Page 1 Viper SRT10 2 0 1 0 O W N E R ’ S M A N U A L COUPE & ROADSTER...
Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name Chrysler Group LLC shall be deemed to be deleted and the name Chrysler Canada Inc. used in substitution therefore. DRIVING AND ALCOHOL Drunken driving is one of the most frequent causes of accidents.
Page 3: Introduction
TABLE OF CONTENTS SECTION ............3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 5: Table Of Contents
CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle.
Page 7 INTRODUCTION 5...
Page 8: Vehicle Identification Number
The Vehicle Identification Number (VIN) is on the left front corner of the instrument panel and is visible from outside the vehicle through the windshield. This number also appears on the Automobile Information Disclosure Vehicle Identification Number Label affixed to a window on your vehicle, the vehicle NOTE: It is illegal to remove or alter the VIN.
Page 9: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 11 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Key-In-Ignition Reminder .
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information ....24 Door Locks ......25 Manual Door Lock .
Page 13 Break-In Recommendations ....63 Safety Tips ......64 Transporting Passengers .
Page 14: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS You can insert the double-sided keys into the locks with either side up. The authorized dealer that sold you your new vehicle has the key code numbers for your vehicle’s locks. These numbers can be used to order duplicate keys from your authorized dealer or a locksmith.
Page 15: Key-In-Ignition Reminder
NOTE: The Power Accessory Delay feature allows you to operate the radio and the power windows for two minutes after turning OFF the ignition switch. Removing the key from the ignition switch and opening the driver’s door will cancel this feature. Your authorized dealership can enable or disable the Power Accessory Delay feature as desired.
Page 16: To Arm The System
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Arm the System Remove the key from the ignition switch and either press a power door LOCK switch while the driver’s or passen- ger’s door is open or press the LOCK button on the Remote Keyless Entry (RKE) transmitter.
Page 17 on the ignition. If this occurs, and you wish to rearm the system, simply repeat either of the previously described arming sequences. • The Vehicle Security Light will remain on steady if the hood or trunk/liftgate is open during the arming process or if there is a fault in the system.
Page 18: To Disarm The System
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Disarm the System There are two ways to disarm the system: • Use the key to unlock the driver’s door. The door lock is located on the outside door panel beneath the mirror.
Page 19: Electronic Immobilization System - Canada Only
Electronic Immobilization System — Canada Only The Electronic Immobilization system prevents unautho- rized vehicle operation by disabling the engine. The system does not need to be armed or activated. Operation is automatic, regardless of whether the vehicle is locked or unlocked. To Arm the System The Electronic Immobilization system will passively arm 30 seconds after the key is removed from the vehicle.
Page 20: Illuminated Entry
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ILLUMINATED ENTRY The interior lights will turn on whenever a door is opened or the liftgate is opened (Coupe models) and the dimmer switch is not in the defeat position. The interior lights will turn on, remain on for approxi- mately 30 seconds, and then fade to off if any of the following occur: •...
Page 21: To Unlock The Doors
RKE Transmitter To Unlock the Doors Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door or twice to unlock both doors. The park lights and turn signal lights will flash to acknowledge the signal and the illuminated entry system will turn on.
Page 22 20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Test the feature while outside of the vehicle, by pressing the UNLOCK button on the RKE transmitter with the ignition in the OFF/LOCK position, and the key removed. 4. Repeat these steps if you want to return this feature to its previous setting.
Page 23: To Lock The Doors
To Lock the Doors Press and release the LOCK button on the RKE transmit- ter to lock the doors. The horn will chirp once and the park lights and turn signal lights will flash to acknowl- edge the signal. Sound Horn with Remote Key Lock This feature will cause the horn to chirp when the doors are locked with the RKE transmitter.
Page 24: Using The Panic Alarm
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Using the Panic Alarm The Panic Alarm unlocks the driver’s door, turns on the interior lights, flashes the park lights and fog lights, and sounds the horn. The Panic Alarm will not work when driving the vehicle.
