Whirlpool CEM2750KQ Parts List page 3

Commercial electric dryer
Hide thumbs

Advertisement

Illus.
Part
No.
No.
DESCRIPTION
1
Literature Parts
LIT8527795 Instructions
Installation
LIT8315969 Label, Wiring
Diagram
LIT8527791 Repair Parts List
2
357213 Nut, Push−In
3
3361029 Bracket, Control
4
8316634 Panel, Control
5
8316516 Cap, End (R.H.)
6
3949734 Cap, End (L.H.)
7
97787 Screw, 11−16 x 3/4
8
3954665 Top
9
3347825 Plate−Mounting (2)
10
98445 Screw, 10−16 x 3/4
11
8316437 Switch, Pushbutton
12
3348109 Lens Light
(Amber)
13
693995 Screw, 8−18 x 3/8
14
689559 Nut, Push−In
15
353424 Connector,
3−Circuit
16
3393918 Screw,
8−18 x 11/32
17
8281182 Screw
8−18 x 1−1/4
18
3979608 Panel, Rear
(Upper)
19
3390647 Screw, 8−18 x 1/2
20
8316640 Light, Indicator
Assembly
21
387402 Hinge (2)
22
8283165 Harness, Main
23
717252 Receptacle
(2−Way)
24
717253 Receptacle
(2−Way)
25
8316433 Pushbutton
TOP AND CONSOLE PARTS
For Model: CEM2750KQ0
Illus.
Part
No.
No.
26
8316238 Meter Case
27
3395683 Housing,
28
357572 Clip, Ground
29
3391018 Tie, Cable
30
3390646 Screw, 8−18 x 5/16
31
3406994 Case, Meter
32
351297 Plug, Harness
33
3954807 Kit, Vertical
35
3349065 Screw, 5/16−24 x 1
37
3387975 Timer,
40
3387974 3−Pin
339855 4−Pin
343777 6−Pin
41
3401682 Harness, Timer
43
3351136 Door, Service
44
3954812 Cushion, Meter
45
339805 Screw,
46
3398893 Ground Wire
47
3394427 Clip, Harness
49
90406 Nut−Cage
51
385421 Funnel, Coin
(White)
Illus.
DESCRIPTION
No.
Conversion Kit
Connector
59
60
61
Coin Slide
62
(Includes
4−Pin Cam)
Timing Cam
63
64
65
Case
66
10−32 x 3/16
67
68
69
70
3
Part
No.
DESCRIPTION
Coin Mechanism Parts, May Be
Ordered from Whirlpool Or
The Vendor(s) Listed Below.
8316526 Security Lock &
Cam Assembly
Slide &
Extension
8316521 Bolt, Slide
Mechanism
8316520 Slide Mechanism
(Vertical 8−Coin)
Inserts
(Not Shown)
8316264 Blank
8316265 25¢
8316525 Money Box W/Lock
Key (Money Box)
(When Ordering,
Specify Vendor
of Money Box Lock)
Slide Extension
Bag Assembly
Key (Service Door)
8316523 Extension
8316524 Kit, Decal
8316532 Installation
Instructions
Coin Kit
3400086 Screw, 10−32 x 3/8
GREENWALD
212 Middlesex Ave.
Chester, CT
06412−1254
1−800−221−0982
sales
@
greenwaldindustries.com
ESD
270 New Jersey Dr.
Fort Washington, PA
19034
1−800−523−1510
info
esdcoin.com
@
8527791
