Cissell MAN65 Owner's Manual

Finishing cabinet
Hide thumbs

Advertisement

Quick Links

Download this manual
Finishing
Finishing
Finishing
Finishing
Finishing
Cabinet
Cabinet
Cabinet
Cabinet
Cabinet
Model MR3FC
Model MR3FC
Model MR3FC
Model MR3FC
Model MR3FC
OWNER'S MANUAL
OWNER'S MANUAL
OWNER'S MANUAL
OWNER'S MANUAL
OWNER'S MANUAL
CISSELL MANUFACTURING COMPANY
CISSELL MANUFACTURING COMPANY
CISSELL MANUFACTURING COMPANY
CISSELL MANUFACTURING COMPANY
CISSELL MANUFACTURING COMPANY
HEADQUARTERS
HEADQUARTERS
HEADQUARTERS
HEADQUARTERS
HEADQUARTERS
831 SOUTH FIRST ST.
P.O. BOX 32270
LOUISVILLE, KY 40232-2270
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER.
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER.
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER.
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER.
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER.
MAN65
4/05
PHONE: (502) 587-1292
SALES FAX: (502) 585-3625
SERVICE/PARTS FAX: (502) 681-1275
Page 1
Page 1
Page 1
Page 1
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MAN65 and is the answer not in the manual?

Questions and answers

Related Manuals for Cissell MAN65

Summary of Contents for Cissell MAN65

  • Page 1 Model MR3FC Model MR3FC Model MR3FC Model MR3FC Model MR3FC OWNER’S MANUAL OWNER’S MANUAL OWNER’S MANUAL OWNER’S MANUAL OWNER’S MANUAL CISSELL MANUFACTURING COMPANY CISSELL MANUFACTURING COMPANY CISSELL MANUFACTURING COMPANY CISSELL MANUFACTURING COMPANY CISSELL MANUFACTURING COMPANY HEADQUARTERS HEADQUARTERS HEADQUARTERS HEADQUARTERS HEADQUARTERS PHONE: (502) 587-1292 831 SOUTH FIRST ST.

  • Page 2: Warranty

    Cissell's factory, transportation prepaid, within the applicable warranty period and found by Cissell to have been defective, and in no event shall Cissell be liable for damages of any kind, whether for any injury to persons or property or for any special or consequential damages.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS Warranty ................2 Specifications ............... 3 Steam Piping Recommendations ......... 4-5 Operating Instructions ............6 Trouble Shooting Chart ............7 Parts Sheets ............... 8-13 MR3FC FINISHING CABINET MR3FC FINISHING CABINET MR3FC FINISHING CABINET MR3FC FINISHING CABINET...

  • Page 4: Steam Piping Recommendations

    STEAM PIPING RECOMMENDATIONS STEAM PIPING RECOMMENDATIONS STEAM PIPING RECOMMENDATIONS STEAM PIPING RECOMMENDATIONS STEAM PIPING RECOMMENDATIONS IMPORTANT: INSTALL STEAM PIPING IN ACCORDANCE WITH ALL LOCAL REGULATIONS AND REQUIREMENTS. 1. Set and level Cabinet in position. Machine should be level to assure proper steam and circulation.
  • Page 5 Page 5 Page 5 Page 5 Page 5 Page 5...

  • Page 6: Operating Instructions

    INSTRUCTIONS OPERATING OPERATING INSTRUCTIONS INSTRUCTIONS FOR CISSELL MOIST-RITE CABINETS AND TUNNELS FOR CISSELL MOIST-RITE CABINETS AND TUNNELS FOR CISSELL MOIST-RITE CABINETS AND TUNNELS FOR CISSELL MOIST-RITE CABINETS AND TUNNELS FOR CISSELL MOIST-RITE CABINETS AND TUNNELS Forward - The Moist-Rite Finishing Cabinets and Finishing Tunnels are designed to restore the finish on most garments.

  • Page 7: Trouble Shooting Chart

    P R O B L E M P R O B L E M C A U S E C A U S E R E M E D Y R E M E D Y P R O B L E M P R O B L E M P R O B L E M C A U S E...

  • Page 8: Parts Sheets

    Page 8 Page 8 Page 8 Page 8 Page 8...
  • Page 9 Blower Wheel SC555 Door Stop SC554 Seal Bracket SC553 Lower Door Seal SC503 Control Panel Cover TUB1867 Lock & Key FB405 Cissell Nameplate SC486 Roller Carriage Rod FG444 Yoke SF48 Clevis Pin SC484 Roller Carriage Stop SC478 Hanger Bar Support SC482...
  • Page 10 Page 10 Page 10 Page 10 Page 10 Page 10...
  • Page 11 Ref. Ref. Ref. Ref. Ref. P a r t P a r t P a r t P a r t P a r t Description Description Description Description Description SC552 Coil Hold Down Bracket SC158 Cross Over Tube Assembly SC611 Steam Jet Bracket SC108...
  • Page 12 CONTROL PANEL ASSEMBLY CONTROL PANEL ASSEMBLY CONTROL PANEL ASSEMBLY CONTROL PANEL ASSEMBLY CONTROL PANEL ASSEMBLY SC876 - Control Panel - 120 V., 60 Hz. SC877 - Control Panel - 240 V., 50/60 Hz. Ref. Ref. Ref. Ref. Ref. P a r t P a r t P a r t P a r t...
  • Page 13 SAFETY GRID (Optional on 120V) SAFETY GRID (Optional on 120V) SAFETY GRID (Optional on 120V) SAFETY GRID (Optional on 120V) SAFETY GRID (Optional on 120V) Ref. Ref. P a r t P a r t Ref. Ref. Ref. P a r t P a r t P a r t Description...

This manual is also suitable for:

Mr3fc
