- Page 1 Call Office Conveyor OWNER’S MANUAL CISSELL MANUFACTURING COMPANY HEADQUARTERS PHONE: (502) 587-1292 831 SOUTH FIRST ST. SALES FAX: (502) 585-3625 P.O. BOX 32270 SERVICE/PARTS FAX: (502) 681-1275 LOUISVILLE, KY 40232-2270 THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER. MAN 77 06/00...
-
Page 2: Safety Precautions
NOTICE THE CUSTOMER/OWNER MUST POST OPERATING INSTRUCTIONS AND SAFETY PRE- CAUTIONS IN CLOSE PROXIMITY TO THE CONVEYOR OPERATOR. SAFETY PRECAUTIONS READ THIS OWNER’S MANUAL THROUGHLY BEFORE INSTALLING, OPERATING, AND PERFORMING ANY MAINTENANCE. KEEP THIS MANUAL FOR FUTURE REFERENCE. POWER TO THE CONVEYOR MUST ALWAYS BE DISCONNECTED OR SHUT OFF PRIOR TO ATTEMPTING ANY SERVICE OR ADJUSTMENT TO THE CONVEYOR. -
Page 3: Table Of Contents
Lubricants - Worm Gear Reducers ..................11 Conveyor Track Lubrication ....................12 Idler Wheel Assembly Parts ..................... 13 Link Drive Sprocket Assembly Parts ..................14 Return End, Drive End Parts ....................15 Control Box Assembly Parts ..................... 16 Cissell Equipment Warranty ..................... 17 Page 3... -
Page 4: General Information, Damaged Goods
Claims for loss or damage to the contents must be made by the cosignee upon the carrier. Do not return damaged merchandise to Cissell. File your claim with the carrier as follows: (Claim for loss or damage is shipment cannot be filed be Cissell). -
Page 5: Assembly Instructions
Feed the links around the link drive sprocket so that the roller sleeve of each J bolt enters a tooth of the link drive sprocket. Be sure the name CISSELL on each link faces to the outside. 11. Feed the links of the last link assembly into the 180 degree track section of the return end assembly;... - Page 6 13. Level entire Conveyor by raising (or lowering) the respective vertical column in its base; or by raising (or lowering) the respective coupler (or end section) on the top of the columns. Tighten the set screws in the socket of each base. Tighten the set screws in the socket of each end section and central coupler. After alignment, pull the Conveyor links by hand, to make sure that everything is free, and that the J bolts are not hitting anything.
-
Page 7: Conveyor Order Identification System
CONVEYOR ORDER IDENTIFICATION SYSTEM NOTE: Digital Control Available Only for Fixed Link Numbering Systems. 1. OPEN BAR NUMBERING (Notches up-Smooth bar down) Each link carries a single number (1, 2, 3, 4,--etc.) and the links are numbered consecutively up to the capacity of the Conveyor. - Page 8 4. PRESELECTED NUMBERING (Notches down-Smooth bar up) This system is especially suited for self-service, and for applications having relatively uniform order sizes that will allow predetermined use of all consecutively numbered spaces of a link. The hanging bar of each link is divided into equal spaces (standare, 10 spaces per link); each space receiving a single order.
-
Page 9: Operating Instructions
OPERATING INSTRUCTIONS The standard Cissell Garment Storage and Retrieval Conveyor is factory fitted with hand and/or foot switches. An electronic automatic control is available as an option. The conveyor hand switch is of a 3-position detent design. The hand switch may be moved from the center, “OFF”... -
Page 10: Dimensions And Clearance - Garment Bag
DIMENSIONS AND CLEARANCE - GARMENT BAG Page 10... -
Page 11: Lubricants - Worm Gear Reducers
LUBRICANTS - WORM GEAR REDUCERS For special applications that involve severe ambient temperature extremes or a seasonal oil requirement, use Mobil SHC 629. Ambient Temperature -30 to 15 deg.F 16 to 50 deg.F 51 to 100 deg.F 111 to 165 deg.F Max. -
Page 12: Conveyor Track Lubrication
CONVEYOR TRACK LUBRICATION Apply Vaseline or light grease in the bottom of the roller track to lubricate the path of the rollers. A narrow strip of lubrication, about 1/8” in diameter and placed along the center of the roller path for about one foot at five foot spacings will be picked up and spread by the rollers. -
Page 13: Idler Wheel Assembly Parts
IDLER WHEEL ASSEMBLY - C301 Ref. No. Part No. Description C310 3/8”-24 Castle Nut C227 13/16” Washer C217 Ball Bearing C143 Retaining Ring C228 Sleeve Spacer C129 Bearing Housing FB124 5/16”-18 x 1 Hex Head Cap Screw C189 Idler Wheel C249 5/16”-18 Hex Nut TU2814... -
Page 14: Link Drive Sprocket Assembly Parts
LINK DRIVE SPROCKET ASSEMBLY-C300 Ref. No. Part No. Description C310 3/8”-24 Castle Nut C227 13/16” Washer C217 Ball Bearing C143 Retaining Ring C228 Sleeve Spacer C129 Bearing Housing C363 5/16”-18 x 1 1/4” Hex Head Cap Screw C1056 #40 Chain 1/2 Pitch, 56” SC400 #40 Chain 1/2 Pitch, 57”... -
Page 15: Return End, Drive End Parts
RETURN END PARTS - C649 (Consists of Ref. No. 1-11 DRIVE END PARTS - C648 (Consists of Ref. No. 4-11) Ref. No. Part No. Description TU2334 Octogon Box TU2335 Box Cover TU2878 #10 x 5/8” Sheet Metal Screw C374 #10 Wire Nut C375 3 Wire Cable (11’... -
Page 16: Control Box Assembly Parts
CONTROL BOX Ref. No. Part No. Description Ref. No. Part No. Description C1844 Control Box TU3479 #10 - 32 x 7/16” C2085 Contractor Rail Truss Screw C183 Rating Nameplate SB180 Switch Box Cover TU15138 Transformer TU7733 #8 Self-Drill Screw C1843 Control Box Cover TU3266 #8 - 32 Hex Nut... -
Page 17: Cissell Equipment Warranty
Cissell to have been defective, and in no event shall Cissell be liable for damages of any kind, whether for any injury to persons or property or for any special or consequential damages. The liability of Cissell does not include furnishing (or paying for) any labor such as that required to service, remove or install;...
