- Page 1 Dolby DP600 ® DVD Drive Replacement Guide Issue 1 Part Number 9110450...
-
Page 2: Corporate Headquarters
European Headquarters Dolby Laboratories, Inc. Wootton Bassett Wiltshire SN4 8QJ England Telephone 44‐1793‐842100 Fax 44‐1793‐842101 DISCLAIMER OF WARRANTIES: EQUIPMENT MANUFACTURED BY DOLBY LABORATORIES IS WARRANTED AGAINST DEFECTS IN MATERIALS AND WORKMANSHIP FOR A PERIOD OF ONE YEAR FROM THE DATE OF PURCHASE. THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES AND NO WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR OF NONINFRINGEMENT OF THIRD‐PARTY RIGHTS (INCLUDING, BUT NOT LIMITED TO, COPYRIGHT AND PATENT RIGHTS). LIMITATION OF LIABILITY: IT IS UNDERSTOOD AND AGREED THAT DOLBY LABORATORIES’ LIABILITY, WHETHER IN CONTRACT, IN TORT, UNDER ANY WARRANTY, IN NEGLIGENCE, OR OTHERWISE, SHALL NOT EXCEED THE COST OF REPAIR OR REPLACEMENT OF THE DEFECTIVE COMPONENTS OR ACCUSED INFRINGING DEVICES, AND UNDER NO CIRCUMSTANCES SHALL DOLBY LABORATORIES BE LIABLE FOR INCIDENTAL, SPECIAL, DIRECT, INDIRECT, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, DAMAGE TO SOFTWARE OR RECORDED AUDIO OR VISUAL MATERIAL), COST OF DEFENSE, OR LOSS OF USE, REVENUE, OR PROFIT, EVEN IF DOLBY LABORATORIES OR ITS AGENTS HAVE BEEN ADVISED, ORALLY OR IN WRITING, OF THE POSSIBILITY OF SUCH DAMAGES. . Part Number 9110450 Dolby and the double‐D symbol are registered trademarks of Dolby Laboratories. Issue 1 © 2009 Dolby Laboratories. All rights reserved. S09/21033 ® Dolby DP600 DVD Drive Replacement Guide... -
Page 3: Replacement Instructions
To replace the DVD drive: Power down the unit as follows: From the touch screen, press > (you may need to enter an System Power>Shutdown administrator password), then press at the prompt. The unit will begin the shutdown process. b. Wait until appears on the screen, as shown in Dolby DP600 Program Optimizer Figure 1, then disconnect the power cords from the back of the unit. Figure 1 Figure 1 Disconnect Power Cords when You See This Screen Remove the DP600 from its rack. ® Dolby DP600 DVD Drive Replacement Guide... - Page 4 Figure 2 Remove top-front screws Figure 2 Remove Top-Front Screws Figure 3 Remove top-rear screws Figure 3 Remove Top-Rear Screws Remove the far‐left and far‐right screws on each side of the lid (two each on the right and left sides). Then loosen (but don’t remove) the remaining (middle three) screws on the left and right sides of the lid, as shown in Figure 4 and Figure Figure 4 Remove Loosen Remove Figure 4 Right-Side Screws ® Dolby DP600 DVD Drive Replacement Guide...
- Page 5 Replacing the DVD Drive Figure 5 Remove Remove Loosen Figure 5 Left-Side Screws Swing the touch‐screen panel out to the left, as shown in Figure Figure 6 Figure 6 Swing Out Touch-Screen Panel Locate the small pry areas behind the right panel, as shown in Figure Figure 7 Figure 7 Locate Pry Areas Behind Right Panel ® Dolby DP600 DVD Drive Replacement Guide...
- Page 6 Replacing the DVD Drive Using your fingers or a cushioned screwdriver, gently pry off the right panel from its left side, as shown in Figure 8 (the other side is a slotted lock). Be careful not to drop the panel, as it is deceptively heavy and will come off suddenly once the locking mechanism disengages. Figure 8 Figure 8 Pry Off Right Panel Remove the lid from the unit, then locate the DVD drive housing assembly, as shown in Figure Figure 9 DVD drive housing assembly Figure 9 Locate DVD Drive Housing Assembly (Front View) ® Dolby DP600 DVD Drive Replacement Guide...
- Page 7 System interface PCB Serial and power connections Figure 10 DVD Drive Housing Assembly and Adjacent Areas (Rear View) Locate the two connections to the front‐panel system reset printed circuit board (PCB) shown in Figure 11). Figure 11 Two system reset connections Figure 11 Connections to System Reset PCB ® Dolby DP600 DVD Drive Replacement Guide...
- Page 8 12 and Figure 13. You disconnect these cables so they do not obstruct the removal of the housing assembly. Figure 12 Disconnect system reset LED power connector Figure 12 System Reset LED Power Connector Figure 13 Disconnect system reset serial connector Figure 13 System Reset Serial Connector ® Dolby DP600 DVD Drive Replacement Guide...
- Page 9 Disconnect DVD serial connector Disconnect DVD power connector Figure 14 Disconnect Serial and Power Connections 12. Disconnect the two connections to the touch‐screen interface PCB on the side of the unit. You can disconnect the rear connection by hand, as shown in Figure Figure 15 Disconnect touch-screen PCB rear connection Figure 15 Disconnect Touch-Screen PCB Rear Connection ® Dolby DP600 DVD Drive Replacement Guide...
- Page 10 Replacing the DVD Drive You can disconnect the front connection by pressing down on the latching mechanism using a pair of needle‐nose pliers (see Figure 16). Figure 16 Disconnect touch-screen PCB front connection Figure 16 Disconnect Touch-Screen PCB Front Connection 13. Locate the screws on the front panel that secure the DVD housing assembly (see Figure 17), and use the 5/64‐inch hex wrench to remove them. Figure 17 Figure 17 Remove the Four Housing Assembly Screws ® Dolby DP600 DVD Drive Replacement Guide...
- Page 11 Replacing the DVD Drive 14. Gently slide the DVD housing toward the rear of the DP600 to free it from the locking mechanism, as shown in Figure Figure 18 Two locking stand-offs on each side Figure 18 Unlock DVD Housing Assembly 15. Gently lift the DVD housing assembly, and slide it to the rear of the DP600, taking care to free the housing from loose cables, as shown in Figure Figure 19 Figure 19 Lift DVD Housing Assembly ® Dolby DP600 DVD Drive Replacement Guide...
- Page 12 Replacing the DVD Drive Remove the old DVD drive, and insert the replacement unit (see Figure 20). Be sure to insert the DVD drive in its original mounting position before tightening the mounting screws. Make sure the mounting screws tighten down in their original locations, as indicated by marks left on the mounting bracket. Figure 20 Insert new drive Figure 20 Replace Drive 17. Reverse steps 1‐15 taking care to properly align and reconnect all the cables. 18. Return the unit to service. Send Us Your Feedback If you have a question or comment regarding this document, send us an email. ® Dolby DP600 DVD Drive Replacement Guide...
