  • Page 1   Dolby DP600 Program ® Optimizer Manual Issue 4 Part Number 91963...
  • Page 2: Corporate Headquarters

    Wootton Bassett Wiltshire SN4 8QJ England Telephone 44‐1793‐842100 Fax 44‐1793‐842101 DISCLAIMER OF WARRANTIES: EQUIPMENT MANUFACTURED BY DOLBY LABORATORIES IS WARRANTED AGAINST DEFECTS  IN MATERIALS AND WORKMANSHIP FOR A PERIOD OF ONE YEAR FROM THE DATE OF  PURCHASE. THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES AND NO WARRANTY  OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR OF NONINFRINGEMENT  OF THIRD‐PARTY RIGHTS (INCLUDING, BUT NOT LIMITED TO, COPYRIGHT AND PATENT  RIGHTS). LIMITATION OF LIABILITY:  IT IS UNDERSTOOD AND AGREED THAT DOLBY LABORATORIES’ LIABILITY, WHETHER IN  CONTRACT, IN TORT, UNDER ANY WARRANTY, IN NEGLIGENCE, OR OTHERWISE, SHALL NOT  EXCEED THE COST OF REPAIR OR REPLACEMENT OF THE DEFECTIVE COMPONENTS OR  ACCUSED INFRINGING DEVICES, AND UNDER NO CIRCUMSTANCES SHALL DOLBY  LABORATORIES BE LIABLE FOR INCIDENTAL, SPECIAL, DIRECT, INDIRECT, OR  CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, DAMAGE TO SOFTWARE OR  RECORDED AUDIO OR VISUAL MATERIAL), COST OF DEFENSE, OR LOSS OF USE, REVENUE, OR  PROFIT, EVEN IF DOLBY LABORATORIES OR ITS AGENTS HAVE BEEN ADVISED, ORALLY OR IN  WRITING, OF THE POSSIBILITY OF SUCH DAMAGES. .  Dolby, Pro Logic, and the double‐D symbol are registered trademarks of Dolby Laboratories.  Dialogue Intelligence is a trademark of Dolby Laboratories. All other trademarks remain the property of their respective owners. © 2009 Dolby Laboratories. All rights reserved. Dolby Laboratories, Inc. Part Number 91963 S09/20700/21461 ® Dolby DP600 Program Optimizer Manual Issue 4...
  • Page 3: Important Safety Instructions

    Regulatory Notices NOTE: This equipment has been tested and found to comply with the limits for a Class A  digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide  reasonable protection against harmful interference when the equipment is operated in a  commercial environment. This equipment generates, uses, and can radiate radio frequency  energy and, if not installed and used in accordance with this instruction manual, may cause  harmful interference to radio communications. Operation of this equipment in a residential  area is likely to cause harmful interference in which case the user will be required to correct  the interference at his own expense. Canada This Class A digital apparatus complies with Canadian ICES‐003. EU/EMC This is a class A product. In a domestic environment this product may cause radio  interference in which case the user may be required to take adequate measures. Important Safety Instructions 1. CAUTION: Troubleshooting must be performed by a trained technician. To reduce the  risk of electric shock, do not attempt to service this equipment unless you are  qualified to do so. 2. Do not defeat the safety purpose of the polarized or grounding‐type plug. A polarized  plug has two blades with one wider than the other. A grounding‐type plug has two  blades and a third grounding prong. The wide blade or the third prong is provided  for your safety. If the provided plug does not fit into your outlet, consult an electrician  for replacement of the obsolete outlet. 3. This apparatus must be earthed (grounded) by connecting to a correctly wired and  earthed power outlet. 4. Ensure that your mains supply is in the correct range for the input power requirement  of the unit. 5. In order to reduce the risk of electrical shock, the power cord must be disconnected  when the power supply assembly is removed. 6. This equipment is designed to mount in a suitably ventilated 19” rack; ensure that any  ventilation slots in the unit are not blocked or covered. 7.
  • Page 4 Regulatory Notices 9. To avoid exposure to dangerous voltages and to avoid damage to the unit, do not  connect the rear panel Ethernet port to telephone circuits. 10. As the colours of the cores in the mains lead may not correspond with the coloured  markings identifying the terminals in your plug, proceed as follows: • The green and yellow core must be connected to the terminal in the plug  identified by the letter E, or by the earth symbol  and yellow. • The blue core must be connected to the terminal marked with the letter N or  coloured black. • The brown core must be connected to the terminal marked with the letter L or  coloured red. 11. This apparatus must be earthed. WEEE PRODUCT END‐OF‐LIFE INFORMATION This product was designed and built by Dolby Laboratories to provide many years of service, and is backed  by our commitment to provide high‐quality support. When it eventually reaches the end of its serviceable  life, it should be disposed of in accordance with local or national legislation. For current information, please visit our website at:      , or coloured green, or green  www.dolby.com/environment. Dolby ® DP600 Program Optimizer Manual...
  • Page 5 This unit complies with safety standard EN60950-1 as appropriate. The unit shall not be exposed to dripping or splashing and no objects filled with liquids, such as coffee cups, shall be placed on the equipment. To ensure safe operation and to guard against potential shock hazard or risk of fire, the following must be observed: Ensure that your mains supply is in the correct range for the input power requirement of the unit.
  • Page 7: Table Of Contents

    Chapter 1 Introduction 1.1 Work-Flow Integration ...3 1.2 Work-Flow Flexibility and Ease of Use ...3 1.3 Applications ...4 1.4 Supported Media Formats and Audio Types ...5 1.5 DP600 Front Panel ...6 1.5.1 Touch Screen User Interface ...6 1.5.2 CD/DVD-ROM Drive ...6 1.5.3 System Reset and Display Controls ...7 1.5.4 Power Supply Indicators ...7 1.5.5 Internal Drive Indicators ...7...
  • Page 8 Table of Contents A.3.3 Selecting a Bookmark to Specify a Path...64 A.4 Entering a Destination Path ...65 Appendix B DP600 Program Optimizer Detailed Profile Descriptions B.1 Understanding DP600 Profiles ...67 B.2 Profile Descriptions...73 Appendix C System Administrator Functions C.1 Access Levels...101 C.1.1 Admin Level ...101 C.1.2 User Level...101 C.1.3 Viewer (default) Level ...101...
  • Page 9 Figure 1-1 Coded Audio with Metadata Analysis and Correction ... 2 Figure 1-2 Audio Analysis and Correction for Audio Types Without Metadata ... 2 Figure 1-3 DP600 Front Panel ... 6 Figure 1-4 DP600 CD/DVD-ROM Drive (Behind Touch Screen Door) ... 6 Figure 1-5 DP600 Rear Panel...
  • Page 10 List of Figures Figure 2-44 Work Orders Info Screen... 39 Figure 2-45 Info Reports Screen... 40 Figure 2-46 Detailed Report Displayed in Reports Info Screen ... 40 Figure 2-47 Export Report Confirmation ... 41 Figure 2-48 Edit Selected Workorder Screen ... 42 Figure 2-49 Click Reports in Home Screen ...
  • Page 11 List of Figures Figure C-20 Automation Screen After Setting Up Criteria ... 113 Figure C-21 Update Automation Criteria Screens ... 114 Figure C-22 Log... s Screen (Success)114 Figure C-23 Log...s Screen (Failure)114 Figure C-24 Select System Log Output Directory Screen ... 115 Figure C-25 Power Screen ...
  • Page 13: Chapter 1 Introduction

    Welcome to Dolby The Dolby DP600 Program Optimizer is a result of Dolby Laboratories’ continued  leadership in the development of innovative broadcast technologies.  DP600 provides a file‐based work‐flow solution for loudness correction, audio    conversion, and upmixing. It is specifically designed for use in cable, satellite, IPTV,  terrestrial TV, radio, and postproduction facilities. The DP600 includes the world’s first  intelligent audio analysis and automated loudness normalization engine, along with the  ability to encode, decode, convert, or transcode between the following Dolby formats:  Dolby Digital, Dolby Digital Plus, Dolby Pulse, and Dolby E bitstreams; as well as PCM,  MPEG‐1 LII, AAC, HE AAC, and HE AAC v.2. It also features a newly designed algorithm  for upmixing legacy two‐channel audio for 5.1‐channel delivery. To ease the transition into  a file‐based workflow, the DP600 also supports many of the most common broadcast media  file and audio formats in use today. For compressed audio formats that include metadata (for example, Dolby E, Dolby Digital,  Dolby Digital Plus, and Dolby Pulse), the DP600 can automatically set or correct the   audio metadata parameter (see Figure dialnorm For audio formats that do not include metadata, the DP600 can automatically set or correct  the   parameter by referencing a user‐defined target level (see Figure dialnorm Content producers and broadcasters can reduce loudness complaints by using the DP600  to provide viewers with a consistent audio experience across programs, channels, and  networks. Expanding upon the unique Dialogue Intelligence the Dolby LM100 Broadcast Loudness Meter, the DP600 normalizes the loudness of audio  programs while preserving their original dynamic range. loudness of file‐based audio bitstreams coded in Dolby Digital, Dolby Digital Plus, Dolby  Pulse, and Dolby E, and validates and corrects the  for decoding and reencoding the original audio bitstream. The DP600 also provides  intelligent speech‐based loudness normalization for both PCM audio and MPEG‐1 LII  audio. The DP600‐C provides faster‐than‐real‐time file‐based encoding, decoding, and conversion  between all of Dolby’s audio formats (Dolby Digital, Dolby Digital Plus, Dolby Pulse, and  Dolby E), and PCM, MPEG‐1 LII, AAC, HE AAC, and HE AAC v.2, while preserving the  audio metadata. In addition, it offers a unique, high‐quality, single‐step Dolby Digital to  Dolby Digital Plus transcoder that preserves the metadata and minimizes tandem coding  losses. This allows the audio from existing media archives to be converted to  next‐generation broadcast formats. The DP600 also supports Dolby Pro Logic for two‐channel matrix‐encoded content derived from multichannel source files. In very rare cases involving extreme loudness corrections that require gain, soft limiting will occur only ...
  • Page 14: Figure 1-1 Coded Audio With Metadata Analysis And Correction

    Introduction Customers interested in enhancing two‐channel audio for use in 5.1‐channel applications  can purchase an optional DP600 software upgrade that adds an intelligent file‐based  upmixing capability. This unique process is based on a newly developed Dolby algorithm  that creates a wider, natural‐sounding sweet spot. It also ensures that subsequent  downmixing is free from artifacts typically found with other solutions. The upmixing  process can be adaptively integrated into the same DP600 work‐flow profiles utilized for  file‐based loudness correction, encoding, decoding, conversion, and transcoding. Figure 1‐1 Dolby DP600 Program Optimizer Uncorrected File Broadcast Media File with Analyze Audio Dolby E, Dolby Digital, or Dolby Digital Plus or Dolby Pulse Analyze Dolby Metadata 01101010011010100111001101110000 Figure 1-1 Coded Audio with Metadata Analysis and Correction Figure 1‐2 Dolby DP600 Program Optimizer Uncorrected File...
  • Page 15: Work-Flow Integration

    Work-Flow Integration You can integrate the DP600 into an existing file‐based network infrastructure as an  intelligent processing node. In this environment, the DP600 adapts to your day‐to‐day  operations and workflow, which includes: • Program ingest, audio transcoding and conversion, and quality control (QC): Newly  ingested content can be routed through the DP600 for loudness analysis and  correction, encoding, decoding, and conversion processes before being moved to your  media storage library or play‐out server.  • Postproduction: File‐based Dolby E, Dolby Digital, Dolby Digital Plus, and Dolby  Pulse bitstreams can be encoded and decoded to and from multichannel . Broadcast . metadata chunk). File‐based media and audio assets can be analyzed, logged, and (if  necessary) corrected in faster than real time before delivery to clients.  • Ad insertion: Newly ingested ad content can be passed directly to the DP600 for  loudness analysis and correction before it’s placed in your storage archive or ad  server.  • Video‐on‐demand (VOD): Customer‐facing VOD servers, as installed at cable and  IPTV head‐ends, need to have their content normalized before it is made available to  the public. This content can be supplied to the servers either directly, via an ingest  department at the broadcaster or affiliate, or via satellite from one or more content  aggregators. The DP600 can be installed at the content aggregator, normalizing  content before it is sent (ʺpitchedʺ) over the satellite link. Alternatively, it can be  installed at the head‐end, taking content that has either been ingested directly or  caught from one or more pitchers and normalizing it before it is passed to the  customer‐facing server. Work-Flow Flexibility and Ease of Use The Dolby DP600 platform supports several types of applications, including archiving,  automated QC, content conversion, and media asset management; it offers considerable  potential for integration with third‐party systems through an open application  programming interface (API). To meet specific user requirements, you can control the DP600 and its processing engines ...
  • Page 16: Applications

