OWNER'S MANUAL
110 lb. HD LAUNDRY DRYER
HD110
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER
MAN HD2110 4/06
Gas: Natural and LP
Steam
Electric
Cissell Manufacturing Co.
831 S. First St. - P.O.Box 32270 - Louisville, Ky. - 40232-2270
Tel: (502) 587-1292 - Fax: (502) 585-2333 -
Sales Fax: (502) 585-3625 - Service/Parts Fax: (502) 681-1275
Technical specifications
Installation instructions
Operating instructions
Maintenance

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDMAN2110 and is the answer not in the manual?

Questions and answers

Related Manuals for Cissell HDMAN2110

Summary of Contents for Cissell HDMAN2110

  • Page 1: Model Numbers & Company Address

    Technical specifications Installation instructions Operating instructions Maintenance Cissell Manufacturing Co. HD110 831 S. First St. - P.O.Box 32270 - Louisville, Ky. - 40232-2270 Tel: (502) 587-1292 - Fax: (502) 585-2333 - Sales Fax: (502) 585-3625 - Service/Parts Fax: (502) 681-1275...

  • Page 2: Important Notices

    IMPORTANT NOTES - PLEASE READ For optimum efficiency and safety, we recommend that you read the manual before operating the equipment. Store this manual in a file or binder and keep for future reference. WARNING: Purchaser must post the following notice in a prominent location: WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or death.
  • Page 3 IMPORTANT NOTES - PLEASE READ WARNING: To avoid fire hazard, do not dry articles containing foam rubber or similar texture materials. Do not put into this dryer flammable items such as baby bed mattresses, throw rugs, undergarments (brassieres, etc.) and other items which use rubber as padding or backing. Rubber easily oxidizes causing excessive heat and possible fire.
  • Page 4 IMPORTANT NOTES - PLEASE READ ATTENTION: L’ACHETEUR DOIT PLACER L’AVERTISSEMENT SUIVANT DANS UN ENDROIT CLAIR ET VISIBLE: AVERTISSEMENT. Assurez-vous de bien suivre les instructions donnees dans cette notice pour reduire au minimum le risque d’incendie ou d’explosion ou pour eviter tuot dommage materiel, toute blessure ou la mort.

  • Page 5: Dryer Warranty

    Cissell’s factory, transportation prepaid, within the applicable warranty period and found by Cissell to have been defective, and in no event shall Cissell be liable for damages of any kind, whether for any injury to persons or property or for any special or consequential damages.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS PAGE Model Numbers & Company Address .................. 1 Important Notices ......................2-4 Dryer Warranty ........................5 Table of Contents ......................6-7 Warnings, Symbols ......................8-9 Unpacking/General Installation .................... 10 General Dimensions ....................... 11-13 Dryer Specifications ....................... 14-15 Electrical Connections ......................

  • Page 7: Table Of Contents

    TABLE OF CONTENTS Two Timer Control Panel Assembly ..................64 DMP Control Panel Assembly .................... 65 Pro Control Panel Assembly ....................66 ProHC Control Panel Assembly ..................67 Rear Motor Control Assembly .................... 68 Parts - TM200 Gear Reducer ..................... 69 Gas Bonnet Assembly ......................

  • Page 8: Warnings, Symbols

    SYMBOLS The following symbols are used in this manual and/or on the machine. Symbol Description NOTE! Hot! Do Not Touch Heiß! Nicht Beruhren Haute temperature! Ne pas toucher Caliente! no tocar dangerous voltage tension dangereuse Gefährliche elektrische Spannung tension peligrosa marche conectado arrêt...
  • Page 9 SYMBOLS Description Symbol rotation in two directions rotation dans les deux sens Drehbewigung in zwei Richtungen movimiento rotativo en los dos sentidos direction of rotation sens de mouvement continu de rotation Drehbewegung in Pfeilrichtung movimiento giratorio o rotatorio en el sentido de la flecha End of Cycle caution attention...

