de ratón...
  • Page 15: Contenido Del Paquete

    Flash Memory Writer para actualización del BIOS X 1 Cable USB X 2 (Opcional) Panel trasero I/O para caja ATX X 1 (Opcional) Configuración completa del Driver CD X 1 Cable IEEE 1394 X1 (Opcional) Disposición del P4TDH JKBMS1 Teclado JKBV1 &...
  • Page 16: Instalación De La Cpu

    Instalación de la CPU Tire de la palanca del lado del zócalo, luego levante la palanca hasta un ángulo de 90 grados. Sitúe el contacto A del zócalo y busque el punto blanco o corte el borde en la CPU. Empareje el contacto A con el punto blanco/ corte del borde, luego inserte la CPU.
  • Page 17: Módulos Ddr Dimm: Ddr1-3

    2 bancos de memoria DDR. Sin embargo, en el mercado existe cantidades de módulos de una cara ocupando la mitad de los bancos. BIOSTAR desea utilizar los módulos a la mayor cantidad posible. Es por ésta razon que dividimos un banco en 2 sockets.
  • Page 18: Conectores, Cabezales, Puentes Y Ranuras

    Conectores, Cabezales, Puentes y Ranuras Conectores del Disco Duro: IDE1/ IDE2/ (IDE3=>opcional) La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO 0~4, Bus Master, y funcionalidad Ultra DMA / 33/ 66/ 100. Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario). El conector IDE puede conectar a un master y un drive esclavo, así...
  • Page 19 diseñando como el bus estándar para la tarjeta de expansion en los ’90 para las máquinas PC XT/AT. Ésta placa madre conserva compatibilidad hacia atrás con el antiguo y configuración lenta del bus. Conectores de Corriente: JATXPWR1/ JATXPWR2 JATXPWR2 (ATX 12V Conector de Corriente) JATXPWR1 (ATX Conector de Corriente Principal) Cabezal de Selección de la Corriente DIMM: DIMMVOLT...
  • Page 20 Cabezal Frontal USB: JUSB3/ JUSB4 Pin1,2 ==> +5V Pin3,4 ==> Dato(-) Pin5,6 ==> Dato(+) Pin7,8 ==> Tierra JUSB3/4 Pin9 ==> KEY Pin10 ==> NA 5V/ 5VSB Selección para USB: JUSBV1/ (JUSBV2/3_4 => Opcional) Contacto 1-2 encendido ==> 5V Contacto 2-3 encendido ==> 5V_SB JUSBV1/2/3_4 5V/ 5VSB Selección para Teclado: JKBV1 Contacto 1-2 encendido...
  • Page 21 Cabezal Memory Stick: JMS1 (opcional) Contacto1 ==> Tierra , Pin2 ==> MS1 Contacto3 ==> 3.3V , Contacto4 ==> MS2 Contacto5 ==> MS3 , Contacto6 ==> MS4 Contacto7 ==> MS5 , Contacto8 ==> MSCLK JMS1 Contacto9 ==> MSPWCTL# Contacto10 ==> MSLED Cabezal de la Tarjeta de Memoria SD: JSD1 (opcional) Contacto1 ==>...
  • Page 22 Conector del Panel Frontal: JPANEL1 PWR_LED ON/OFF HLED ==> Conector de Altavoz HLED ==> LED del Disco Duro ==> Boton de Reinicio ==> Conector Infrarojo ==> Boton de Suspension PWR_LED ==> Corriente LED ON/ OFF ==> Boton de Encendido Subsistema de Audio: JAUDIO1/ JCDIN1 JAUDIO1 (Cabezal de Audio Frontal) JCDIN1...
  • Page 23 Conector del Panel Frontal de Audio/ Jumper Block Pin 5 y 6 La senal de salida de linea del Audio ==> encamina al conector de la salida de linea Pin 9 y 10 del Audio ubicado en el panel trasero. La senal de salida de linea del Audio y la senal de Entrada del Mic estan disponibles desde el conector de Audio del panel frontal.
  • Page 24: Deutsch

    Deutsch Merkmale des P4TDH Verwendet einen Intel 82845G/ 82801DB Chipsatz, Winbond W83627HF, LAN-Chip (optional), serieller ATA Controller (optional), IEEE 1394 Chip (optional) und H/W Sound-Chip CMI 8738 (optional). Enthält Onboard I/O-Einrichtungen, wie z.B. serielle Schnittstelle, parallele Schnittstelle, VGA-Schnittstelle, PS/2-Mausschnittstelle, PS/2-Tastaturschnittstelle,...
  • Page 25: Packungsinhalt

