FCC Statement and Copyright
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in a
particular installation.
The vendor makes no representations or warranties with respect to the
contents here of and specially disclaims any implied warranties of
merchantability or fitness for any purpose. Further the vendor reserves the
right to revise this publication and to make changes to the contents here of
without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole is not allowed without
first obtaining the vendor's approval in writing.
The content of this user's is subject to be changed without notice and we
will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P4TDG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Biostar P4TDG

  • Page 1 FCC Statement and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    ENGLISH... 1 P4TDG Features ... 1 Package contents... 1 Layout of P4TDG ... 2 CPU Installation... 2 CPU Installation... 3 DDR DIMM Modules: DDR1-2 ... 4 Jumpers, Headers, Connectors & Slots ... 5 ESPAÑOL... 10 Características del P4TDG ... 10 Contenido del Paquete ...
  • Page 3: English

    English P4TDG Features Use Intel 82845G/ 82801DB Chipset, Winbond W83627HF, LAN Chip (optional). Contains on board I/O facilities, which include a serial port, a parallel port, a VGA port, a PS/2 mouse port, a PS/2 keyboard port, audio ports, USB ports, a LAN port (optional) and a game port.
  • Page 4: Layout Of P4Tdg

    Rear I/O Panel for Micro-ATX Case X 1 (Optional) Fully Setup Driver CD X 1 Layout of P4TDG JKBV1 & Mouse JKBMS1 JATXPWR2 Socket 478 USB & LAN JUSBV1 JRJ45USB1 JCOM1 JPRNT1 JVGA1 JGAME_USB1 JUSBV2 CHIP JAUDIO1 JTAD1 JCDIN1 JCDIN2...
  • Page 5: Cpu Installation

    CPU Installation Pull the lever sideways away from the socket then raise the lever up to 90-degree angle. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU. Match Pin A with the white dot/cut edge then insert the CPU.
  • Page 6: Ddr Dimm Modules: Ddr1-2

    DDR DIMM Modules: DDR1-2 DRAM Access Time: 2.5V Unregister (Non-ECC) DDR 200/266 MHz Type required. DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin) DIMM Socket DDR Module Location DDR 1 64MB/128MB/256MB/512MB/1GB DDR 2 64MB/128MB/256MB/512MB/1GB * The list shown above for DRAM configuration is only for reference. How to install a DIMM Module 1.
  • Page 7: Jumpers, Headers, Connectors & Slots

    Peripheral Component Interconnect Slots: PCI1-3 This motherboard is equipped with 3 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards, which has, supplanted the older ISA bus standard in...
  • Page 8 Power Connectors: JATXPWR1/ JATXPWR2/ (JAUXPWR1=>Optional) JATXPWR2 JATXPWR1 (ATX 12V Power Conn.) (ATX Main Power Conn.) DIMM Power Selection Connector: JDIMMVOLT JDIMMVOLT JDIMMVOLT (Default ==> 2.5V) (Default ==> 2.6V) Wake On LAN Header: WOL1 Ground 5V_SB Wake up WOL1 Front USB Header: JUSB3/(JUSB4=>Optional) Pin1,2 ==>...
  • Page 9 5V/ 5VSB Selection for USB: JUSBV1/ (JUSBV2/3_4=> Pin 1-2 on ==> 5V Pin 2-3 on ==> 5V_SB JUSBV1/2/3_4 5V/ 5VSB Selection for Keyboard: JKBV1 Pin 1-2 on ==> 5V Pin 2-3 on ==> 5V_SB JKBV1 Memory Stick Header: JMS1 (optional) Pin1 ==>...
  • Page 10 Smart Card Header: JSC1 (optional) Pin1 ==> 5V Pin3 ==> SCAPWRCTL# Pin4 ==> SCAR5# Pin5 ==> SCAC4 , Pin6 ==> SCALED Pin7 ==> SCAIO , Pin8 ==> SCAC8 JSC1 Pin9 ==> SCACLK Pin10 ==> SCAPSNT Front Panel Connector: JPANEL1 PWR_LED HLED ==>...
  • Page 11: Back Panel Connectors

    Audio Subsystem: JAUDIO1/ (JTAD1=>Optional)/ JCDIN1/ (JCDIN2=>Optional) JAUDIO1 (Front Audio Header) JCDIN2 => optional (CD-ROM Audio-In Header) Back Panel Connectors RJ45USB1 JKBMS1 JPRNT1 LAN(Optional) PS/2 Mouse Parallel PS/2 COM1 COM1 Keyboard JCOM1 (Normal Mode) RJ45USB1 RJ45USB1 JKBMS1 JKBMS1 JPRNT1 JPRNT1 LAN(Optional) LAN(Optional) PS/2 PS/2...
  • Page 12: Español