  • Page 10: Unpacking/General Installation

    UNPACKING/GENERAL INSTALLATION (ALL DRYERS) UNPACKING This dryer is packed in a large wooden crate. Upon arrival of the equipment, any damage in shipment should be reported to the carrier immediately. Upon locating permanent location of a unit, care should be taken in movement and placement of equipment.

  • Page 11: General Dimensions

    GENERAL DIMENSIONS - GAS DRYERS ALL DIMENSIONS ARE +/- 1/4” (6.4 MM) AND ARE SUBJECT TO CHANGE WITHOUT NOTICE Page 11...
  • Page 12 DRYER DIMENSIONS - STEAM MODEL ALL DIMENSIONS ARE +/- 1/4” (6.4 MM) AND ARE SUBJECT TO CHANGE WITHOUT NOTICE Page 12...
  • Page 13 DRYER DIMENSIONS - ELECTRIC MODEL ALL DIMENSIONS ARE +/- 1/4” (6.4 MM) AND ARE SUBJECT TO CHANGE WITHOUT NOTICE Page 13...

  • Page 14: Dryer Specifications

    SPECIFICATIONS Floor Space GENERAL Gas ............67” Deep x 47” W x 89-1/8” H SPECIFICATIONS FOR (1702 mm x 1194 mm x 2264 mm) 110 lb. DRYERS Steam ............67” Deep x 47” W x 93-3/4” H (1702 mm x 1194 mm x 2382 mm) Door Opening ..........31-1/4”...
  • Page 15 SPECIFICATIONS STEAM HEATED DRYERS Operating Steam Pressure ......100 PSIG (6.9 bar) Max. ONLY Boiler HP (w/normal ld.) (14FPI) ...10.4 (7.76 kW) (4-Coil) .............7.87 (5.88 kW) (6-Coil) .............9.5 (5.88 kW) Steam Coils ..........(2) 40-1/2”L x 15-3/4”H x 6”W (2) (1029 mm x 401 mm x 153 mm) Traps for Steam Heating Coils ....3/4”...

  • Page 16: Electrical Connections

    ELECTRICAL CONNECTIONS (WITH GROUNDING INSTRUCTIONS Dryers must be electrically grounded by a separate #14 or larger ELECTRICAL green wire from the grounding terminal within the service connection CONNECTIONS box, to a cold water pipe. In all cases, the grounding method must FOR ALL DRYERS comply with local electrical code requirements;...

  • Page 17: Gas Piping

    GAS PIPING The size of the gas service pipe is dependant upon many variables, GAS SERVICE such as tees, lengths, etc. Specific pipe size should be obtained from INSTALLATION the gas supplier. Refer to the Gas Pipe Size Chart in this manual for INFORMATION general gas pipe size information.

  • Page 18: Gas Piping

    GAS PIPING Page 18...

  • Page 19: Gas Pipe Size Chart

    GAS PIPE SIZE CHART TOTAL BTU/HR GAS PIPE SIZE FOR 1000 BTU (250 KCAL) NATURAL GAS (for LP Gas correct AT 7” W.C. (17.5 MBAR) PRESSURE TOTAL total BTU/HR below by KCAL multiplying by .6) In figuring total length of pipe, make allowance for tees and elbows. (25 ft.) (50 ft.) (75 ft.)

  • Page 20: Gas Piping Installation

    GAS PIPING INSTALLATION 1. The installation must conform to local codes or in absence of GAS PIPING local codes, with the National Fuel Gas Code, ANSI Z223.1 INSTALLATION or the CAN/CGA-B149, Installation Codes. 2. Check with utilities for proper gas pressure and gas supply line.

  • Page 21: Steam Piping Installation

    STEAM PIPING INSTALLATION 1. Set and anchor dryer in position. Machine should be level to INSTALLATION assure proper steam circulation. INSTRUCTIONS 2. To prevent condensate draining from headers to dryer, piping should have a minimum 12” (305 mm) above respective header.

  • Page 22: Steam Piping Installation

    STEAM PIPING INSTALLATION (ILLUSTRATION) Page 22...