    Introduction Applications The DP600 has many applications in cable, satellite, IPTV, terrestrial, and postproduction  broadcasting. Cable Applications • Automated VOD file analysis and loudness correction  • Automated VOD file transcoding and conversion • Automated digital program insertion (DPI) file analysis and loudness correction  • Automated broadcast media file audio transcoding and conversion • Automated broadcast media file QC and loudness correction  Satellite Applications • Pay‐per‐view (PPV) file analysis and loudness correction  • PPV file audio transcoding and conversion • Automated broadcast media file audio transcoding and conversion • Automated broadcast media file QC and loudness correction IPTV Applications • Automated VOD file analysis andloudness correction • Automated VOD file transcoding and conversion • Automated broadcast media file audio transcoding and conversion • Automated broadcast media file QC and loudness correction Terrestrial Applications (Networks/Affiliates/Independent Stations) •...
  • Page 17: Supported Media Formats And Audio Types

    Supported Media Formats and Audio Types The DP600 supports many media formats and audio types, including media file formats  and linear and coded audio types. Media File Formats GXF (SMPTE 360M);MXF operational patterns per SMPTE 390M (OP‐Atom); SMPTE 378M (OP‐1a); SMPTE 391M (OP‐1b with internal essence file formats only); MXF  container (essence) support per SMPTE 379M (GC); SMPTE 381M (GC‐MPEG); SMPTE  383M (GC‐DV minus supportfor audio essence interleaved in DV);  SMPTE 382M (GSC‐AESBWF); MPEG‐2 program stream; MPEG‐2 single program  transport stream Linear Audio Types • ,  , and multichannel . .wav audio metadata . • , including multichannel  .aiff • 16‐, 20‐, and 24‐bit PCM (within any of the aforementioned media file formats) Coded Audio Types Dolby Digital (AC‐3), Dolby Digital Plus (E‐AC‐3), Dolby Pulse (HE AAC, HE AAC v.2  plus metadata), Dolby E, AAC, HE AAC, MPEG‐1 LII Dolby DP600 Program Optimizer Manual ®...
  • Page 18: Dp600 Front Panel

    Introduction DP600 Front Panel The DP600 front panel includes the following components: • Touch screen user interface • CD/DVD‐ROM drive and system reset/display controls (behind touch screen door) • Power supply indicators  • Local storage indicators • USB 2.0 port Figure 1‐3 Touch screen user interface DP600 Program Optimizer DP600 Program Optimizer Figure 1-3 DP600 Front Panel 1.5.1 Touch Screen User Interface The LCD touch screen provides user controls for the initial configuration; rescheduling,  canceling, and pausing work orders and reports; and checking the system status. You  simply touch the icon that represents the desired function, and the DP600 responds  accordingly. To add and configure work orders and export reports, you need to use the  DP600 Client, as described in Section functions, see Section 1.5.2...
  • Page 19: System Reset And Display Controls

    1.5.3 System Reset and Display Controls These recessed buttons are located behind the touch screen, above the CD/DVD‐ROM  drive. If you need to press any of these buttons, use a nonconductive material, such as a  toothpick.  If you press the  you cannot restart the system by pressing <Ctrl>+<Alt>+ <Delete> to restart. Always avoid  restarting by disconnecting and reconnecting the power cables. You can use the 1.5.4 Power Supply Indicators Three power supply LEDs on the front panel indicate whether the power is on, if one of the  redundant power supplies has failed, and the temperature of the unit.  Power: This green LED lights when the DP600 has power.  Power supply failure: This red LED is off during normal operation. It lights or  flashes red if either of the redundant power supplies fails. Temperature: This tricolor LED glows green when the temperature of the unit is   cool, yellow if the temperature is warm, and red if the temperature is hot. If this  LED is yellow or red, the operating environment may be warmer than expected  and in need of modification. In such a case, call your Dolby authorized technical  representative immediately. 1.5.5 Internal Drive Indicators The DP600 has five physical internal hard drives. Drives 1 and 2 are arranged in a  RAID 1 configuration to provide protection for the operating system as well as  local storage. The remaining three hard drives are configured as separate drives to  provide local storage. This configuration of one RAID pair and three separate  drives represents four logical drives.  There are four bicolor LEDs on the front panel, labeled  the status of the DP600’s four logical internal hard drives. The drive LEDs function as  follows: Off (nonilluminated): Indicates a functional drive with no current disk access activity. Green: Indicates normal drive activity.
  • Page 20: Usb 2.0 Port

    Introduction LEDs  ,  , and  configured as separate drives and do not have RAID backup capability. If any of these  drives fail, the failed drives must be replaced, and any work orders in progress during the  failure must be restarted.  If one of the drive LEDs turns red, refer to Table failed. Typically, the DP600 automatically rebuilds the RAID array when one of the RAID  drives has a problem or is replaced (with the power on). During the RAID rebuild process,  LED   blinks in red in half‐second intervals. When the rebuild process is complete, LED  stops blinking.  In some instances (for example, if you replace a non‐RAID drive), you must initiate the  rebuild process manually, as described in Section If you replace both RAID drives, you also need to reinstall the DP600 software. In such a  case, follow the instructions for a clean installation in Section software, the system automatically synchronizes the two RAID drives, re‐creating the  original mirrored RAID array (manual rebuild not required). For instructions on replacing a drive, see Section Table 1-1 Local Storage LED Conditions Front-Panel LED 1.5.6 USB 2.0 Port The front‐panel USB 2.0 port is provided for license loading from a USB flash drive or  to connect the provided USB keyboard.  indicate the status of the other three physical disks. These disks are  Condition Failed Physical Drive Solid red Blinks in red in ...
  • Page 21: Dp600 Rear Panel

    3.0–1.25A 50/60Hz Power Supply Power Supply Alarm Reset Alarm Reset Dolby and the double-D symbol are registered trademarks of Dolby Laboratories. Dolby and the double-D symbol are registered trademarks of Dolby Laboratories. Power supplies PS/2 ports Figure 1‐6 Figure 1-5...
  • Page 23: Chapter 2 Using The Dp600

    3.0–1.25A 50/60Hz Power Supply Power Supply Alarm Reset Alarm Reset Dolby and the double-D symbol are registered trademarks of Dolby Laboratories. Dolby and the double-D symbol are registered trademarks of Dolby Laboratories. Connect power Figure 2-1 Connect DP600 Keyboard (Front-Panel Connection) Caution: Currently, you must use the DP600’s upper Ethernet port to connect to your ...
  • Page 24: Starting The System For The First Time

    Using the DP600 Starting the System for the First Time Note: Before starting the system, be sure it’s connected to an active network. To download your license and enable the DP600, you also need a PC with Internet  access and an available USB port, and the USB device provided with your unit. The DP600 touch screen provides a user‐friendly interface where you perform actions by  pressing the respective screen area. The touch screen is calibrated during the  manufacturing process. When you start the DP600 for the first time, the DP600 Welcome! screen appears, which  provides a checklist of things you need before you can set up the system, as shown in  Figure 2‐3. Figure 2‐3 Figure 2-3 DP600 Welcome! Screen   Dolby DP600 Program Optimizer Manual ®...
  • Page 25: Figure 2-4 Network Screen

    To configure the system: Be sure you are ready to proceed by checking the  right arrow at the bottom of the screen. The  Network the system, the IP address appears only if you enter a static IP address (DHCP  unchecked). If you’re using DHCP, the IP address does not appear until you complete  the system setup. Note: Figure 2‐4 Figure 2-4 Network Screen In the  General Configuration Enter Hostname will appear in the appropriate format when you need to make entries using the touch  screen.  Dolby DP600 Program Optimizer Manual ®  screen appears, as shown in the example in Figure In this screen, and in all the following DP600 setup screens, you enter  information to configure your system. If you press the  the bottom left corner of any of the following setup screens, the system  cancels all of your entries (in all the setup screens, in addition to the  currently displayed setup screen). A cancel confirm prompt appears.  If you confirm, the unit cancels your entries and automatically reboots,  and then the   screen reappears. At this point, you can reenter  Welcome! your settings.    box, press the  Hostname alphanumeric key pad appears, as shown in Figure Starting the System for the First Time...
  • Page 26: Figure 2-5 Hostname Keypad

    Using the DP600 Figure 2‐5 Figure 2-5 Hostname Keypad Press on the desired keys to enter a hostname, then select  Enter a unique name with no spaces or other nonconventional network naming  characters (for example, dp600‐unit‐1). In the  General Configuration Enter Gateway Address Figure 2‐6 Figure 2-6 Enter Gateway Address Number Pad Screen Press on the desired numbers to enter an optional gateway address, then select  In the  Upper Interface Settings dynamic addressing or uncheck this box (by pressing on it) if you want to enter a  fixed IP address.  The upper interface corresponds to the top Ethernet port (port 0) on the DP600 rear  panel. The lower interface (bottom port) is currently nonfunctional. If you specified a fixed IP address, the respective fields are now active. Make your  entries by pressing on the number pad screens, then press on the appropriate numbers (see the gateway address     box, press on the   number pad appears, as shown in Figure  ...
  • Page 27: Figure 2-7 Date & Time Screen

    number pad instructions described in step 4). Alternatively, you can press on the field,  and then use the USB keyboard to make your entries (as described in step 3 for the   field). Hostname Press the right arrow at the bottom of the  The  Date & Time Figure 2‐7 Figure 2-7 Date & Time Screen Press the Server Date & Time The  Set Server Date/Time Figure 2‐8 Figure 2-8 Set Server Date/Time Screen 10. Press the up and down arrows above and below each field to set the server date and  time, then press  11. Press the  Server The  Select Region Dolby DP600 Program Optimizer Manual...
  • Page 28: Figure 2-9 Select Region Screen

    Using the DP600 Figure 2‐9 Figure 2-9 Select Region Screen 12. Press on your region, then press the right arrow. The  Select City You need to select your closest city to ensure that submitted work orders run at the  scheduled time. Figure 2‐10 Figure 2-10 Select City or Zone Screen  S      screen appears for your region, as shown in Figure Zone  L 2‐10. Dolby DP600 Program Optimizer Manual ®...
  • Page 29: Figure 2-11 End User License Agreement Screen

    13. Press on your closest city, then press  The  End User License Agreement Figure 2‐11 Figure 2-11 End User License Agreement Screen 14. Read the license agreement and be sure you understand it, then press the  and accept these terms The  License personal identification number ( license your unit for operation.  Figure 2‐12 Figure 2-12 License Screen Dolby DP600 Program Optimizer Manual ® finish screen appears, as shown in Figure   box, and press the right arrow.  screen appears. This screen displays the unit’s ...
  • Page 30: Figure 2-13 Select Product Licensing On Dolbysupport Home Page

    Using the DP600 15. Locate the USB flash device in the DP600 packing kit, and insert it into a PC with  Internet access.  16. Open a Web browser and go to  17. If you have previously registered, simply log in. 18. If you are a new user, please take a few moments to register. 19. Once logged in, select  in Figure 2‐13. A shortcut to DP600 product licenses may also appear under  shortcut appears, you can select it to go directly to the  Figure 2‐13 Select Product Licensing or DP600 Get License Shortcut Figure 2-13 Select Product Licensing on DolbySupport Home Page The  Get New License File Figure 2‐14 Enter required information, then select Register product Figure 2-14 Get New License File Page...
  • Page 31: Figure 2-15 Product Registered Page

    20. Select  DP600 21. Enter the required information in the rest of the fields (the unit’s  displayed on the DP600 touch screen, as shown in the example in Figure Fields marked with an asterisk (*) are required.  22. After entering information in all the required fields, select  bottom of the page, as shown in Figure Once the product is registered, a message in red text near the top of the screen informs  you that the DP600 is now registered, and the registered product information appears  at the bottom of the screen (identified by serial number), as shown in Figure Figure 2‐15 Enter PIN Figure 2-15 Product Registered Page 23. To download your license for the base unit, enter the unit’s PIN in the field next to the  serial number, then select  the DP600 touch screen, as shown in the example in Figure 24. To upgrade the base unit for encoding, decoding, transcoding and conversion, or  upmixing: • Select  Upgrade Figure 2‐16.  • Enter the unit’s PIN and the respective upgrade key you received with your unit.  If you do not have an upgrade key, contact Dolby Laboratories. • Select  Upgrade Dolby DP600 Program Optimizer Manual ®...
  • Page 32: Figure 2-16 Upgrade Serial Number