    HDD-Kabel X 1, FDD-Kabel X 1 Flash-Speicher-Writer für BIOS-Aktualisierung X 1 USB-Kabel X 2 (Optional) I/O-Rückseite für ATX-Gehäuse X 1 (Optional) Installations-CD für Treiber X 1 IEEE 1394-Kabel X 1 (Optional) Layout des P4TDH JKBMS1 JKBV1 K/B & Maus JATXPWR2...
  • Page 26: Installation Der Cpu

    Installation der CPU Ziehen Sie den Hebel seitwärts von der Sockel und neigen Sie ihn um 90-Grad nach oben. Suchen Sie Pin A im Sockel und den weißen Punkt oder die Abschnittkante in der CPU. Passen Sie Pin A mit dem weißen Punkt/der Abschnittkante zusammen und legen Sie danach die CPU ein.
  • Page 27: Ddr-Dimm-Module: Ddr1-3

    Motherboard nur bis zu 2 Bänke von DDR-Speicher. Auf dem Markt gibt es jedoch viele einseitige Module die nur eine halbe Bank belegen. BIOSTAR möchte so viele Module wie möglich verwenden, daher wird eine Bank in 2 Sockel aufgeteilt. Das bedeutet, dass die Bank nur einen doppelseitigen oder zwei einseitige Module unterstützt.
  • Page 28: Jumper, Header, Anschlüsse & Slots

    Jumper, Header, Anschlüsse & Slots Festplattenanschlüsse: IDE1/ IDE2/ (IDE3=>optional) Das Motherboard ist mit einem 32-bit erweiterte PCI IDE Controller ausgestattet, welcher den PIO Modus 0~4, Bus Master, und Ultra DMA / 33/ 66/ 100 Funktionen zur Vefügung stellt. Dieser ist mit drei HDD-Anschlüssen versehen IDE1 (primär), IDE2 (sekundär) und IDE3 (optional).
  • Page 29 Stromanschlüsse: JATXPWR1/ JATXPWR2 JATXPWR2 (ATX 12V Stromanschl.) JATXPWR1 (ATX Netzstromanschl.) DIMM Power Selection Header: JDIMMVOLT (Optional) Jump offen ==> 2.5V Pin 1-2 off ==> 2.6V Pin 1-2 ein ==> 2.6V Pin 3-4 off ==> 2.7V Pin 3-4 ein ==> 2.7V JDIMMVOLT JDIMMVOLT Pin 5-6 off ==>...
  • Page 30 Front USB Header: JUSB3/ JUSB4 Pin1,2 ==> +5V Pin3,4 ==> Daten(-) Pin5,6 ==> Daten(+) Pin7,8 ==> Masse Pin9 ==> KEY JUSB3/4 Pin10 ==> nicht belegt 5V/ 5VSB Auswahl für USB: JUSBV1/ (JUSBV2/3_4=> Optional) Pin 1-2 ein ==> 5V Pin 2-3 ein ==> 5V_SB JUSBV1/2/3_4 5V/ 5VSB Auswahl für Tastatur: JKBV1 Pin 1-2 ein ==>...
  • Page 31 Memory Stick Header: JMS1 (optional) Pin1 ==> Masse , Pin2 ==> MS1 Pin3 ==> 3.3V , Pin4 ==> MS2 Pin5 ==> MS3 , Pin6 ==> MS4 Pin7 ==> MS5 , Pin8 ==> MSCLK JMS1 Pin9 ==> MSPWCTL# Pin10 ==> MSLED SD-Speicherkarte-Header: JSD1 (optional) Pin1 ==>...
  • Page 32 Anschlüsse auf der Vorderseite: JPANEL1 PWR_LED EIN/AUS HLED ==> Lautsprecheranschl. HLED ==> Festplattenanzeige ==> Reset-Taste ==> Infrarotanschl. ==> Sleep-Taste PWR_LED ==> Stromanzeige EIN/ AUS ==> Ein-/Ausschalttaste Audio Subsystem: JAUDIO1/ JCDIN1 JAUDIO1 JCDIN1 (Front Audio Header) (CD-ROM Audio-In Header)
  • Page 33 Audio-Anschluss auf Vorderseite/ Jumper-Block Pin 5 and 6 Audio Line Out Signale werden an den ==> Audio Line Out Anschluss auf der kseite weitergeleitet. Pin 9 and 10   Audio Line Out und Mikro In Signale sind f die Anschl se  ...
  • Page 34: 日本語