  • Page 23: Exhaust Installation-Multiple Exhaust

    EXHAUST INSTALLATION—MULTIPLE EXHAUST For Exhaust Duct less than 14 feet and 2 elbows equivalent and less than 0.6 inches static pressure. DRYER EXHAUSTS Area of section "A-A" must be equal to the sum of dryer exhaust pipes entering muliple exhaust pipe. (See chart below.) MODELS: HD20, HD30, HD30SL, HD30ST, HD50, &...
  • Page 24 DRYER INSTALLATION WITH MULTIPLE EXHAUST (ILLUSTRATION) Page 24...

  • Page 25: Dryer Installation With Multiple Exhaust

    DRYER INSTALLATION WITH MULTIPLE EXHAUST For Exhaust Duct more than 14 feet (5 m) and 2 elbows equivalent EXHAUST and more than 0.3 inches (8 mm) static pressure. INSTALLATION— MULTIPLE MANIFOLD 1. Make-up air from outside building may enter enclosure from top or side walls.

  • Page 26: Dryer Make-Up Air Requirements

    RECOMENDED MINIMUM DRYER MAKE-UP AIR REQUIREMENTS Dryer Dryer Pocket Maximum Air Flow Duct Size For Required Make-up Model Capacity Rate per Pocket Service Connection Air Area per Pocket m3/h inch sq. inch cm2 HD20.1 HD30SL 13.6 1020 HD30.1 13.6 1063 HD30ST 13.6 HD50.1...

  • Page 27: Exhaust Installation - Separate Exhaust

    DRYER INSTALLATION WITH SEPARATE EXHAUST (PREFERRED) DRYER INSTALLATION WITH SEPARATE EXHAUST DRYER INSTALLATION (PREFERRED) WITH SEPARATE EXHAUST (PREFERRED) For Exhaust Duct less than 14 feet (5 m) and 2 elbows equivalent and less than 0.3 (8 mm) inches static pressure. NEVER exhaust the dryer into a chimney.

  • Page 28: Dryer Air Flow Installation

    DRYER AIR FLOW INSTALLATION Nothing is more important than air flow for the proper operation of a clothes dryer. A dryer is DRYER AIR FLOW a pump which draws make-up air from the out-of-doors, through the heater, through the INSTALLATION clothes and then forces the air through the exhaust duct back to the out-of-doors.

  • Page 29: Rules For Safe Operation Of Dryer

    RULES FOR SAFE OPERATION OF DRYER 1. Be sure your dryer is installed properly in accordance with the RULES FOR SAFE recommended instructions. OPERATION OF DRYER 2. CAUTION Be safe—shut main electrical power supply and gas supply off externally before attempting service. 3.

  • Page 30: Energy Saving Tips

    ENERGY SAVING TIPS Install dryer so that you can use short, straight venting. ENERGY SAVING TIPS Turned elbows and long vent tubing tend to increase drying time. Longer drying time means the use of more energy and higher operating costs. Operate dryer using full-size loads.

  • Page 31: Operating Instructions-Two Timer Models

    OPERATING INSTRUCTIONS—TWO TIMER MODELS Page 31...
  • Page 32 OPERATING INSTRUCTIONS—TWO TIMER MODELS OPERATING INSTRUCTIONS—TWO TIMER MODELS OPERATING INSTRUCTIONS—TWO 1. After loading the dryer with the water washed clothes load, TIMER MODELS close the loading door. For better drying, do not load dryer with combination of garments that twist. 2.

  • Page 33: Operating Instructions -Two Timer Models

    OPERATING INSTRUCTIONS—TWO TIMER MODELS OPERATING INSTRUCTIONS—TWO TIMER MODELS OPERATING (continued) INSTRUCTIONS—TWO TIMER MODELS What is happening to the drying operation: a. The fan motor will operate. b. The basket will rotate. c. The heat source will be energized. d. The heated air will mix with the water washed clothes to evaporate the moisture from the garments.

  • Page 34: Service Savers

    SERVICE SAVERS To help you troubleshoot the dryer, listed below are the most TROUBLESHOOTING common reasons for service calls and some answers to the problems. Before you call service, please review the following items: 1. Is the door completely closed? DRYER WON’T START 2.