    Using the DP600 Figure 2‐16 Figure 2-16 Upgrade Serial Number All upgrades appear at the bottom of the screen under you are done, click the  next to its serial number and click  all upgrades applied). Proceed to step 25.  Note: If you decide to upgrade your licenses at a later time and have an  Upgrading Your License on page 109. Figure 2‐17 Figure 2-17 Upgrade Appears Under Previous Upgrades Note:    button. On the  Done Download   After you apply your system upgrade keys, future downloads do not  require reentering the keys. After entering your PIN, click  and your license automatically downloads (including all applicable  upgrade keys). Enter PIN Enter upgrade key Click Upgrade . When ...
  • Page 33: Figure 2-18 License Confirmation Prompt

    25. At the prompt, save the downloaded file to the USB flash device inserted in your PC.  This file is the license for your DP600 system (including any upgrades). 26. Remove the USB flash device from your PC, and insert it into one of the DP600 USB  ports.  It will take a few seconds for the DP600 to recognize the license. 27. Press the  license A confirmation prompt informs you that the license installed successfully.  Note: Figure 2‐18 Figure 2-18 License Confirmation Prompt 28. Press  The  Finished! Figure 2‐19 Figure 2-19 Finished! Screen 29. Press  finish The DP600 setup is now completed and the system automatically reboots. During the  reboot process, remove any discs in the CD/DVD‐ROM drive, as the system attempts  to boot from any inserted disc. If an installation disc is inserted, the system begins a  new installation. You can repeat the previous steps for each license you want to download and each  upgrade you want to apply to your license. Dolby DP600 Program Optimizer Manual ®...
  • Page 34: Dp600 Home Screen

    Using the DP600 2.2.1 DP600 Home Screen After you complete the DP600 setup, the unit automatically reboots and the DP600  screen appears, as shown in Figure This screen displays the date and time at the upper right corner. The system status in the  right column shows icons indicating the current status of the  (for each installed hard drive). A green happy face icon  indicates correct functionality. A  red sad face icon  details, as described in Section work orders the work order and report functions later in this chapter, as described in Section Note the lock icon next to the date and time. When this icon is in the locked  system is in view only mode. In this mode, you can display some information and check  the system status, but cannot reconfigure or operate the system. To reconfigure the system,  you must log in with an  you must log in with a  icon and entering your user ID and password. When you log in, the lock icon changes to  the unlocked  Figure 2‐39. After ten minutes of idle time, the system returns to the locked position, but you should log  out by pressing the lock icon and pressing  done working in the unlocked mode. To obtain a  USER System Administrators can also perform all  administrator, see Appendix system. Figure 2‐20 Figure 2-20 DP600 Front-Panel Home Screen 2‐20.
  • Page 35: Using The System Screen

    2.2.2 Using the System Screen The   screen allows you to check the system information and status. In addition, if  system you have an  ADMIN upgrade your license, archive and delete files, and reboot or shut down the system. Checking the System Info and Status To check the system information and status: Press  system When the system is locked, the  Figure 2‐21. In this state, you can access only the  ,  upgrade maintenance must log in with an  described in Appendix Figure 2‐21 Figure 2-21 System Screen Press    info The   screen appears, as shown in Figure info   Software Information Figure 2‐22...
  • Page 36: Figure 2-23 Status Screen

    Using the DP600 Press  status The   screen appears, as shown in Figure status  and  volumes Figure 2‐23 Figure 2-23 Status Screen Press  volumes The  volumes for each disk volume. When any volume exceeds 90% capacity, the disk happy face on  the   screen turns to a sad face. In addition to the system’s internal storage, this  Home screen displays the status of your work order source and destination external storage  (described on page 31 and page 32).  Figure 2‐24 Figure 2-24 Volumes Screen in the   screen. system  status by pressing the respective icons. disks      in the   screen. status  screen appears, as shown in Figure  ...
  • Page 37: Using The Dp600 Remote Client Software

    Press    disks The   screen appears, which displays the status for each RAID drive, as shown in  disks Figure 2‐25. Figure 2‐25 Figure 2-25 Disks Screen Using the DP600 Remote Client Software To process audio using the DP600, you need to use the Dolby DP600 Remote Client  software (also referred to as “DP600 Client“ or “Client”). With this application, you can  define and run an operation we call a work order. The DP600 Client runs on your  Microsoft ® Windows but provides more user control functions. For example, with the Client, you can: • Add and configure work orders • Run work order profiles to analyze dialogue levels, perform dialogue normalization,  and encode, decode, transcode or convert, and upmix audio files • Export work order reports 2.3.1 Understanding Work Orders Currently, there are seven types of work orders: • Standard •...
  • Page 38 Using the DP600 Standard, Pinnacle Standard, and Omneon Standard Work Orders These types of work orders process audio on a file‐by‐file basis. You specify the path to the  source file on your PC or anywhere on the network. You also specify a destination where  you want to save the processed file. Pinnacle work orders are designed specifically for  Pinnacle Systems specifically for Omneon server files and are incompatible with other formats. Hot Folder Work Order With this type of work order, you specify the path to a source folder on your PC or network  where the audio files you want to process are located. The DP600 periodically looks for files  of a specific type in this folder, which is controlled by the work order profile. The work  order profile associated with your hot folder also determines how the DP600 processes the  files. In addition, you specify the destination where you want to save the processed files.  When the DP600 sees the specified file type in the source directory, it processes those files  according to the current profile, and then saves the processed files in the destination folder.  Note: You can link only one work order profile with a single hot folder. However, you can  create multiple hot folders, each with a different profile. Pinnacle Hot Folder Work Order This type of hot folder is designed specifically for Pinnacle MediaStream server files. Omneon Hot Folder Work Order This type of hot folder is designed specifically for Omneon server files and is incompatible ...
  • Page 39: Running The Dp600 Client

    You can download a copy of the DP600 manual (this manual) by clicking the  If the current version of Client software is not already installed on the Client PC, the  correct version automatically downloads directly from the DP600 (no Internet access  required). You can install and run the Client from multiple computers simultaneously. Client  updates automatically occur each time the Client runs on a specific PC. For this reason,  the Client isnʹt really installed as such. You simply run the application from the DP600,  which automatically downloads any necessary files and updates as required. Dolby DP600 Program Optimizer Manual ® >  menu. Dolby Laboratories splash screen appears, as shown in Figure  T  in the splash screen ™  Web Start launches, the Client automatically connects to the   screen appears, as shown in Figure home Using the DP600 Remote Client Software ®  6 or higher,  ®  3 or higher. Other browsers and  2‐26. Download manual Download Java 2‐27. ...
  • Page 40: Dp600 Client Home Screen

    Using the DP600 2.3.3 DP600 Client Home Screen After launching the DP600 Client, as described in Section screen appears on your PC. This screen looks similar to the  touch screen and you can perform many of the same functions using the Client. You can  also perform some additional functions. The Client functions are described on the  following pages. When a procedure says “click” something, this means that you can  perform the respective function only with the Client. If it says “press or click,” this means  you can perform the respective function using the touch screen or the Client. However, to  access any of their respective locked areas, you must log in separately on the touch screen  and the Client. Figure 2‐27 Figure 2-27 DP600 Client Home Screen   2.3.2, the DP600 Client  home  screen on the front‐panel  home Dolby DP600 Program Optimizer Manual ®  ...
  • Page 41: Creating A Work Order

    Creating a Work Order To create a work order:  Click  work orders Figure 2‐28 {Click work orders   Figure 2-28 Displaying the Work Orders Screen The  work orders and configure a work order and perform other related functions.  Click   at the right side of the  Figure 2‐29 Figure 2-29 Adding a Work Order Dolby DP600 Program Optimizer Manual ®  near the upper left corner of the   ...
  • Page 42: Figure 2-30 Login User Screen

    Using the DP600 The     screen appears, as shown in the example in Figure Login User To add and configure work orders, you need to log in with a  and password. If you don’t have an ID and password, contact your system administrator.  If your system administrator hasn’t set up IDs yet, a default ID and password is provided  in Section C.2. Figure 2‐30 Figure 2-30 Login User Screen Click your ID ( enter your password and click  The    Workorder work order selected. In this menu, you can enter information in the displayed fields to configure your work  orders. You can also click the  additional settings for hot folders. Figure 2‐31 Figure 2-31 Add Workorder Screen   Click your ID Click here to enter password Click login  or ...
  • Page 43: Figure 2-32 Selecting A Work Order Type

    To set up your work order: Click the  Name Click the  Type Pinnacle Standard or  Folder, Grass Valley Hot Folder Note: Omneon Standard Omneon servers and are incompatible with other platforms. Figure 2‐32 Figure 2-32 Selecting a Work Order Type Click the  Source The  Enter Path the path to the file or folder (for a hot folder) that you want to designate for processing.  Before entering a path, be sure you’re connected to an active network, and then set up  a shared folder for all authorized users, as described in Section Note: You can enter a path using any of the following methods:  • Enter a URL (directly) Type the desired URL in the  which cannot include the username/password/domain information in the  field (for example, smb://dp600/users/common/hot_folder/). If necessary, you can  enter a ...
  • Page 44: Figure 2-33 Enter Path Screen

    Using the DP600 • Browse to the desired location Click  browse select either  necessary) enter a  Credentials  screen. Then click  Details desired file or folder and click  desired file or folder in the  browse entered URL. • Select a bookmark Click on the   screen (as previously described), then select the desired bookmark to specify  File the path and click  the  (SMB only) in the corresponding fields each time you select the bookmark. After  selecting the bookmark, you can click  Note: Figure 2‐33 Figure 2-33 Enter Path Screen Use one of the methods to enter the path to the file or folder (for a hot folder) that you  want to designate for processing, then click  Click the  Destination Enter Path where you want to save the processed files. This screen is identical to the  screen described earlier for the source path. Use one of the methods to enter the path to the location where you want to save the ...
  • Page 45: Figure 2-34 Entering The Work Order Start Time

    Enter the  Priority If you want the system to process a work order first in the queue, enter  work orders with the same priority, the system sets the queue using the  as explained in step 7. If you want to start your work order immediately, use the default (  field. If you want to specify a start time for your work order, click on the  Start At  field. The  Start At Figure 2‐34 Figure 2-34 Entering the Work Order Start Time Use the up and down arrows to specify a day, month, year, and time when you want  to start (run) the work order, then click  For  Hot Folder work orders, if you want to run your work order indefinitely, use the default  Indefinitely Figure 2‐35 Figure 2-35 Standard Settings for Hot Folder and Pinnacle, Omneon, and Grass Valley Hot Folders Dolby DP600 Program Optimizer Manual ®...
  • Page 46: Figure 2-36 Entering The Work Order End Time (Hot Folders And Grass Valley Hot Folders Only)

    Using the DP600 If you want to specify a time when the DP600 stops looking for files to process in this  hot folder, click the  End At 10. Use the up and down arrows to specify a day, month, year, and time when you want  to end the hot folder work order, then click  Figure 2‐36 Figure 2-36 Entering the Work Order End Time (Hot Folders and Grass Valley Hot Folders Only) 11. Click in the  processes the work order. 12. Click the  Additional Settings folder settings. In addition, Grass Valley Hot Folders provide some network settings.  Figure 2‐37 shows all the hot folder settings. Figure 2‐37 Hot Folder, Pinnacle Hot Folder, and Omneon Hot Folder Settings Figure 2-37 Additional Hot Folder Settings  field.
  • Page 47 Following is a description of each of the  • Stable Period Allows you to fine‐tune the hot folder/work order activation process for your  specific network environment. This applies to configurations where the system  copies files from one server into a hot folder the DP600 is monitoring on another  server. This is typical in work‐flow environments that process an extremely large  number of files. In this type of work flow, some remote file systems cannot  confirm to any degree of accuracy when a file is completely copied from its source  into a hot folder.  By utilizing the  all new files in the hot folder, and waits until the file size stabilizes (does not  increase in size). If the file size remains the same for the number of milliseconds  (ms) you enter in the  process on the respective files. The default is  ensure the system doesn’t begin processing files before they’re completely copied  into the designated hot folder. • Scan Interval Specifies how often the DP600 scans a hot folder for new files to process. The  default is  • Retry Count Specifies how many times the system tries to process a hot folder work order  before the work order fails. The default is  • Retry Delay Specifies how many seconds the system waits before retrying to process a hot  folder work order. The default is  • IP Address Specifies the  • Notes Allows you to enter any related text for the corresponding work order. 13.
  • Page 48: Figure 2-38 Selecting A Work Order Profile

