FO R UM SP E AKE R SP E C I F I C AT I ON S
Power Handling:
Continuous
Program
Peak
Frequency Response:
(-10dB)
Frequency Response:
(+/-3dB)
Sensitivity (@2.83V):
Max SPL:
Coverage (H x V):
Directivity:
Impedance:
Regulatory Approvals:
(9UL, CE)
Transducers:
LF Driver Size
HF Driver Size
Crossover Frequency:
Enclosure Material:
Connector Type:
Dimensions:
(H x W x D)
Net Weight:
* Features, details & specifications are subject to change without notice

FORUM 8
100W
200W
400W
60Hz−20kHz 55Hz−20kHz
90Hz−20kHz 90Hz−20kHz
90dB/1watt/1meter 92dB/1watt/1meter
116dB
70˚ Conical
6.69
8Ω nominal
CE
8" Coaxial
2" Compression Driver 2" Compression Driver
2.3kHz
MDF
Speakon™/Terminal strip Speakon™/Terminal strip
370 x 285 x 280mm 430 x 322 x 320mm
14.6" x 11.2" x 11" 17" x 12.7" x 12.6"
11.2kg
24.6lbs.
FORUM 10 FORUM 12
150W 200W
300W 400W
600W 800W
60Hz−20kHz
90Hz−20kHz
94dB/1watt/1meter
120dB 123dB
55˚ Conical 60˚ Conical
7.15 7.21
8Ω nominal 8Ω nominal
CE
10" Coaxial 12" Coaxial
2" Compression Driver
2.2kHz 2.0kHz
MDF MDF
Speakon™/Terminal strip
508 x 375 x 350mm
20" x 14.8" x 13.8"
15kg 17.6kg
33lbs. 38.7lbs.
FORUM 15
300W
600W
1200W
60Hz−20kHz
70Hz−20kHz
95dB/1watt/1meter
126dB
65˚ Conical
7.1
8Ω nominal
CE CE
15" Coaxial
2" Compression Driver
2.1kHz
MDF
Speakon™/Terminal strip
558 x 449 x 430mm
22" x 17.7" x 17"
23.5kg
52lbs.