  • Page 35: Troubleshooting Chart

    TROUBLESHOOTING CHART TROUBLE CAUSE REMEDY Motor will not start. No power. Check fuses on circuit breakers. Make sure main control switch is ON. Incorrect power. Check power source; voltage, phase and frequency must be the same as specified on electrical rating plate. Time off.
  • Page 36 TROUBLESHOOTING CHART TROUBLE CAUSE REMEDY Dryer runs, but no heat. Incorrect voltage. Check for correct control voltage - 24V. No voltage. Check power supply, check secondary voltage on trans- former and check wiring and wiring diagram. Lint Door open. Close lint door. Defective gas valve.
  • Page 37 TROUBLESHOOTING CHART TROUBLE CAUSE REMEDY Main burners burning Dirt in burner. Blow out. improperly. High gas pressure. Adjust gas pressure per rating plate. Orifice too large. Send to factory for correct orifices. Restricted or blocked Clean exhaust. exhaust. Main burner cycles on and Defective ground.

  • Page 38: Direct-Spark Ignition Operation

    DIRECT-SPARK IGNITION OPERATION NOTE: Some models are equipped with a dual ignition system. DIRECT SPARK The dual ignition system contains two Direct Spark IGNITION Ignition modules in parallel. Each module has its own OPERATION Flame Sense circuit and acts independently of the other. If either Bonnet Limit Thermostat opens because of high heat or flame impingement, the entire ignition system will shut down.
  • Page 39 DIRECT SPARK IGNITION OPERATION FLOW CHART Page 39...

  • Page 40: General Maintenance

    MAINTENANCE—GENERAL DAILY CLEAN LINT TRAP DAILY. Remove lint before starting day’s operation. A clean lint trap will increase the efficiency of the dryer, as the moisture-laden air will be exhausted more quickly. DRYER AREA. Keep dryer area clean and free from combustible materials, gasoline and other flammable vapors and liquids.

  • Page 41: Burner Air Inlet Adjustment

    BURNER AIR INLET ADJUSTMENT BURNER AIR INLET ADJUSTMENT Page 41...

  • Page 42: Basket Alignment (Tm200 Gear Reducer)

    BASKET ALIGNMENT FOR DRYERS WITH TM200 GEAR REDUCER Page 42...
  • Page 43 BASKET ALIGNMENT FOR DRYERS WITH TM200 GEAR REDUCER INSTRUCTIONS INSTRUCTIONS FOR ALIGNING BASKETS ON 1. Loosen bolts number one (1) through five (5). 110 LB. DRYERS 2. Place pin “A” in position shown in figures 1 and 2. 3. Check pins “B” at position shown in figures 1 and 2 for equal clearance.

  • Page 44: Basket Alignment (Gear Motor)

    BASKET ALIGNMENT FOR DRYERS WITH GEAR MOTOR Jacket Rear View BASKET TOO LOW If there are shims under Bearing B; 1. Loosen bolts 2. Remove shim(s). 3. Tighten bolts - check alignment. If there are no shims under B; 1. Loosen bolts on bearing A. 2.

  • Page 45: Shimming The Basket And Spider Assembly

    SHIMMING THE BASKET AND SPIDER ASSEMBLY This procedure is normally necessary when replacing either the INSTRUCTIONS FOR basket or the spider assembly on any dryer. The alignment of these SHIMMING THE BASKET two parts are crucial in assuring a true running basket. AND SPIDER ASSEMBLY A.

  • Page 46: Air Switch Adjustment

    AIR SWITCH ADJUSTMENT AIR SWITCH 1. Shut off current; disconnect leads and remove air switch. 2. Lay air switch assembly on flat surface. Adjust air blade at ADJUSTMENT “A” (figure 1) so that air blade lays flat and surface “B” is parallel to the flat surface.