    日本語 P4TDH の機能 Intel 82845G/ 82801DBチップセット、Winbond W83627HF、LANチップ (オプション)、シリアルATAコントローラ(オプション)、IEEE 1394チ ップ(オプション)、H/WサウンドチップCMI 8738(オプション)使用。 シリアルポート、パラレルポート、VGAポート、PS/2マウスポート、PS/2 キーボードポート、オーディオポート、USBポート、LANポート(オプシ ョン)、ゲームポートに2つのUSB(オプション)ゲームポートを含むオン ボードI/O設備を搭載しています。 ® Intel Pentium 4 (ソケット478)プロセッサ最大2.53 GHz対応。 Ultra 100/66/33、BMIDE、PIOモード対応。 USB2.0高速デバイス対応。 DDR 200/266 MHzアンレジスタ(非ECC)デバイス用に、最大3つのシン グルサイドまたは2つのダブルサイド*8に対応。速度は400/533 MHz フロントサイド バス周波数。 ダブルサイド x 16 DDRデバイスには対応していません。 AGP 2.0インターフェース、2X/4X高速書込みプロトコル対応。(1.5Vのみ) PC ATX形式フォームファクター仕様に対応。 Windows 98SE、Windows NT、Windows 2000、Windows ME、Windows XP、LINUX、SCO UNIXなどの人気のOSに対応。...
  • Page 35: パッケージ内容

    パッケージ内容 HDDケーブル X 1、FDDケーブル X 1 BIOSアップデート用のフラッシュメモリ書込み X 1 USBケーブル X 2 (オプション) ATXケース用の背面I/Oパネル X 1 (オプション) 完全セットアップドライバCD X 1 IEEE 1394ケーブル X 1 (オプション) P4TDH のレイアウト JKBMS1 K / B JKBV1 と マ ウ ス JATXPWR2 JATXPWR2 JCFAN1 ソケ ット...
  • Page 36: Cpu のインストール

    CPU のインストール ソケットからレバーを横に引き、レバーを90°の角度に上げてください。 ソケット内でピンAの位置を確認し、CPUの白い点または端を固定してくださ い。ピンAを白い点または端に合わせ、CPUを挿入してください。 レバーを下に下ろしてください。ファンをCPUに乗せ、金具で留めて、ファンの電 源ポートをJCFAN1に取り付けてください。 CPU/システムファンヘッダー:JCFAN1/ JSFAN1 設 置 設 置 セ ンス セ ンス JCFAN1 JSFAN1...
  • Page 37: Ddr Dimm モジュール:Ddr1-3

    DDR DIMM モジュール:DDR1-3 DRAMアクセス時間:2.5Vアンレジスタ(非ECC)DDR 200/266 MHz タイプが必要。 DRAMタイプ:64MB/ 128MB/ 256MB/ 512MB DIMMモジュール (184ピン) チップセットの限度により 、 このボードは2バンクまでのDDRメモリに対 応しています。 但し、市販されている製品の中には、シングルサイドモジュールが バンクの半分を占領しているものが多くあります。BIOSTARはモジュー ルをできるだけ利用しようと考えました。そこで、私たちはバンクを2 つのソケットに分割しました。つまり、バンクは1つのダブルサイドまた は2つのシングルサイドモジュールのみに対応できることになります。 DDR1 DDR2 バンク DDR3 Does not support Double-sided * 16 DDR Dimms 1には2つのDDRソケットが含まれ、1つが白、1つが青となっています。 ※ 1つのDDRモジュールがあり、これがシングルなのか、ダブル サイドDDR モジュールなのかわからない場合は、DDR1(青い方)のソケットに挿入して みてください。...
  • Page 38: ジャンパー、ヘッダー、コネクタ、スロット