    Using the DP600 Figure 2‐38 Figure 2-38 Selecting a Work Order Profile 15. Select the work order profile you want to use to process your files, then click  After you add a work order, it runs as specified in the  work order is running, the  Figure 2‐39 Figure 2-39 Work Order Running as Displayed in Home Screen    screen displays the progress, as shown in Figure home    menu. When a  Add Workorder 2‐39. Dolby DP600 Program Optimizer Manual ®...
  • Page 49: Figure 2-40 Work Orders Screen Displays Database

    After you add a work order, it appears in the  in the  orders home profiles, creation dates, status, scheduled start times, and source files for all work orders,  as shown in Figure of each entry. Figure 2‐40 Figure 2-40 Work Orders Screen Displays Database When you click the filter criteria icon  Figure 2‐40), the  Figure 2‐41 Figure 2-41 Workorder Filter Criteria Screen When you configure the filter criteria, you can modify the default information displayed in  the  work orders reappears in color  screen. When you click  in white. Following is a description of each filter criteria option. Dolby DP600 Program Optimizer Manual ® work orders  screen). In this screen, the work order database displays the names, ...
  • Page 50: Figure 2-42 Date Created Options

    Using the DP600 Name Contains This option specifies that the  keywords you enter in this field. The default is  orders appear. Profile This option specifies that the  profile. When you click in this field, the  Figure 2‐38. In this field, you can select the desired profile. The default is  specifies that work orders using any profile appear. Date Created This option specifies that the  period. When you click in this field, you can select the desired option from the drop‐down  menu. The default is  , the  All Dates  fields, you can enter an exact before or after date and time using the displayed  Created After controls. The default is  shows all the options. Figure 2‐42 Figure 2-42 Date Created Options Priority This option specifies that the  or below a certain number. When you click in the  can select the desired priority from a drop‐down menu, as shown in Figure default is  Include All Figure 2‐43 Figure 2-43 Set Priority Values  screen displays only work orders that include the ...
  • Page 51: Figure 2-44 Work Orders Info Screen

    In addition to adding work orders and displaying work order information, the screen displays other icons, which enable you to display more information, as well as  pause, edit, cancel, and delete a selected work order. Following is a description of each of  these icons: When you select a work order in the database, and then press or click the  icon, profile, schedule, and reports information appears in the  shown in Figure Figure 2‐44 Figure 2-44 Work Orders Info Screen In addition, if you press or click the  information appears for the selected work order, as shown in Figure displays the following information for each work order: • Date  • Severity  • Description  • Name of work order Dolby DP600 Program Optimizer Manual ® 2‐44.    icon in the  reports Creating a Work Order work orders  screen, as ...
  • Page 52: Figure 2-45 Info Reports Screen

    Using the DP600 Figure 2‐45 Figure 2-45 Info Reports Screen On the right side of the  the   screen responds accordingly. Following is a description of each of these icons. reports When you press or click on a work order report to select it, and then press or  click this icon, the corresponding detailed report appears, as shown in the  example in Figure Figure 2‐46 Figure 2-46 Detailed Report Displayed in Reports Info Screen    screen, five icons appear. When you click any of these icons,  reports 2‐46.   Dolby DP600 Program Optimizer Manual ®...
  • Page 53: Figure 2-47 Export Report Confirmation

    When you press or click any of the lower four icons, only work order reports associated  with that icon appear. When you press or click again on the same icon, this type of report  no longer appears. If you click more than one icon, the respective reports appear,  corresponding to all the selected icons. Following is a description of each of these icons. Selecting this icon displays any work order reports that contain information,  but no warnings or errors. Selecting this icon displays any work order reports that contain warnings. Selecting this icon displays any work order reports that contain errors. When you click on a work order report, and then click this icon (displayed  only in the DP600 Client), the system saves a text file of the report to the  desired location on your PC. A confirmation dialog box appears where you  enter the desired name and path, and then click  Figure 2‐47 Figure 2-47 Export Report Confirmation When a work order is running and you press or click this icon, the work order  pauses. To resume processing, click or press this icon again. When you select a work order in the database, and then press or click this icon, the  Edit Selected Workorder can edit your work order settings. After making the desired changes, you can either  select  update work order. If you create a new work order, we recommend entering a new name to  differentiate it from the original work order. The new work order now appears in  the work order database. Dolby DP600 Program Optimizer Manual ®    screen appears, as shown in Figure  to update the current work order or select  Creating a Work Order , as shown in Figure 2‐47.
  • Page 54: Figure 2-48 Edit Selected Workorder Screen

    Using the DP600 Figure 2‐48 Figure 2-48 Edit Selected Workorder Screen When you click this icon, the  Figure 2‐31. In this menu, you can set up your work orders, as described on page 31.  One of these icons is displayed, depending on the state of the selected work order.  If the selected work order is running or scheduled, the  can press or click this icon to cancel the selected work order. If the selected work  order is not scheduled or running, the  work order from the database. In either case, a prompt appears, which asks you to  confirm your action (cancel or delete). Select  prompt.     Workorder delete  screen appears, as shown in   icon appears and you  cancel  icon appears, and you can delete the   or   at the confirmation  cancel Dolby DP600 Program Optimizer Manual ®...
  • Page 55: Figure 2-49 Click Reports In Home Screen

    Displaying Work Order Reports from the Home Screen In addition to displaying work order reports from the work order database, you can also  access reports from the  To access a report from the  Press or click the  Figure 2‐49 Figure 2-49 Click Reports in Home Screen The home  reports Figure 2‐50 Figure 2-50 Click Info in Home Reports Screen Dolby DP600 Program Optimizer Manual ®  screen.  home  screen: home  icon in the ...
  • Page 56: Figure 2-51 Display Report In Home Reports Info Screen

    Using the DP600 Press or click the desired work order report, then click  The respective work order report appears, as shown in Figure Figure 2‐51 Figure 2-51 Display Report in Home Reports Info Screen Send Us Your Feedback If you have a question or a comment regarding this chapter, send us an email.   info. 2‐51. Dolby DP600 Program Optimizer Manual ®...
  • Page 57: Chapter 3 System Maintenance

    This chapter explains how to maintain the Dolby you how to diagnose and repair hard drives and power supplies. Maintaining the DP600 Hard Drives The DP600 has five physical internal hard drives. Drives 1 and 2 are arranged in a RAID 1  configuration to provide protection for the operating system as well as local storage. The  remaining three hard drives are configured as separate drives to provide local storage. This  configuration of one RAID pair and three separate drives represents four logical drives.  There are four bicolor LEDs on the front panel, labeled  the status of the DP600’s four logical internal hard drives. The drive LEDs function as  follows: • Off (nonilluminated): Indicates a functional drive with no current disk access activity • Green: Indicates normal drive activity • Red: Indicates a drive failure LED  shows the status of the two‐drive RAID 1 configuration. The operating system is  installed on these mirrored drives to prevent a physical drive failure, resulting in an  inoperable system. If either of the mirrored drives fails, the other RAID drive enables the  system to operate normally until the failed drive is replaced. LEDs  ,  , and  configured as separate drives and do not have RAID backup capability. If any of these  drives fail, the failed drives must be replaced, and any work orders in progress during the  failure must be restarted. If one of the drive LEDs turns red, refer to Table failed. Typically, the DP600 automatically rebuilds the RAID array when one of the RAID  drives has a problem or is replaced (with the power on). During the RAID rebuild process,  LED 1 blinks in red in half‐second intervals. When the rebuild process is complete, LED 1  stops blinking.  In some instances (for example, if you replace a non‐RAID drive), you must initiate the  rebuild process manually, as described in Section If you replace both RAID drives, you also need to reinstall the DP600 software. In such a  case, follow the instructions for a clean installation in Section software, the system automatically synchronizes the two RAID drives, re‐creating the ...
  • Page 58: Replacing A Drive

    System Maintenance Table 3‐1 shows the LED conditions that specify the failed drive. Table 3-1 Local Storage LED Conditions Front-Panel LED 3.1.1 Replacing a Drive To replace a DP600 hard drive: Look at the front‐panel drive LEDs, then refer to Table has failed. Figure 3‐1 Figure 3-1 Red LED Indicates Failed Disk Drive Condition Failed Physical Drive Solid red Blinks in red in  two‐second intervals Blinks in red in  half‐second intervals Solid red Solid red Solid red  ...
  • Page 59: Figure 3-2 Remove The Dp600 Drive Cover

    Remove the DP600 front‐panel drive cover by placing one hand on its left side and  one hand on its right side, then pulling it toward you until it disengages from the  main unit, as shown in Figure Figure 3‐2 Figure 3-2 Remove the DP600 Drive Cover Use a Phillips screwdriver to loosen the four screws that secure the drive retaining  bracket, then remove the bracket as shown in Figure Caution: When loosening the screws, be sure not to remove them completely from the  bracket. Figure 3‐3 Figure 3-3 Remove the Drive Retaining Bracket Dolby DP600 Program Optimizer Manual ® 3‐2.     Maintaining the DP600 Hard Drives 3‐3.
  • Page 60: Figure 3-4 Physical Drive Numbers

    System Maintenance Starting from the left side of the drive cage, the first slot contains physical drive 1  (RAID drive 1). The second slot contains physical drive 2 (RAID drive 2). Starting with  the third slot, physical drives 3, 4, and 5 are installed next, in that order. In this  example, RAID drive 1 is the failed drive that requires replacement. how the drives are numbered from left to right (numbers do not appear on the actual  unit). Figure 3‐4 Figure 3-4 Physical Drive Numbers Match the failed drive’s number (determined in step 1) with the corresponding  physical drive, then grasp the drive’s finger tab and slide it out of its slot, as shown in  the example in Figure Figure 3‐5 Finger tab Figure 3-5 Remove Failed Drive from DP600   3‐5.    Figure 3‐4 shows  Dolby DP600 Program Optimizer Manual ®...
  • Page 61: Figure 3-6 Insert Replacement Drive In Dp600

    Be sure that no work order is running, then grasp the replacement drive’s finger tab,  and firmly but gently slide the drive into its slot (see Figure resistance, which indicates that the drive is seated in its socket.  You can replace a drive with a higher capacity unit but not with a lower capacity unit. Figure 3‐6 Figure 3-6 Insert Replacement Drive in DP600 Position the retaining bracket in front of the hard drives, lining it up with the screw  holes, then use a Phillips screwdriver to tighten its four screws and secure the drives,  as shown in Figure Figure 3‐7 Figure 3-7 Reinstall Retaining Bracket Reinstall the front cover by positioning it so that the mounting tang on the right side  of the RAID bay inserts in the mounting slot on the rear of the front cover. To do this,  hold the front cover so that there is an approximately 10‐degree angle between the  cover and the front of the unit, as shown in Figure Dolby DP600 Program Optimizer Manual ®   3‐7.    Maintaining the DP600 Hard Drives 3‐6) until you feel  3‐8.
  • Page 62: Rebuilding A Drive