  • Page 47: Dryers With Reversing Control Timer

    DRYERS WITH REVERSING CONTROL TIMER INSTRUCTIONS FOR Instructions In operation, coasting of basket increases, making it necessary to DRYERS WITH readjust reversing timer. REVERSING CONTROL TIMER CAUTION Failure to do this will cause the thermal overload units for the basket to cut-out unnecessarily and probably damage the gear reducer.
  • Page 48 DRYERS WITH REVERSING CONTROL Instructions INSTRUCTIONS FOR DRYERS WITHOUT NOTE REVERSING CONTROL Fan rotates counter-clockwise as viewed from back end of FAN AND BASKET motor. See arrow on motor support. ROTATION Basket rotates counter-clockwise as viewed from back end of motor. See arrow on motor support.

  • Page 49: Large Gear Reducer Maintenance

    LARGE GEAR REDUCER MAINTENANCE LARGE GEAR LARGE GEAR REDUCER MAINTENANCE REDUCER Before placing the dryer in operation, check the oil level. If the oil MAINTENANCE level is correct, it can be checked by removing the fill overflow plug on the right hand side of the gear reducer (facing rear). If oil must be added, remove the pop-off valve at the top of the gear reducer and add as needed.

  • Page 50: Front Exploded View

    FRONT VIEW Ref. Part No. Description TU5803 Basket and Spider Assembly (Galvanized) (TM200 Gear Reducer) TUS5803 Basket and Spider Asembly (Stainless Steel) (TM200 Gear Reducer) TU16028 Basket and Spider Assembly (Galvanized) (Gear Motor) TUS16028 Basket and Spider Asembly (Stainless Steel) (Gear Motor) TU6469 Basket, without Spider (Galvanized) TUS6469...

  • Page 51: Rear View (Tm200 Gear Reducer)

    REAR VIEW (TM200 GEAR REDUCER) 60 Cycle Fan Assembly 50 Cycle Fan Assembly See following page for part numbers. Page 51...
  • Page 52 REAR VIEW PARTS (TM200 GEAR REDUCER) TU4934 1/4” - 20 x 7/16” Hex Nut (Pkg. of 6) TU3575 7/8” Internal Tooth Lockwasher FB189 1/4” - 20 x 1” Hex Head Screw TU5312 3/8” - 16 x 3” Square Head Set Screw CFB3000 1/2”...
  • Page 53 REAR VEIW ( GEAR MOTOR) 60 Cycle Fan Assembly 50 Cycle Fan Assembly See following page for part numbers. Page 53...

  • Page 54: Rear View (Gear Motor)

    REAR VIEW PARTS (GEAR MOTOR) SB-00837-0 Screw, #10 TU2814 5/16” Split Lockwasher (Pkg. of 6) TU16016 Bearing, Pillow Block, 2” C249 5/16” - 18 Hex Nut (Pkg. of 6) TU16030 Screw, 5/8-11 x 2 -3/4 lg. TU2831 3/8” Split Lockwasher (Pkg. of 6) TUX329 Washer, Flat, 5/8”...

  • Page 55: Front Panel And Door Assembly

    FRONT PANEL ASSEMBLY * Cover plate used for DMP, PRO, and PRO HC dryers. Ref. Ref. Part No. Description Part No. Description TU15454WHT Front panel assembly, complete (Excludes cover plate). ESA-00862-0 Reed Switch Assembly TU3785 #8 E.T. Cup washer SB-00975-0 #6-32 Screw TU5503 Door latch spacer...

  • Page 56: Two Timer Thermostat Assembly

    THERMOSTAT ASSEMBLY - 2 TIMER Ref. Part No. Description TU6030 Assembly, Thermostat TU5530 Mounting Bracket TU1980 Thermostat TU3593 Thermometer TU3816 Lens Replacement (Texas Gage ONLY) TU8475 Lens Replacement (Marshaltown Inst. ONLY) TU11193 Lens Replacement (Weiss—consult factory) TU13213 Lens Replacement (Weiss—consult factory) TU490 Thermostat Knob (Fahrenheit) TU491...

  • Page 57: Burner Access Door

    TU14631 - Burner Access Door complete (Specify color) CA-13098-0 Gasket, DR dryer control doors SB-00951-0 Screw,#8 X 7/16" Philips F.H. TU14629 Asm, 125# Access door weld (Specify color) TU14630 Trim, 125# Burner access door TU14662 Logo, Cissell TU5739 Rod, support arm Page 57...