    ジャンパー、ヘッダー、コネクタ、スロット ハードディスク コネクタ:IDE1/ IDE2/ (IDE3=>オプション) このマザーボードには32ビットのエンハンスPCI IDEコントローラが搭載されており、PIO モード0-4、バスマスター、Ultra DMA / 33 /66 / 100機能を提供することができま す。IDE1(プライマリ)、IDE2 (セカンダリ)、IDE3(オプション)の3つのHDDコネクタがります。 IDEコネクタはマスター及びスレーブドライブに接続し、最大4つまでのハードドライブを 接続することができます。最初のハードドライブは、常にIDE1に接続してください。 シリアル ATA コネクタ:(JSATA1/ JSATA2=>オプション) このマザーボードには、2チャンネルのS-ATAインターフェースを持つPCIからSATAへの コントローラが含まれています。SATA 1.0仕様を満たし、最大5GHzの速度でデータ を転送することができます。 フロッピーディスク コネクタ:FDD1 このマザーボードは標準フロッピーディスク コネクタを搭載しており、360K、720K、 1.44M、2.88Mのフロッピーディスクに対応しています。このコネクタはフロッピーディスク ドライブのリボンケーブルに対応しています。 アクセレレーション グラフィックポートスロット AGP1 お使いのモニタを直接ビデオカードに接続することができます。このマザーボードはPCI スロットのビデオカードに対応していますが、アクセレレーション グラフィック ポート (AGP/1.5V及び4X AGPカードのみ対応)も搭載されています。AGPカードはAGP 技術を利用し、ビデオ効果と性能、特に3Dの性能を大幅に改善します。...
  • Page 39 電源コネクタ:JATXPWR1/ JATXPWR2 JATXPWR2 (A T X 12V 電 源 接 続 ) JATXPWR1 (A T X M a in電 源 接 続 ) DIMM 電源選択ヘッダー:JDIMMVOLT (オプション) Pin 1-2 off ==> 2.6V Pin 3-4 off ==> 2.7V JDIMMVOLT JDIMMVOLT Pin 5-6 off ==> 2.8V Pin 7-8 off ==>...
  • Page 40 USBの5V/ 5VSB選択:JUSBV1/ (JUSBV2/3_4=> オプション) ピン1 - 2オ ン = = > 5 V ピン2 - 3オ ン = = > 5 V _S B JUSBV1/2/3_4 キーボードの 5V/ 5VSB 選択:JKBV1 ピン1 - 2オ ン = = > 5 V ピン2 - 3オ ン = = > 5 V _S B JKBV1 フロント...
  • Page 41 SD メモリカードヘッダー:JSD1 (オプション) ピン1 = = > G ro u n d , ピン2 = = > S 1 ピン3 = = > 3 .3 V , ピン4 = = > S 2 ピン5 = = > S D 3 , ピン6 = = >...
  • Page 42 オーディオ サブシステム:JAUDIO1/ JCDIN1 JAUDIO1 JCDIN1 (C D - R O M オ ー デ ィオ イン ヘ ッダ ー ) (フロントオ ー デ ィオ ヘ ッダ ー )
  • Page 43 フロ ントパ ネ ル コネ クタ/ジ ャンパ ー ブロック オ ー デ ィオ ライン出 力 シ グ ナ ル は バ ックパ ネ ル の オ ー デ ィオ 出 力 コネ クタに 接 続 。 オ ー デ ィオ ライン出 力 とマ イク入 力 シ グ ナ ル は フロ ントパ ネ ル...
  • Page 44: Warpspeeder

    WarpSpeeder Introduction [ WarpSpeeder™ ], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click. The Overvoltage Manager, on the other hand, helps to power up CPU core voltage and Memory voltage.
  • Page 45: System Requirement

    System Requirement OS Support: Windows 98 SE, Windows 98 Me, Windows 2000, Windows XP DirectX: DirectX 8.1 or above. (The Windows XP operating system includes DirectX 8.1. If you use Windows XP, you do not need to install DirectX 8.1.) Installation Execute the setup execution file, and then the following dialog will pop up.
  • Page 46 When you see the following dialog in setup procedure, it means setup is completed. If the “Launch the WarpSpeeder Tray Utility” checkbox is checked, the Tray Icon utility and [ WarpSpeeder™ ] utility will be automatically and immediately launched after you click “Finish”...
  • Page 47: Usage