    System Maintenance Figure 3‐8 Figure 3-8 Reinstall Front-Panel Drive Cover Slide the front cover over the mounting tang and move it to the left until the mounting  stud on the left rear side of the cover engages the hole in the front of the unit.  If you replaced one RAID drive and did not shut down the system, the RAID array  rebuilds automatically. However, if you are not running multiple work orders, we  recommend shutting down the system, rebooting, and manually rebuilding the RAID  array, as described in Section 3.1.2. If you replaced a non‐RAID drive, rebooting and manual rebuilding is required, as  described in Section 3.1.2. If you replaced both RAID drives (drives 1 and 2), you need to use the DP600 software  DVD to reinstall the software, as described in Section a clean installation and the system automatically synchronizes the two RAID drives,  re‐creating the original mirrored RAID array (manual rebuilding not required). 3.1.2 Rebuilding a Drive To rebuild a DP600 hard drive: Place the DP600 in an idle state by halting all work orders being processed. Determine which physical hard drive has failed (1, 2, 3, 4, or 5) by checking the drive  LEDs on the DP600 front panel, as described in Section Shut down the unit by clicking the  failed drive from its slot, following the instructions in Section 4. Be sure a monitor and keyboard are connected to the DP600, then reconnect the  power. 5. Press <Alt>+<3> when prompted to access the 3ware At this point, a red dialog box informs you that a degraded disk array is installed. Press  any key to continue. If you replaced one of the RAID drives (physical drives 1 or 2): •...
  • Page 63 • Press the <Tab> key to select  • Use the arrow keys to select  A list appears that shows which RAID drive is designated for rebuilding. • Press <Enter> to select  • Press <F8>, then type  Note: On some smaller keyboards you may need to press < function for the dual‐use keys. If you are rebuilding only the RAID array and did not replace a RAID drive: • Use the arrow keys on the keyboard to highlight the RAID marked as degraded,  then press the space bar to select it. • Press the <Tab> key to select  • Use the arrow keys to select  A list appears that shows which RAID drive is designated for rebuilding. • Press <Enter> to select  • Press <F8>, then type  Depending on the original size of the RAID array, a rebuild will take from one to  several hours to complete. During this time, the system operates normally. If you replaced a single non‐RAID drive (physical drives 3, 4, or 5):  • Use the arrow keys to highlight the new drive that appears in the  area, then press the space bar to select it.  • Press the <Tab> key to move to the menu buttons at the bottom of the screen, then  use the arrow keys to select the  The available unit should now appear in the  box. • Use the arrow keys to select the  • Type  main screen reappears. ...
  • Page 64: Replacing A Dp600 Power Supply

    System Maintenance Replacing a DP600 Power Supply The DP600 requires only one power supply; a second unit is provided for backup. If a  problem occurs with either of these power supplies, the power failure indicator LED on the  front panel flashes red (see Figure number for each of your DP600’s power supplies is identified by a label affixed to the right  side of each unit. Figure 3‐9 Figure 3-9 DP600 Front-Panel Power Supply Indicator To replace a DP600 power supply: Identify the failed unit in the rear panel by its nonilluminated LED, as shown in the  example in Figure Figure 3‐10 Figure 3-10 DP600 Failed Power Supply (Top Unit in Figure) 3‐9) and a warning alarm sounds. The Dolby catalog    Failed power supply red LED 3‐10. ...
  • Page 65: Figure 3-11 Loosen Thumbscrew On Failed Power Supply

    Press the red  disconnect the power cable on the failed power supply and loosen the unit’s  thumbscrew by turning it counterclockwise, as shown in Figure Figure 3‐11 Press Alarm Reset button 100–240Vac 3.0–1.25A 50/60Hz Figure 3-11 Loosen Thumbscrew on Failed Power Supply Press the failed power supply’s tab to the left while grasping its handle and pulling  the unit out of its slot (see Figure 3‐12 and Figure Figure 3‐12 Pull handle Pull handle Figure 3-12 Press on Tab and Pull Handle to Remove Failed Power Supply Dolby DP600 Program Optimizer Manual ®...
  • Page 66: Figure 3-13 Remove Failed Power Supply

    System Maintenance Figure 3‐13 Figure 3-13 Remove Failed Power Supply Position the replacement unit squarely within its slot and push it along the guiding  surface until it snaps into place, as shown in Figure Figure 3‐14 Figure 3-14 Install New Power Supply     3‐14. Dolby DP600 Program Optimizer Manual ®...
  • Page 67: Upgrading/Installing The Dp600 Software

    Tighten the thumbscrew by turning it clockwise and reconnect power, as shown in  Figure 3‐15. The replacement unit’s LED turns green and the front panel’s red LED turns off,  verifying that the new unit is functioning correctly. Figure 3‐15 Figure 3-15 New Power Supply Installed and AC Cable Reconnected Upgrading/Installing the DP600 Software The DP600 packing kit includes a DP600 Installation Software DVD. With this disc, you can  perform a clean installation or an upgrade of the DP600 software (if required). A clean  installation restores the DP600 to the factory settings, deleting all your network settings,  custom profiles, work orders and reports, bookmarks, and user login information.  Caution: An upgrade updates the software to the latest release, retaining all your network  settings, but deleting all custom profiles, work orders and reports, bookmarks,  and user login information. To perform an upgrade or a clean installation of the DP600 software: Be sure the provided keyboard is connected to one of the unit’s USB ports. Insert the DP600 Installation Software DVD in the CD/DVD drive, and reboot the  system. A message says that the software is already installed and displays the currently  installed version and the version on the DVD. It prompts you to either type upgrade (refresh) or press any key to start a clean installation. Press  to upgrade (refresh) or press any other key to start a clean installation. The upgrade or clean installation process begins. When the new software is completely  installed, you are prompted to press any key to reboot, and to remove the DVD. Dolby DP600 Program Optimizer Manual ®...
  • Page 68: Upgrading Licenses

    System Maintenance Press any key to reboot and remove the installation disc from the CD/DVD drive.  If the disc is still in the CD/DVD drive while rebooting, a clean installation begins. Although the touch screen was calibrated during the manufacturing process, you may  need to recalibrate. If the touch screen calibration setup appears, as shown in  Figure 3‐16, you need to follow steps a–d, below, within approximately 30 seconds.  If you do not proceed within this time period, the calibration screen disappears. If the  calibration setup does not appear, proceed directly to step d, to complete the upgrade  or clean installation. Figure 3‐16 Press target Figure 3-16 Calibration Setup Screen A small target appears at the upper left corner of the calibration setup, and a cross  appears at each of the other three corners. To calibrate the touch screen: Press the target at the upper left corner for a couple of seconds until it changes to  a cross. The cross at the upper right corner changes to a target.  b. Press the target at the upper right corner until it changes to a cross. Continue this procedure at the lower left corner and the lower right corner. When the calibration is complete, the DP600 Welcome! screen appears, providing  a checklist of things you need before you can configure the system, as shown in  Figure 2‐3.  d. If you performed an upgrade, you can just page through the screens to retain your  previous network settings. For clean installations, you must follow the  instructions in Section Upgrading Licenses If you have an  ADMIN transcoding and conversion or upmixing, see Upgrading Your License on page 109. Rebooting and Shutting Down If you have an ...
  • Page 69: Appendix A Setting Up A Shared Folder And Entering A Path

    Setting Up a Shared Folder For source and destination work order directories, you need to set up a shared folder for  all authorized users. The following instructions provide a high‐level example for creating  a shared folder on a Microsoft ® Dolby  DP600 Client application: 1. Create a login account on the Windows PC named  Create a folder in the root of your hard drive named 3. Copy content files into  4. Right‐click on the  Select the  Share this folder Click the  Permissions Click the  8. Be sure the  Location Enter dp600 10. Click the  Check Names 11. Click the  12. Be sure the permissions for the added user is set to  13. Click the  14.
  • Page 70: Entering A Path

    Setting Up a Shared Folder and Entering a Path Entering a Path When you add a work order, you need to enter the  hot folder) that you want to designate for processing. In addition, you need to enter the  path to the location where you want to save the processed files. You can enter  Destination and  Source Destination • Entering a URL • Browsing  • Selecting a bookmark The following sections describe each of these methods. Note: Supported file system protocols include FTP, SAMBA/CIFS, and SFTP. Entering a Source Path To enter a source path: Select  home The  Add Workorder In this example we’ll select a  Figure A‐1 Figure A-1 Add Workorder Screen...
  • Page 71: Entering A Url To Specify A Path

    Click on the  The  Enter Path Figure A‐2 Figure A-2 Enter Path Screen A.3.1 Entering a URL to Specify a Path To enter a URL: In the  Enter Path enter a  Username shown in Figure Note: Figure A‐3 Figure A-3 Type URL in Enter Path Screen Dolby DP600 Program Optimizer Manual ®...
  • Page 72: Browsing To A Location To Specify A Path

    Setting Up a Shared Folder and Entering a Path After entering a URL, click  Your URL appears in the  example in Figure If you click the the work order.  Note: Additional Settings Retry Delay described on pages 34 and 35. Figure A‐4 Figure A-4 URL Entered in Add Workorder Screen A.3.2 Browsing to a Location to Specify a Path To browse to a location: Click  browse Figure A‐5 Figure A-5...
  • Page 73: Figure A-6 Select Protocol Screen

    Figure A‐6 Figure A-6 Select Protocol Screen Select either  bottom of the screen. The    Enter User Credentials a Windows Share/SMB path). Figure A‐7 Figure A-7 Enter User Credentials Screen Enter a  Username screen, then click the right arrow at the bottom of the screen. The  Enter Server Details Enter a path in the  (for a Windows Share/SMB path), then click  Dolby DP600 Program Optimizer Manual ®    or  Windows Share/SMB FTP or SFTP  screen appears, as shown in the example in Figure  ...
  • Page 74: Figure A-8 Enter Server Details Screen

    Setting Up a Shared Folder and Entering a Path Figure A‐8 Figure A-8 Enter Server Details Screen The  Select File Share/SMB path). In this screen, you can select the file or folder you want to specify as  the path to your source files.  You can also bookmark a path by clicking a by clicking  , refresh the displayed path by clicking  directory by clicking  Figure A‐9 Figure A-9 Select File Screen Click on the desired file or folder, then click  Your path appears in the  Click  in the   E  screen appears, as shown in the example in Figure dd bookmark  ...
  • Page 75: Figure A-10 Create Bookmark

    Your path appears in the  If you want to create a bookmark, click on the desired file or folder in the  screen, click  Figure A‐10 Figure A-10 Create Bookmark The  Add Bookmark displayed. Enter a unique name for your bookmark in the  Figure A‐11, then click  Your bookmark appears in the  as shown in the example in Figure drop‐down menu (in the a path, as shown in Figure Figure A‐11 Figure A-11 Add Bookmark Screen Dolby DP600 Program Optimizer Manual ®  screen, as shown earlier in Figure Add Workorder , and then click  add bookmark    screen appears with the bookmark’s file/folder name and URL   pane at the left side of the  Bookmarks A‐10. It also appears in the ...
  • Page 76: Selecting A Bookmark To Specify A Path

    Setting Up a Shared Folder and Entering a Path A.3.3 Selecting a Bookmark to Specify a Path To select a bookmark: Click the  Bookmarks All the bookmarks you previously added in the  drop‐down menu. a bookmark Select the desired bookmark in the drop‐down menu to specify a path, then click  as shown in Figure Figure A‐12 Figure A-12 Selecting a Bookmark The selected bookmark’s path appears in the  as shown in the example in Figure Figure A‐13 Figure A-13 Bookmark Entered in Source Field  field in the ...
  • Page 77: Entering A Destination Path

    Entering a Destination Path To enter a Destination path: Click the  Destination The  Enter Path in Figure A‐2.  Use any of the methods described for entering a source path to enter the destination  path, then click  Send Us Your Feedback If you have a question or a comment regarding this appendix, send us an email. Dolby DP600 Program Optimizer Manual ®  field in the  Add Workorder screen appears. This screen is identical to the   (see Section A.3). Entering a Destination Path  screen. screen shown  Enter Path...
  • Page 79: Appendix B Dp600 Program Optimizer Detailed Profile Descriptions