  • Page 58: Lint Door Assembly

    LINT DOOR ASSEMBLY Ref. Part No. Description TU14638 - Lint Door Complete (Specify color) LA-00123-0 Latch SB-00836-0 Screw, Pancake SB-00949-0 Fastener, kickplate TU14594Label, English TU15410Label, 5 Language TU14635Lint dr. weld asm. (Specify color). TU14636Handle TU14637Trim TU14639Kickplate Page 58...

  • Page 59: Dmp Sensor Assembly

    DMP SENSOR ASSEMBLY Ref. Part No. Description TU15538 DMP Thermostat Assembly TU15537 Bracket EA-00411-0 Switch - 220 degrees TU11991 Thermistor M262 Screw, #8-32 TU3266 Nut, hex brass #8-32 TU3624 Screw, #6-32 TU3400 Nut, hex brass #6-32 Page 59...

  • Page 60: Two Timer Sensor Assembly

    2 TIMER SENSOR ASSEMBLY Ref. Part No. Description TU6029 - Thermostat Assembly TU2477 Thermostat #AR594 TU2486 Bracket TU3801 Nut, speed #C18784-010-4 Page 60...

  • Page 61: Pro Sensor Assembly

    PRO SENSOR ASSEMBLY Ref. Part No. Description ESA-00940-0 Sensor Assembly 254/00009/10 Thermistor CA-23067-0 Thermostat EA-00411-0 Switch, 220 Degrees SB-00828-0 Screw, Mach. P.H. #8-32 X 1/2 SB-00952-0 Screw, P.H. #6-32 x 3/8 TU3266 Nut, Hex #8-32 TU3400 Nut, Hex #6-32 Page 61...

  • Page 62: Prohc Sensor Assembly

    PROHC SENSOR ASSEMBLY - UPPER and LOWER Ref. Part No. Description TU14724 PROHC Sensor assembly (upper) SB-00952-0 Screw, #6-32x 3/8” long TU14693 Mounting plate upper probe TU14694 Cover plate, probe TU3400 Nut, #6-32 TU7733 Screw, self drill #8-18x 1/2” long 254/00060/00 Humidity sensor UPPER ASSEMBLY...

  • Page 63: Air Switch Assembly

    AIR SWITCH ASSEMBLY Ref. Part No. Description TU8206 Assembly, Air Switch F888 E-Ring TU1770 Insulator TU1771 Tinnerman Nut, #6 TU2463 Actuator Arm TU3219 Screw, #6 TU3476 Decal TU7733 Screw, #8 TU8155 Micro Switch TU8171 Bracket Assembly Page 63...

  • Page 64: Two Timer Control Panel Assembly

    2 TIMER CONTROL PANEL ASSEMBLY Ref. Part Ref. Part Description Description ET208 #6-32 x 1/4” Binding Hd Screw TU15406WHT Panel W/A F1300 24V Relay TU2555 Knob Assembly FG147 Toggle Switch TU3805 #15-32 Hex Nut TU12874 Reversing Board TU7733 #8-18 x 1/2” Self Drilling Screw TU12932 Timer (0-60 Minutes) TU8629...

  • Page 65: Dmp Control Panel Assembly

    DMP CONTROL PANEL ASSEMBLY Part No. Description TU14469WHT DMP Control Panel Welded Assembly TU15184 Opl Dmp, Rt-Side (Dn) Overlay TU14137 Buzzer, 24V TU14435 Emergency Stop (50 Hz) TU15724 7/8” Button Plug (60 Hz) TU3400 #6-32 Hex Nut TU14404 Controller Opl/Coin Board, New M270 #6 Int Tooth Lock Washer Page 65...

