Intel ® 945P Express Chipset; Graphics Subsystem; Audio Subsystem - Intel D945PWM Product Manual

®
Intel 945P Express Chipset
The Intel 945P Express Chipset consists of the following devices:
•
Intel 82945P Memory Controller Hub (MCH) with Digital Media Interface
•
Intel 82801GB I/O Controller Hub (ICH7)
•
Serial Peripheral Interface (SPI) Flash or Firmware Hub (FWH)
Related Link:
Go to the following link for more information about the Intel 945P Express Chipset:
http://developer.intel.com/design/nav/pcserver.htm

Graphics Subsystem

Desktop Board D945PWM includes the following:
•
Intel 945P Express Chipset
•
PCI Express x16 connector for graphics expansion

Audio Subsystem

Desktop Board D945PWM includes a flexible 6-channel audio subsystem based on an Intel High
Definition Audio codec:
The audio subsystem features:
•
Intel 82801GB I/O Controller Hub (ICH7)
•
SigmaTel STAC9220 audio codec
•
Impedance sensing capability for jack re-tasking
•
S/N (signal-to-noise) ratio: 95 dB
•
Microphone input that supports:
⎯ Stereo microphone
⎯ Microphone boost
The subsystem includes the following connectors:
•
Front panel audio connector, including functionality for:
⎯ Line out
⎯ Mic in
•
Back panel audio connectors that are configurable through the drivers of the audio devices:
⎯ Line in
⎯ Line out
⎯ Mic in
⎯ Center/LFE out
⎯ Rear left and right out
Desktop Board Features