    Understanding DP600 Profiles A DP600 profile defines a set of actions and processes on a specific type of source file,  which includes specific actions on any or all audio data types and the configurations  contained within them (if applicable). Following are some important points to remember regarding DP600 profiles: Note: DP600 profile information is updated periodically. For the latest information on  DP600 profiles, please go to the DP600 area on  The DP600 profiles and processes always expect and are capable of providing  multichannel  file: Left, Right, Center, LFE, Left Surround, Right Surround per SMPTE 320M Table 2.  (Failure to adhere to this rule results in unintended behavior.) All DP600 profiles and processes that expect and/or provide multichannel or  multiprogram audio must be contained in a single file (that is, all channels are  interleaved). For this reason, the DP600 does not support discrete (single‐channel  monophonic) input files that (together) comprise a complete multichannel audio  program. However, the DP600 does support single‐channel monophonic  files that do represent a complete audio program.  For any DP600 profiles that expect a PCM  chunk  is optional. In cases where the metadata chunk is not present, the DP600  processes utilize a default set of metadata parameters, except where noted in the  profile descriptions provided on the following pages in this appendix. For this reason,  the Dolby metadata chunk is required to obtain full control over any or all Dolby  metadata parameters (on a file‐by‐file basis). All decoder‐related profiles that output PCM  (unless noted otherwise), except for Dolby E decoding, which defaults to 24‐bit  sample depths. Unless otherwise noted, many files processed by the DP600 (that is, the output files)  contain the text string  example, a source file name such as  DP600_test-corrected.mpg  The Dolby metadata chunk specification is available upon request. Dolby DP600 Program Optimizer Manual ®...
  • Page 80 DP600 Program Optimizer Detailed Profile Descriptions Profiles that are capable of processing source files into multiple output files (for  example, a 5.1+2–channel Dolby E decode) name each program as follows: Program 1:  source_filename-sequence[1]-program[1]-corrected.wav Program 2:  source_filename-sequence[1]-program[2]-corrected.wav Note: -corrected All profiles referencing MPEG‐2 transport streams assume that only a single program  is present. For   files larger than 4 GB, the DP600 supports only the European Broadcasting  .wav Union (EBU) RF64 BWF‐compatible multichannel file format. (An RF64 format file  may also be termed as a Multichannel Broadcast WAV Format, or MBWF, file). All 20‐bit Dolby E data must be formatted per SMPTE 337M and wrapped in a 24‐bit   file container before transferring it to the DP600 for processing (this excludes any  .wav Dolby E data contained within an MPEG transport stream, MPEG program stream, or  GXF file). 10. All 16‐bit Dolby E data must be formatted per SMPTE 337M and wrapped in a 16‐bit   file container before transferring it to the DP600 for processing (this excludes any  .wav Dolby E data contained within an MPEG transport stream, MPEG program stream, or  GXF file). Note: 16‐bit Dolby E data is supported only when used with specific profiles. For more  information, see the profile descriptions in Section Note: The  .aiff 4294967296 bytes (that is., 4.29 GB). The following DP600 profiles are described in Section Profile: AAC_AAC‐1 ‐> Dolby Pulse (HE AAC) Speech‐Based Loudness Correction via ...
  • Page 81 Understanding DP600 Profiles Profile: AC3_EC3‐1 ‐> Dolby Digital (AC‐3) to Dolby Digital Plus (E‐AC‐3) Transcode on  page 75 Profile: AC3_PCM‐1 ‐> Dolby Digital (AC‐3) to .wav Extensible PCM (with Metadata  Chunk) on page 75 Profile: AC3_PCM‐2 ‐> Dolby Digital (AC‐3) to .wav Extensible PCM (with Metadata  Chunk) on page 75 Profile: AIFF/E_AIFF/E‐1 ‐> AIFF File with Dolby E or Dolby Digital (Formatted as per  SMPTE 337M) Loudness Correction on page 76 Profile: AIFF/E_PCM‐1 ‐> AIFF File with Dolby E (Formatted as per SMPTE 337M) to AIFF  (PCM) with Speech‐based Loudness Normalization to –27 LKFS on page 76 Profile: AIFF/E_STITCH_AC3‐1 ‐> Dolby Digital (AC‐3) on page 77 Profile: AIFF/PCM_PCM‐1 ‐> AIFF PCM File Loudness Normalization to –27 LKFS on  page 77 Profile: EC3_EC3‐1 ‐> Dolby Digital Plus (.ec3) Speech‐Based Loudness Correction on  page 78 Profile: EC3_PCM‐1 ‐> Dolby Digital Plus (E‐AC‐3) to .wav Extensible PCM (with  Metadata Chunk) on page 78 Profile: EC3_PCM‐2 ‐> Dolby Digital Plus (E‐AC‐3) to .wav Extensible PCM (with  Metadata Chunk) on page 78 Profile: GXF_AC3‐1 ‐> GXF File with Dolby E Transcoded to Dolby Digital .ac3 Files on  page 79 Profile: GXF_GXF‐1 ‐> GXF File Dolby E dialnorm Correction on page 79 Profile: GXF_GXF‐2‐>GXF File Dolby E dialnorm Correction and PCM Normalization to  –27 LKFS on page 79 Profile: GXF_GXF‐3 ‐> GXF File Dolby E and PCM Normalized to –27 LKFS on page 80 Profile: GXF_GXF‐4 ‐> GXF File with PCM Tracks (Only) Normalized to –27 LKFS on ...
  • Page 82 DP600 Program Optimizer Detailed Profile Descriptions Profile: MXF_MXF ‐> Dolby E Dialogue Normalization Correction and Normalize  Loudness to –27LKFS for Two‐Channel PCM on page 82 Profile: Omneon_Omneon ‐> Omneon Dolby E Dialogue Normalization Correction &  Normalize Loudness to ‐27 LKFS for Two‐Channel PCM on page 83 Profile: PCM_AAC‐1 ‐> .wav PCM to Dolby Pulse (HE AAC) Encoding with Speech‐Based  Loudness Estimation and Dialogue Normalization Provisioning on page 84 Profile: PCM_AC3‐1 ‐> .wav PCM to Dolby Digital (AC‐3) Encoding with Speech‐Based  Loudness Estimation and dialnorm Provisioning on page 84 Profile: PCM_AIFF/E‐1 ‐> Multichannel AIFF PCM File to NTSC (29.97 Hz) Dolby E  Encoding on page 84 Profile: PCM_AIFF/E‐2 ‐> Multichannel AIFF PCM File to PAL (25 Hz) Dolby E Encoding   on page 85 Profile: PCM_DOWNMIX ‐> Multichannel PCM (.wav) Dolby Pro Logic II Downmix on  page 85 Profile: PCM_EC3‐1 ‐> .wav PCM to Dolby Digital Plus (E‐AC‐3) Encoding  on page 85 Profile: PCM_MPII‐1 ‐> .wav PCM to MPEG‐1 LII Encoding  on page 86 Profile: PCM_PCM‐1 ‐> .wav PCM File Speech‐Based Loudness Normalization to –27 LKFS  on page 86 Profile: PCM_PCM‐2 ‐> .wav PCM File Loudness Estimation and Dolby Metadata Chunk  Generation on page 86 Profile: PCM_PCM‐3 ‐> .wav PCM File Loudness Normalization to –27 LKFS and Dolby  Metadata Chunk Generation on page 87 Profile: PCM_UPMIX ‐> .wav PCM file Upmixing to Multichannel PCM (wav)  on page 87 Profile: PCM_WAV/E‐1 ‐> .wav PCM File to NTSC (29.97 Hz) Dolby E Encoding  on page 87 Profile: PCM_WAV/E‐2 ‐> .wav PCM File to NTSC (25 Hz) Dolby E Encoding  on page 88...
  • Page 83 Understanding DP600 Profiles Profile: TS_TS‐2 ‐> MPEG‐2 Transport Stream MPEG‐1 LII Loudness Normalization and  Dolby Digital (AC‐3) and Dolby Pulse (HE AAC) Dialnorm Correction on page 90 Profile: TS_TS‐3 ‐> MPEG‐2 Transport Stream MPEG‐1 Layer II Loudness Normalization  on page 91 Profile: TS_TS‐4 ‐> MPEG‐2 Transport Stream with MPEG‐1 LII Loudness Normalization  and Transcoding to AC‐3 with the Correct dialnorm Value on page 91 Profile: TS_TS‐5 ‐> MPEG‐2 Transport Stream with Dolby Digital (AC‐3) Transcode to  Dolby Digital Plus (E‐AC‐3) on page 91 Profile: TS_TS‐7 ‐> MPEG‐2 Transport Stream with MPEG‐1 L11 Loudness Normalization  and Transcoding to Dolby Pulse (HE AAC) with the Correct Dialogue Normalization Value  on page 92 Profile TS_TS‐8 ‐> MPEG‐2 Transport Stream with Dolby Digital (AC‐3) Loudness  Correction and Transcoding to Dolby Pulse (HE AAC) on page 92 Profile: WAV/AC3_PCM‐1 ‐> Dolby Digital (337M Formatted .wav) to .wav Extensible  PCM (with Metadata Chunk)  on page 92 Profile: WAV/E_AC3‐1 ‐> Dolby E (337M Formatted .wav) to Dolby Digital (AC‐3) File on  page 93 Profile: WAV/E_AC3‐2 ‐> Dolby E (337M Formatted .wav) to Dolby Digital (AC‐3) File  (AC‐3 dialnorm Value Automatically Provisioned to the Correct Value) on page 93 Profile: WAV/E_AC3‐3 ‐> Dolby E (337M Formatted .wav) to Dolby Digital (AC‐3) File  on  page 94 Profile: WAV/E_AC3‐4 ‐> Dolby E (337M .wav) to Dolby Digital (.ac3) with Adaptive .wav  (PCM) Upmix on page 94 Profile: WAV/E_EC3‐1 ‐> Dolby E (337M Formatted .wav) to Dolby Digital Plus (E‐AC‐3)  File  on page 95 Profile: WAV/E_PCM‐1 ‐> Dolby E (337M Formatted .wav) to .wav Extensible PCM (with ...
  • Page 84 DP600 Program Optimizer Detailed Profile Descriptions Profile: WAV/E_STITCH_AC3‐2 ‐> Adaptive PCM/Dolby E (337M .wav) to Dolby Digital  (.ac3) on page 99 Profile: WAV/E_WAV/AC3‐1 ‐> Dolby E (337M Formatted .wav) to Dolby Digital (AC‐3)  (16‐Bit 337M/340M Formatted .wav)  on page 99 Profile: WAV/E_WAV/AC3‐2 ‐> Dolby E (337M Formatted .wav) to Dolby Digital (AC‐3)  (24‐bit 337M/340M Formatted .wav)  on page 100 Profile: WAV/E_WAV/E‐1 ‐> Dolby E (337M .wav) Loudness Correct and Reencode on  page 100 Profile: WAV/E_WAV/E‐2 ‐> Dolby E (337M .wav) Loudness Correct via Metadata on  page 100 Dolby DP600 Program Optimizer Manual ®...
  • Page 85: Profile Descriptions