    Usage [ WarpSpeeder™ ] includes 1 tray icon and 5 panel: 1. Tray Icon: Whenever the Tray Icon utility is launched, it will display a little tray icon on the right side of Windows Taskbar. This utility is responsible for conveniently invoking [ WarpSpeeder™ ] Utility. You can use mouse to left-click the little tray icon to invoke [ WarpSpeeder™...
  • Page 48 the following figure; the utility’s first window you see is Main Panel. Main Panel contains features as follows: a. Display the CPU Speed, CPU external clock, Memory clock, AGP clock, and PCI clock information. b. Contains About, Voltage, Overclock, and Hardware Monitor Buttons for invoking respective panels.
  • Page 49 3. Voltage Panel Click the Voltage button in Main Panel, the button will be highlighted and the Voltage Panel will slide out to up as the following figure. In this panel, you can decide to increase CPU core voltage and Memory voltage or not.
  • Page 50 4. Overclock Panel Click the Overclock button in Main Panel, the button will be highlighted and the Overclock Panel will slide out to left as the following figure. This panel contains the following features: a. “–3MHz button”, “-1MHz button”, “+1MHz button”, and “+3MHz button”: provide user the ability to do real-time overclock adjustment.
  • Page 51 Dialog’s setting. “Verify button”: User can click this button and [ WarpSpeeder™ ] will proceed a testing for current frequency. If the testing is ok, then the current frequency will be saved into system registry. If the testing fails, system will do a fail-safe rebooting. After reboot, the [ WarpSpeeder™ ] utility will restore to the hardware default setting or load the verified best and stable frequency according to the Recovery Dialog’s setting.
  • Page 52 5. Hardware Monitor Panel Click the Hardware Monitor button in Main Panel, the button will be highlighted and the Hardware Monitor panel will slide out to left as the following figure. In this panel, you can get the real-time status information of your system. The information will be refreshed every 1 second.
  • Page 54 Note: Because the overclock, overvoltage, and hardware monitor features controlled several separate chipset, [ WarpSpeeder™ ] divide these features to separate panels. If one chipset is not on board, the correlative button in Main panel will be disabled, but will not interfere other panels’ functions. This property can make [ WarpSpeeder™...
  • Page 55: Trouble Shooting

    Trouble Shooting PROBABLE SOLUTION No power to the system at all Power light don’t * Make sure power cable is securely plugged in illuminate, fan inside power supply does not turn * Replace cable on. Indicator light on keyboard does not turn on * Contact technical support PROBABLE SOLUTION...
  • Page 56: Solución De Problemas

    Solución de Problemas CAUSA PROBABLE SOLUCIÓN No hay corriente en el sistema. La luz de * Asegúrese que el cable de transmisión esté corriente no ilumina, ventilador dentro de la seguramente enchufado. fuente de alimentación apagada. Indicador de * Reemplace el cable. luz del teclado apagado.
  • Page 57: Problemlösung

    Problemlösung MÖGLICHE URSACHE LÖSUNG Das System hat keine Spannungsversorgung. * Versichern Sie sich, dass das Stromkabel richtig Die Stromanzeige leuchtet nicht, der Lüfter im angebracht ist Inneren Stromversorgung wird nicht * Ersetzen Sie das Stromkabel eingeschaltet. Tastaturleuchten sind nicht an. * Wenden Sie sich an Ihre Kundendienststelle MÖGLICHE URSACHE LÖSUNG...
  • Page 58: トラブルシューティング

    トラブルシューティング トラブル 解決方法 電源ライトが点灯せず、給電されていない。電源内のフ * 電源ケーブルが正しく接続されているか確認してくださ ァンも稼動しない。キーボードのインジケータも点灯して い。 いない。 * ケーブルを交換してください。 * テクニカルサポートにご連絡ください。 トラブル 解決方法 システムが作動しない。キーボードの電源がオンになり、 * DIMMの両端に均等に力をかけ、モジュールがしっかり インジケータも点灯する。ハードディスクも回転している。 と容器に収まるまで、押し込んでください。 トラブル 解決方法 * ディスクからディスクコントローラボードへのケーブルを点 シ ス テ ム が ハ ー ド デ ィ ス ク ド ラ イ ブ か ら 起 動 し な い 。 CD-ROMからの起動となる。...
  • Page 59 2つ目のハードディスクをインストールした後、システムが * マスター/スレーブジャンパーを正しく設定してください。 起動しなくなった。 * SETUPプログラムを実行し、正しいドライブタイプを選 択してください。ドライブの製造元に問い合わせ、他の ドライブとの互換性を確認してください。...
  • Page 60 07/22/2002...