  • Page 66: Pro Control Panel Assembly

    PRO CONTROL PANEL ASSEMBLY Ref. Part No. Description 254/00039/00 Overlay 254/00070/00 Pro Control M261 #8-32 Screw M270 Lockwasher TU14435 Emergency Stop (50 Hz) TU15724 7/8” Button Plug (60 Hz) TU14442WHT Control Panel Welded Assembly TU14701 Spacer TU14727WHT Cover TU3400 #6-32 Nut TU15899 Pro / ProHC EPROM Chip (Standard program) Page 66...

  • Page 67: Prohc Control Panel Assembly

    PROHC CONTROL PANEL Ref. Part No. Description 254/00018/00 Overlay 254/00070/00 ProHC Control M261 #8-32 Screw M270 Lock Washer TU14435 Emergency Stop (50 Hz) TU15724 7/8” Button Plug (60 Hz) TU14442WHT Control Panel W/A TU14701 Spacer TU14727WHT Cover TU3400 #6-32 Nut TU15899 Pro / ProHC EPROM Chip (Standard program) Page 67...

  • Page 68: Rear Motor Control Assembly

    REAR MOTOR CONTROL ASSEMBLY Ref. Part No. Description TU13700 Plate, Motor Control TU13802 Transformer, 115/208/230 75VA TU13514 Transformer, 60VA 460V/24V 60VA TU13642 Transformer, 60VA 575V/24V 60VA TU2973 Screw, #8 TU13516 Contactor, 24VAC IEC 12A W/AUX TU7733 Screw, #8 self drilling EA-00685-0 Reversing Contactor, 3 POLE/24V COIL/12A TU16101...

  • Page 69: Parts - Tm200 Gear Reducer

    TM204 Small Klozure TM211 Large End Cap 10 1/2 Dia. TM212 Small End Cap 6 3/4 Dia. TM225 Worm and Worm Gear Set (for TM200 ONLY) (only sold as set) Not Illustrated—TU3465 one pint of Cissell Transmission Oil Page 69...

  • Page 70: Gas Bonnet Assembly

    GAS BONNET ASSEMBLY PART DESCRIPTION PART DESCRIPTION NO.. TU9614 Gas Manifold TU4606 3/4” x 4” Nipple CB36 1/4” - 20 x 1/2” Hex Head TU4934 1/4” - 20 Hex Nut (Pkg 6) Screw TU13823 3/4” x 36” Nipple OP267 3/4” x 1/2” Steel Bushing TU3539 Burner Orifice PT196...

  • Page 71: Steam Bonnet Assembly (4 Coil) - Tu13691

    STEAM BONNET (4 COIL) 24V - TU13691 PART DESCRIPTION PART DESCRIPTION NO.. TU7393 Top Plate TU4605 3/4” Elbow TU3209 #14 x 5/8” Sheet Metal Screw TU4608 3/4” x 2” Nipple TU6458 Air Filter TU4610 3/4” x 5” Nipple (3 each) TU1699 Steam Coil (4 Coil) (2 each) TU4600...

  • Page 72: Steam Bonnet Assembly (6 Coil) - Tu13692

    STEAM BONNET (6 COIL) 24V - TU13692 PART DESCRIPTION PART DESCRIPTION NO.. TU7393 Top Plate TU4605 3/4” Elbow TU3209 #14 x 5/8” Sheet Metal Screw TU4608 3/4” x 2” Nipple (3 each) (Pkg. of 6) (4 each) TU4610 3/4” x 5” Nipple TU6080 Air Filter (4 required) TU4600...

  • Page 73: Electric Bonnet Assembly

    ELECTRIC BONNET PART DESCRIPTION TU11785 Bonnet Weldment TU7113 Top Weldment TU9908 Terminal Cover TU9909 Rear Cover TU7119 Front Cover TU5958 Bushing TU7089 Thermostat (300° F) TU2793 #8 x 5/8" Screw (Pkg. of 6) TU7733 #8 x 1/2" Screw (Pkg. of 6) CFB1500 1/2"...

  • Page 74: Electric Bonnet - Heating Elements, Fuses, Etc

    ELECTRIC BONNET - ELEMENTS, FUSES, ETC. e z i e r i ° 5 c r i t i u l a t t a l . e z a t l . s l Page 74...
  • Page 75 Page 75...