    Profile Descriptions Following are descriptions of all the current DP600 profiles. Profiles that perform  encoding, decoding, transcoding, and conversion functions require the DP600‐C.  Profiles that perform upmixing require the DP600 upmixing upgrade. Note: DP600 profiles are updated periodically. For the latest DP600 profiles, please go to  the DP600 area on  Profile: AAC_AAC-1 -> Dolby Pulse (HE AAC) Speech-Based Loudness Correction via Metadata Process Loudness Estimate and Correct .aac File Measurement Type  Speech-based ITU -R Profile AAC_AAC‐1 corrects the metadata values (  file if the measured dialogue loudness is greater then the orginal dialogue  .aac normalization value by  Profile: AAC_PCM-1 -> Dolby Pulse (HE AAC) to .wav Extensible PCM (with Metadata Chunk) Process ->...
  • Page 86 DP600 Program Optimizer Detailed Profile Descriptions Profile: AC3_AAC-1 -> Dolby Digital Loudness Correction and Transcoding to Dolby Pulse Process Loudness Estimate and Correct .ac3 File Measurement Type  Speech-based ITU -R Profile AC3_AAC‐1 corrects the metadata values ( the   file if the measured dialogue loudness is greater than the original dialogue  .ac3 normalization by  set to ADTS MP2 and encoded output data rates are adaptively provisioned per broadcast  presets. Profile: AC3_AC3-1 -> Dolby Digital (AC-3) Speech-Based Loudness Correction via Metadata Process ...
  • Page 87 Profile: AC3_EC3-1 -> Dolby Digital (AC-3) to Dolby Digital Plus (E-AC-3) Transcode Process  Dolby Digital (AC-3) to Dolby Digital Plus (E AC-3) Transcoder .ac3 file Profile AC3_EC3‐1 directly transcodes an  Digital Plus file type. All metadata is preserved in this profile, except for the output data  rate. For 1/0 (mono) sources, the output data rate is 96 kbps. For 2/0 (stereo) sources, the  output data rate is 128 kbps. For 2/1 sources, the output data rate is 160 kbps. For 3/2 or 3/2L  sources, the output data rate is 224 kbps. Profile: AC3_PCM-1 -> Dolby Digital (AC-3) to .wav Extensible PCM (with Metadata Chunk) Process ...
  • Page 88 DP600 Program Optimizer Detailed Profile Descriptions Profile: AIFF/E_AIFF/E-1 -> AIFF File with Dolby E or Dolby Digital (Formatted as per SMPTE 337M) Loudness Correction AIFF w/ Estimation and dialnorm correction for Dolby SMPTE 337M formatted Dolby E or Dolby Digital Profile AIFF/E_AIFF/E‐1 performs speech‐based ITU‐R BS. 1770‐1 loudness correction on ...
  • Page 89 Profile: AIFF/E_STITCH_AC3-1 -> Dolby Digital (AC-3) Process  Transcode Dolby E and /or encode 2-channel PCM to Dolby Digital (AC-3) with seamless 2/0 <-> 3/2L metadata transitions AIFF w/ SMPTE 337M formatted Dolby E NOTE: All programs and sequences are normalized to -27 LKFS w/ and/or 2-channel PCM AIFF Measurement Type ...
  • Page 90 DP600 Program Optimizer Detailed Profile Descriptions Profile: EC3_EC3-1 -> Dolby Digital Plus (.ec3) Speech-Based Loudness Correction .ec3 File Dolby Digital Plus (E AC-3) Single independent substream only Profile EC_EC3‐1 provides ITU‐R BS.1770‐1 speech‐based dialnorm correction within  Dolby Digital Plus ( dynrng, and  compr the original dialogue normalization value by ±1 dB. Note: This profile supports only a single independent Dolby Digital Plus substream (up  to 5.1 channels). Profile: EC3_PCM-1 -> Dolby Digital Plus (E-AC-3) to .wav Extensible PCM (with Metadata Chunk) Process ...
  • Page 91 Profile: GXF_AC3-1 -> GXF File with Dolby E Transcoded to Dolby Digital .ac3 Files Process  Dolby E decode  Speech-based Loudness Estimation for all Dolby E programs Dolby Digital encode for each E program with GXF File with Dolby E Measurement Type ...
  • Page 92 DP600 Program Optimizer Detailed Profile Descriptions Profile: GXF_GXF-3 -> GXF File Dolby E and PCM Normalized to –27 LKFS Estimation and normalization to -27 LKFS for GXF File with Dolby E & PCM Tracks Measurement Type  Speech-based Profile GXF_GXF‐3 normalizes all Dolby E programs and PCM audio tracks contained  within pairs of GXF tracks (media type 18 as defined in Table 5 of SMPTE 360M‐2004),  resulting in a speech level normalized to –27 LKFS.
  • Page 93 Profile: GXF_GXF-6 -> GXF File 5.1+2+2 PCM Normalization to –27 LKFS Estimation and normalization to -27 LKFS for GXF File with a 5.1 and two +2 PCM programs Only Measurement Type  Speech-based Profile GXF_GXF‐6 normalizes a 5.1‐channel PCM and two two‐channel PCM programs  contained in the GXF file, resulting in a speech level normalized to –27 LKFS for both. Note  that tracks 1–6 (pairs 1–3) are treated as a single 5.1 program, and tracks 7 and 8 (pair 4)  and 9 and 10 (pair 5) are treated as two‐channel programs. Other configurations are not  supported by this profile. Profile: GXF_GXF-7 -> GXF File PCM Tracks 1–4 Normalization to –27 LKFS GXF File with PCM on Tracks ½...
  • Page 94 DP600 Program Optimizer Detailed Profile Descriptions Profile: GXF_PCM-1 -> GXF File with Dolby E to Multiprogram .wav Extensible File with Dolby Metadata Chunk Containing the Correct dialnorm Value Process  Dolby E decode  Speech-based Loudness Estimation for all Dolby E programs GXF File with Dolby E Profile GXF_PCM‐1 decodes all Dolby E streams within a GXF file to a single ...
  • Page 95 Profile: Omneon_Omneon -> Omneon Dolby E Dialogue Normalization Correction & Normalize Loudness to -27 LKFS for Two-Channel PCM Omneon AIFF or WAVE audio essence w / PCM and/or Dolby E Profile Omneon_Omneon provides both dialnorm correction for Dolby E (all programs)  and speech‐based normalization for any two‐channel PCM found within Omneon program files. Omneon MXF and QuickTime essence are adaptively supported. Two‐channel PCM audio essence is normalized to –27  LKFS.  Note: This profile does not exclusively require the presence of both Dolby E and  two‐channel PCM audio tracks. As a result, the DP600 can dynamically adapt to  either one or both of the essence types found on your Omneon server. Note: This profile directly supports workflows that utilize either the Omneon ...
  • Page 96 DP600 Program Optimizer Detailed Profile Descriptions Profile: PCM_AAC-1 -> .wav PCM to Dolby Pulse (HE AAC) Encoding with Speech-Based Loudness Estimation and Dialogue Normalization Provisioning Process  PCM to Dolby Pulse (HE-AAC) WAVE Note: Multichannel WAVE PCM Files are supported Profile PCM_AAC‐1 encodes PCM ...
  • Page 97 Profile: PCM_AIFF/E-2 -> Multichannel AIFF PCM File to PAL (25 Hz) Dolby E Encoding AIFF w/ PCM Profile PCM_AIFF/E‐2 encodes a multichannel PCM  output   file contains 25 Hz Dolby E formatted per SMPTE 337M (20‐bit mode). Note that  .aiff the output   file (which contains the 20‐bit Dolby E data) utilizes 24‐bit audio sample  .aiff words. Therefore, each 20‐bit Dolby E data word is placed in the twenty most significant  bits of each   audio sample word. Also note that only source files containing either six or  .aiff eight channels are supported. As a result, a two‐channel source file generates an error  condition and is not processed. Profile: PCM_DOWNMIX -> Multichannel PCM (.wav) Dolby Pro Logic II Downmix Process ...
  • Page 98 DP600 Program Optimizer Detailed Profile Descriptions Profile: PCM_MPII-1 -> .wav PCM to MPEG-1 LII Encoding WAVE Process  PCM to MPEG-1 Layer II Profile PCM_MPII‐1 encodes PCM  sources are accepted. Profile: PCM_PCM-1 -> .wav PCM File Speech-Based Loudness Normalization to –27 LKFS Process Speech -based Loudness Estimation and Normalize to -27 LKFS WAVE Measurement Type ...
  • Page 99 Profile: PCM_PCM-3 -> .wav PCM File Loudness Normalization to –27 LKFS and Dolby Metadata Chunk Generation Process Speech -based Loudness Estimation and Normalize to -27 LKFS WAVE & Dolby Metadata chunk generation Measurement Type  Speech-based Profile PCM_PCM‐3 normalizes the loudness of the file, resulting in a long‐term speech  level of –27 LKFS. In addition, it automatically generates a Dolby metadata chunk with the  proper dialogue normalization value and RF/Line mode compression profiles set to Film  Standard, while the remaining Dolby metadata parameters are set to default values. Note  that multichannel ...
  • Page 100 DP600 Program Optimizer Detailed Profile Descriptions Profile: PCM_WAV/E-2 -> .wav PCM File to NTSC (25 Hz) Dolby E Encoding Process  Dolby E Encoding (25Hz) WAVE PCM Dolby E Program Config  5.1+2 or 5.1 only Profile PCM_WAV/E‐2 encodes PCM  contains 25 Hz Dolby E formatted per SMPTE 337M (20‐bit mode). Note that the output   file (which contains the 20‐bit Dolby E data) utilizes 24‐bit audio sample words.  .wav Therefore, each 20‐bit Dolby E data word is placed in the 20 most significant bits of each ...
  • Page 101 Profile: PS_PCM-1 -> MPEG-2 Program Stream Dolby E Decode to Multiprogram .wav Extensible File with Dolby Metadata Chunk (dialnorm set correctly) MPEG-2 Program Stream with Dolby E Profile PS_PCM‐1 decodes all Dolby E streams within an MPEG‐2 program stream to a  single multiprogram PCM  dialogue normalization value for each program in the audio metadata chunk is set  correctly. Also note that this profile assumes the MPEG‐2 program stream file was  generated by an Avid/Pinnacle Systems Profile: PS_PS-1 -> MPEG-2 Program Stream with Dolby Digital (AC-3) Dialnorm Correction MPEG-2 Program Stream with Dolby Digital (AC-3)
  • Page 102 DP600 Program Optimizer Detailed Profile Descriptions Profile: PS_PS-3 -> MPEG-2 Program Stream with Dolby E Dialnorm Correction and MPEG-1 LII Normalization Process Speech -based Loudness Estimation and dialnorm correction (Dolby E) MPEG-2 Program & Layer II normalized to -27 LKFS Stream with Dolby E &...
  • Page 103 Profile: TS_TS-3 -> MPEG-2 Transport Stream MPEG-1 Layer II Loudness Normalization MPEG-2 Transport Stream with MPEG-1 Measurement Type  Speech-based Layer II Profile TS_TS‐3 normalizes the loudness of all MPEG‐1 LII elementary streams contained  within the MPEG‐2 transport stream file. This process scales the loudness, resulting in a  dialogue loudness of –24 LKFS in the output file.  Profile: TS_TS-4 -> MPEG-2 Transport Stream with MPEG-1 LII Loudness Normalization and Transcoding to AC-3 with the Correct dialnorm Value MPEG-2 Transport Stream with a single MPEG-1 Layer II ES...
  • Page 104 DP600 Program Optimizer Detailed Profile Descriptions Profile: TS_TS-7 -> MPEG-2 Transport Stream with MPEG-1 L11 Loudness Normalization and Transcoding to Dolby Pulse (HE AAC) with the Correct Dialogue Normalization Value Process Speech -based Loudness Normalization to -24 LKFS MPEG-2 Transport for MPEG-1 Layer II Dolby Pulse (HE-AAC) Stream MPEG-1 Measurement Type ...
  • Page 105 Profile: WAV/E_AC3-1 -> Dolby E (337M Formatted .wav) to Dolby Digital (AC-3) File WAVE w/ Process  Dolby E to Dolby Digital (AC-3) SMPTE 337M formatted Dolby E Profile WAV/E_AC3‐1 transcodes a 5.1 or a 5.1+2 Dolby E stream/file formatted per SMPTE  337M wrapped in a  automatically provisioned at either 384 kbps (for six‐channel audio) or 192 kbps (for  two‐channel audio). All remaining metadata parameters follow the AC‐3 metadata for  each program contained in the Dolby E data file/stream. Note that only files containing  either 5.1 or 5.1+2 Dolby E data are supported. Profile: WAV/E_AC3-2 -> Dolby E (337M Formatted .wav) to Dolby Digital (AC-3) File (AC-3 dialnorm Value Automatically Provisioned to the Correct Value) Process ...
  • Page 106 DP600 Program Optimizer Detailed Profile Descriptions Profile: WAV/E_AC3-3 -> Dolby E (337M Formatted .wav) to Dolby Digital (AC-3) File Process  Dolby E to Dolby Digital (AC-3) WAVE w/ Measurement Type  Speech-based SMPTE 337M formatted Dolby E Dialnorm Metadata Correction only Profile WAV/E_AC3‐3 transcodes a 5.1 or a 5.1+2 Dolby E stream/file formatted per SMPTE ...
  • Page 107 Profile: WAV/E_EC3-1 -> Dolby E (337M Formatted .wav) to Dolby Digital Plus (E-AC-3) File WAVE w/ Process  Dolby E to Dolby Digital Plus SMPTE 337M formatted Dolby E Profile WAV/E_EC3‐1 transcodes a Dolby E stream/file formatted per SMPTE 337M  wrapped in a  .wav provisioned at either 192 kbps (for six‐channel audio) or 96 kbps (for two‐channel audio).  All E‐AC‐3 metadata parameters are provisioned from the AC‐3 metadata within each  program contained in the Dolby E data file/stream. Note that only files containing 5.1 or  5.1+2 Dolby E data are supported. Profile: WAV/E_PCM-1 -> Dolby E (337M Formatted .wav) to .wav Extensible PCM (with Metadata Chunk) W AVE w/ Measurement Type ...
  • Page 108 DP600 Program Optimizer Detailed Profile Descriptions Profile: WAV/MP2_WAV/MP2-1 -> WAVE (w/ MPEG-1 LII only) Loudness Correction to -24 LKFS Estimation and Normalize to -24 LKFS W AVE w/ MPEG LII (fmt MPEG 0x0050 ) Measurement Type  Speech-based Profile WAV/MP2_WAV/MP2‐1 provides ITU‐R BS.1770‐1 speech‐based loudness  normalization within MPEG‐1 LII audio files carried in a  Note: MPEG‐1 LII audio essence must be properly signaled via the ...
  • Page 109 Profile: WAV/E_STITCH_AAC-1 -> Adaptive PCM/Dolby E (wave 337M) Frame Align, Stitch to Dolby Pulse (HE AAC) WAVE w/ Process  Dolby E decode and /or 2-channel SMPTE 337M formatted Dolby E PCM to seamless Dolby Pulse (HE-AAC) with and/or 2-channel 2/0 <->...
  • Page 110 DP600 Program Optimizer Detailed Profile Descriptions Profile: WAV/E_STITCH_AC3-1 -> Adaptive PCM/Dolby E (337M .wav) to Dolby Digital (.ac3) W AVE w/ SMPTE 337M formatted Dolby E and/or 2-channel PCM W AVE Profile WAV/E_STITCH_AC3‐1 transcodes 5.1 or a 5.1+2 20‐bit  SMPTE 337M wrapped in a 24‐bit . rates are automatically provisioned as six‐channel and two‐channel programs at 384 kbps.  Any two‐channel PCM programming (that is, not Dolby E data) detected within the source  file (that is, within the Dolby E 337M  .wav with an   of 2/0 and seamlessly stitched (in the proper sequence) into the final . acmod (that is, along with the 5.1 [3/2L] ...
  • Page 111 Profile: WAV/E_STITCH_AC3-2 -> Adaptive PCM/Dolby E (337M .wav) to Dolby Digital (.ac3) W AVE w/ Process  Dolby E and/or 2-channel PCM SMPTE 337M formatted Dolby E with 2/0 <-> 3/2L metadata transitions and/or 2-channel PCM W AVE Profile WAV/E_STITCH_AC3‐2 transcodes a 5.1 16‐bit Dolby E file (formatted per SMPTE  337M wrapped in a 16‐bit . is automatically provisioned to 384 kbps. Any two‐channel PCM programming (that is, not ...
  • Page 112 DP600 Program Optimizer Detailed Profile Descriptions Profile: WAV/E_WAV/AC3-2 -> Dolby E (337M Formatted .wav) to Dolby Digital (AC-3) (24-bit 337M/340M Formatted .wav) Process  Dolby E to Dolby Digital (AC-3 ) W AVE w/ Measurement Type  Speech-based SMPTE 337 M formatted Dolby E Dialnorm Metadata Correction Profile WAV/E_WAV/AC3‐2 encodes a Dolby E file formatted per SMPTE 337M wrapped ...
  • Page 113: Appendix C System Administrator Functions