    Español Características del P4TDG Usa Chipset Intel 82845G/ 82801DB, Winbond W83627HF, LAN Chip (opcional). Contiene facilidades I/O integrados en la placa madre en el que incluye un puerto serie, un puerto paralelo, un puerto VGA, un puerto de ratón PS/2, un puerto de teclado PS/2, puertos de audio, puertos USB, un puerto LAN (opcional) y un puerto de juego.
  • Page 13: Disposición Del P4Tdg

    Cable USB X 2 (Opcional) Panel trasero I/O para ATX X 1 (Opcional) Configuración completa del Driver CD X 1 Disposición del P4TDG Teclado JKBV1 & Raton JKBMS1 JATXPWR2 Socket 478 USB & LAN JUSBV1 JRJ45USB1 JCOM1 JPRNT1 JVGA1 JUSBV2...
  • Page 14: Instalación De La Cpu

    Instalación de la CPU Tire de la palanca del lado del zócalo, luego levante la palanca hasta formar un ángulo de 90 grados. Sitúe el contacto A del zócalo y busque el punto blanco o corte el borde en la CPU. Empareje el contacto A con el punto blanco/ corte del borde, luego inserte la CPU.
  • Page 15: Módulos Ddr Dimm: Ddr1-2

    Módulos DDR DIMM: DDR1-2 DRAM Tiempo de Acceso: 2.5V Unbuffered DDR 200/266 MHz Tipo requerido. DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulo DIMM (contacto 184) Localización del Zócalo Módulo DDR DIMM DDR 1 64MB/128MB/256MB/512MB/1GB DDR 2 64MB/128MB/256MB/512MB/1GB * La lista de arriba para la configuración DRAM es solamente para referencia.
  • Page 16: Conectores, Cabezales, Puentes Y Ranuras

    Conectores, Cabezales, Puentes y Ranuras Conectores del Disco Duro: IDE1/ IDE2 La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO 0~4, Bus Master, y funcionalidad Ultra DMA / 33/ 66/ 100. Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario). El conector IDE puede conectar a un master y un drive esclavo, así...
  • Page 17 Conectores de Corriente: JATXPWR1/ JATXPWR2/ (JAUXPWR1=>Opcional) JATXPWR2 (ATX 12V Conector de Corriente.) (ATX Conector de Corriente Principal.) Conector de la Corriente de Selección DIMM: JDIMMVOLT Puente Abierto ==> 2.5V Pin 1-2 off ==> 2.6V Contacto 1-2 encendido ==> 2.6V Pin 3-4 off ==> 2.7V Contacto 3-4 encendido ==>...
  • Page 18 5V/ 5VSB Selección para USB: JUSBV1/ (JUSBV2/3_4 Contacto 1-2 encendido ==> 5V Contacto 2-3 encendido ==> 5V_SB JUSBV1/2/3_4 5V/ 5VSB Selección para Teclado: JKBV1 Contacto 1-2 encendido ==> 5V Contacto 2-3 encendido ==> 5V_SB JKBV1 Cabezal Memory Stick: JMS1 (opcional) Contacto1 ==>...
  • Page 19 Cabezal Smart Card: JSC1 (opcional) Contacto1 ==> 5V Contacto3 ==> SCAPWRCTL# Contacto4 ==> SCAR5# Contacto5 ==> SCAC4 , Contacto6 ==> SCALED Contacto7 ==> SCAIO , Contacto8 ==> SCAC8 JSC1 Contacto9 ==> SCACLK Contacto10 ==> SCAPSNT Conector del Panel Frontal: JPANEL1 PWR_LED HLED PWR_LED ==>...
  • Page 20 Subsistema de Audio: JAUDIO1/ (JTAD1=>Opcional)/ JCDIN1/ (JCDIN2=>Opcional) JAUDIO1 (Cabezal de Audio Frontal) JCDIN2 => opcional (Cabezal de Entrada de Audio CD-ROM) Conectores del Panel Trasero RJ45USB1 JKBMS1 JPRNT1 LAN(Opcional) Raton PS/2 Paralelo Teclado COM1 COM1 PS/2 JCOM1 (Modo Normal) RJ45USB1 RJ45USB1 JKBMS1 JKBMS1...
  • Page 21: Trouble Shooting

    Trouble Shooting PROBABLE No power to the system at all Power light don’t illuminate, fan inside power supply does not turn on. Indicator light on keyboard does not turn on PROBABLE System inoperative. Keyboard lights are on, power indicator lights are lit, hard drive is spinning.
  • Page 22: Solución De Problemas

    Solución de Problemas CAUSA PROBABLE No hay corriente en el sistema. La luz de corriente no ilumina, ventilador dentro de la fuente de alimentación apagada. Indicador de luz del teclado apagado. CAUSA PROBABLE Sistema inoperativo. Luz del teclado encendido, luz de indicador de corriente iluminado, disco rígido está...
  • Page 23 05/07/2002 MTDG-001...