    This chapter is for DP600 system administrators only. Before users can operate the system,  a system administrator must set up user IDs and passwords, which specify the respective  access level for each user. Access Levels There are three DP600 access levels:  • VIEWER default : password required • USER : password required • ADMIN C.1.1 Admin Level The   level is intended only for system administrators. With this level of access, a  ADMIN system administrator can perform all DP600 functions.  C.1.2 User Level The   level is intended for DP600 operators. Users can view information and system  USER status, and set up work orders and generate reports, but cannot cancel or edit work orders  or use the  config C.1.3 Viewer (default) Level At the   ( VIEWER operate the system. This is the default level of access and does not require a password.
  • Page 114: Setting Up An Admin Level Password

    Setting Up an Admin Level Password Before setting up  the system. You can perform this function using the DP600 touch screen user interface or  the DP600 Client. You or any other user can log in to the touch screen and the Client with  the same  USER their respective functions. To set up your  Press or click the lock icon at the upper right side of the  and date), as shown in Figure Figure C‐1 Figure C-1 Press or Click the Lock Icon to Display the Login Screen The    Login User Figure C‐2 Figure C-2 Login User Screen  IDs, you need to add a new  USER  ID, but all users must log in to each of these interfaces separately to access ...
  • Page 115: Figure C-3 Press Or Click Config In System Screen

    Press or click  , and click  admin The lock icon  now accessible at the  date. After ten minutes of idle time, the system returns to the locked position, but you  should press  mode. Press or click system  The   screen appears, as shown in Figure system Figure C‐3 Press or click config Figure C-3 Press or Click Config in System Screen Press or click  The   screen appears, as shown in Figure config Figure C‐4 Press or click users Figure C-4 Press or Click Users in Config Screen Dolby DP600 Program Optimizer Manual ®...
  • Page 116: Figure C-5 Press Or Click + In Add And Remove Users Screen

    Press or click  The add ( Figure C‐5 Figure C-5 Press or Click + in Add and Remove Users Screen Press or click  The  Enter New User Press or click the  Figure C‐6 Figure C-6 Add Admin Level User Press or click the  and write it down in a safe place.  Later, you will delete the default  of your new password. Press or click the  Your new  IDs using this same procedure. ADMIN 10. Click the lock icon to display the  11. Click  logout 12.
  • Page 117: Adding Users

    14. Press or click the default  15. Press or click remove ( The default ID no longer appears in the list of users.  Adding Users To add a  level ID follow the same procedure, as described in Section USER an   ID), but select  ADMIN Deleting IDs and Passwords To delete a  USER click remove ( Reconfiguring the System To reconfigure the system, you need to log in with an  Caution: Before changing the network settings, be sure you’re connected to a network. To reconfigure the  Log in with your  Click or press  Figure C‐7 Figure C-7 System Screen Click or press  Dolby DP600 Program Optimizer Manual ®...
  • Page 118: Figure C-8 Config Screen

    Figure C‐8 Figure C-8 Config Screen Click or press  The  network shown in Figure for the  undo  button. If you click or press the  cancel in this screen only. After changing your network settings, you are prompted to  manually reboot the system.  Figure C‐9 undo button Figure C-9 Network Screen Reconfiguring the Date & Time Settings To reconfigure the  Press  config The  config your  date & time Press  date & time A prompt appears, informing you that the system will automatically reboot and return ...
  • Page 119: Figure C-10 Date & Time Reboot Screen

    Figure C‐10 Figure C-10 Date & Time Reboot Screen Press   to return to the commissioning application, and page through the screens  until you display the  This screen is similar to the  Change the date and time settings, then page through the screens and press the  button. The system automatically reboots with your new settings. Dolby DP600 Program Optimizer Manual ®   settings. date & time screen in Figure date & time Reconfiguring the System 2‐7.    finish...
  • Page 120: Figure C-11 Calibrate Button

    Recalibrating the Touch Screen Your DP600 touch screen was calibrated during the manufacturing process, but you may  need to perform a recalibration if you experience any irregularities.  To recalibrate the touch screen: Press  config The  config the touch screen, if required.  Press  touchscreen The  calibrate Figure C‐11 Figure C-11 Calibrate Button Press the  calibrate The calibration setup appears with a small target at the upper left corner, and a cross  at each of the other three corners, as shown in Figure screen, proceed as follows within approximately thirty seconds from the time it  appears. If you do not proceed within this time period, the calibration screen  disappears. • Press the target at the upper left corner for a couple of seconds until it changes to  a cross.  The cross at the upper right corner changes to a target.  • Press the target at the upper right corner until it changes to a cross. • Continue the above procedure at the lower left corner and the lower right corner. When the calibration is complete, the  move on to any other screen, as required. Figure C‐12 Press target Figure C-12 Calibration Setup Screen  in the ...
  • Page 121: Figure C-13 Upgrade Screen

    Upgrading Your License To upgrade your license from a DP600 to a DP600‐C (to allow encoding, decoding,  transcoding, conversion, and other features), or to upgrade for upmixing, use the touch  screen as follows: Press  upgrade The  upgrade your license from this screen, but not the DP600 software.  Figure C‐13 Figure C-13 Upgrade Screen Press the  license The  License Upgrade to the  License follow the same procedure (beginning on page 17) to upgrade your license. Figure C‐14 Figure C-14 License Upgrade Screen Dolby DP600 Program Optimizer Manual ®   in the    screen. system  screen appears, as shown in Figure  ...
  • Page 122: Figure C-15 Maintenance Screen

    Maintaining Work Orders To maintain your work orders: Press or click  The  maintenance Figure C‐15 Figure C-15 Maintenance Screen Archiving Work Order Reports Manually To archive your work order report files, press or click  screen. The  Report Archive Criteria like the  Filter Workorder Criteria specify which report files to archive, based on your archiving criteria.  This screen adds two other options,  functions in the same way as entering a path for work order files, described earlier  location on page 32 (and in greater detail in Section A.2 and Section the path where you want to archive your report files.  additional option for deleting only loudness reports. Figure C‐16 Figure C-16 Report Archive Criteria Screen  ...
  • Page 123: Figure C-17 Workorder Deletion Criteria Screen

    Deleting Work Orders Manually To delete your work order files, press or click  The  Workorder Deletion Criteria functions in the same way as the  In this case, you specify which work order files to delete, based on your deletion criteria.  Figure C‐17 Figure C-17 Workorder Deletion Criteria Screen Dolby DP600 Program Optimizer Manual ® delete  screen appears, as shown in Figure   Workorder Filter Criteria   Reconfiguring the System   in the   screen. maintenance C‐17. This screen   screen, shown in Figure 2‐41.
  • Page 124: Figure C-18 Automation Screen

    Archiving Reports and Deleting Work Orders Automatically To archive work order reports and delete work orders automatically:  Press or click  The  automation Figure C‐18 Figure C-18 Automation Screen Press or click  The  Enter New Automation Criteria functions like the  Figure C‐16 and Figure and work orders to delete on a recurring basis, based on the entered criteria. This screen  also provides additional criteria: archive or delete Workorder Threshold ( configure the system for the first time deletes reports and the associated work orders from the DP600 from DP600 ( Figure C‐19 Figure C-19 Enter New Automation Criteria Screen  ...
  • Page 125: Figure C-20 Automation Screen After Setting Up Criteria

    Enter the desired automation criteria, then click  Your specified automation jobs appear in the  example in Figure Figure C‐20 Figure C-20 Automation Screen After Setting Up Criteria In addition to the  right margin: : Displays a list of logs, indicating the date, time, and success or failure of the  • logs selected automation job, as shown in the examples in Figure Figure C‐23.  : Displays the  • update job. In this screen you can edit the respective job’s automation criteria, as shown in  the examples in Figure : Deletes the selected automation job. • delete Dolby DP600 Program Optimizer Manual ® C‐20.    button, this screen also provides three additional options in the  Update Automation Criteria C‐21.
  • Page 126: Figure C-21 Update Automation Criteria Screens

    Figure C‐21 Figure C-21 Update Automation Criteria Screens Figure C‐22 Figure C-22 Logs Screen (Success) Figure C‐23 Figure C-23 Logs Screen (Failure)       Dolby DP600 Program Optimizer Manual ®...
  • Page 127: Figure C-24 Select System Log Output Directory Screen

    Archiving System Logs To archive system logs, press or click  The  Select System Log Output Directory screen functions in the same way as entering a path for work order files, as described on  page 32 (and is described in greater detail in Section A.2 and Section specify a directory where you want to save the DP600 Server logs. If you experience a  system problem, send the respective log file to your Dolby authorized technical  representative. Figure C‐24 Figure C-24 Select System Log Output Directory Screen Dolby DP600 Program Optimizer Manual ®  in the  system log  screen appears, as shown in Figure   Reconfiguring the System  screen. maintenance C‐24. This ...
  • Page 128: Figure C-25 Power Screen

    Rebooting and Shutting Down the System To reboot or shut down the system: Press or click  The  power Figure C‐25 Figure C-25 Power Screen To reboot or shut down the system, press or click  A confirmation prompt asks if you’re sure you want to reboot (or shut down) the  DP600, as shown in the example in Figure Figure C‐26 Figure C-26 Reboot DP600 Confirmation Prompt Press or click  If pressing or clicking the  <Ctrl>+<Alt>+<Delete> on the provided keyboard.  When you shut down, the  Figure C‐27. When you see this screen (and the drive LEDs are not blinking),  disconnect the power cables to shut down completely. Figure C‐27 Figure C-27 OK to Shut Down When This Screen Appears (and the Drive LEDs Are Not Active) Caution: Currently the front‐panel touch screen may not display the local ...
  • Page 129 access levels admin ... 101 user... 101 viewer ... 101 add work order... 30 adding users... 105 admin level access defined... 101 logging in ... 30 setting up... 102 applications cable ... 4 described ... 3 IPTV ... 4 satellite... 4 terrestrial broadcast ... 4 archiving work order reports, manually ... 110 archiving, system logs ... 115 audio port ...
  • Page 130 Index hostname ... 13 hot folder described ... 3 Grass Valley described... 26 selecting ... 31 Omneon described... 26 selecting ... 31 Pinnacle described... 26 selecting ... 31 work order described... 26 selecting ... 31 IP address ... 14 IPTV applications ... 4 LEDs DP600 internal drives ...
  • Page 131: Index

    status checking... 23 system rebooting ... 116 setup... 12 shutting down ... 116 status ... 23 system administrator functions... 101 system logs, archiving ... 115 system reset button ... 7 system screen locked... 23 unlocked ... 105 temperature LEDs... 7 terrestrial broadcast applications... 4 time zone ... 16 touch screen calibrating ... 56 front panel...

Table of Contents

Save PDF