Page 25: Battery Replacement
3. Press and hold the UNLOCK button for at least five seconds, but no longer then 10 seconds on a previously programmed RKE transmitter. Then, press the PANIC button while still holding the UNLOCK button. 4. Release both buttons at the same time. A chime will sound to signal that the programming feature is acti- vated.
Page 26: General Information
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Separate the two halves of the RKE transmitter with a coin or similar object. Separating RKE transmitter Halves 2. Remove and replace the battery. Avoid touching the new battery with your fingers. Skin oils may cause battery deterioration.
Page 27: Door Locks
can affect transmitter operation. To verify if this is the cause, move the vehicle to another area and test RKE transmitter operation. 2. The RKE transmitter may become “out of sync” and will no longer function if operated more than 255 times while out of range of the vehicle (23 ft or 7 m) or if operated while the vehicle battery is dead or discon- nected.
Page 28: Manual Door Lock
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be injured seriously or fatally. Don’t leave the key in the ignition.
Page 29: Power Door Locks
Power Door Locks A power door lock switch is on each door trim panel. Use this switch to lock or unlock the doors. Power Door Lock Switch NOTE: To prevent you from accidentally locking your keys in the vehicle, the power door locks will not operate if the key is in the ignition and the driver’s door is open.
Page 30: Windows
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Input from the door handles is ignored once the vehicle is moving faster than 5 mph (8 km/h). Automatic Door Locks Programming The Automatic Door Locks feature can be enabled or disabled as follows: 1.
Page 31: Auto-Down Feature
• Windows cannot be driven up during Power Acces- sory Delay with a door open. Furthermore, opening the door will stop the window movement immediately if the window is in the process of going up. • The window will lower slightly if it is closed com- pletely when opening the door.
Page 32: Wind Buffeting
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To open the window to a desired position, press and hold the WINDOW switch in the first detent. Release the switch when you want the window to stop. Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears.
Page 33: Trunk Lock And Release - Convertible Models Only
• When all doors are locked (except for RKE transmitter liftgate access). Refer to “Entering the Liftgate with the System Armed — Coupe” under “Security Alarm System” for additional information. The word “DECK” will flash in the odometer when the liftgate is open.
Page 34: Trunk Safety Warning - Convertible Models Only
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE You can also unlatch the trunk lid with the key. The key cylinder is located on the trunk lid. The word “DECK” will flash in the odometer when the trunk lid is open. With the key in the ignition switch, this display will turn off approximately 40 seconds after switching OFF the ignition, or if the Power Accessory Delay feature is active, it will turn off approximately...
Page 35: Trunk Emergency Release
Trunk Emergency Release The trunk of your vehicle is equipped with an emergency release handle. It is located on the inside of the trunk lid, near the latch, and is coated so that it glows in a darkened trunk. Pull on the handle to open the trunk. Emergency Release THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 OCCUPANT RESTRAINTS...
Page 36 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE way out and then adjusting the belt to the desired length to restrain a child seat or secure a large item in a seat — if equipped If you will be carrying children too small for adult-sized seat belts, the seat belts or the Lower Anchors and Tether for CHildren (LATCH) feature also can be used to hold infant and child restraint systems.
Page 37: Lap/Shoulder Belts
ejection and the risk of injury caused by striking the inside of the vehicle. Everyone in a motor vehicle should be belted at all times. Lap/Shoulder Belts Each seat belt is a combined lap/shoulder belt system. The belt webbing retractor will lock only during very sudden stops or impacts.
Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Two people should never be belted into a single seat belt. People belted together can crash into one another in an accident, hurting one another badly. Never use a lap/shoulder belt or a lap belt for more than one person, no matter what their size.
Page 39 4. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Latch Plate To Buckle (Convertible Shown) THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 WARNING! • A belt that is buckled into the wrong buckle will not protect you properly.
Page 40 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • A belt that is worn under your arm is very danger- ous. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck injury.
Page 41 WARNING! • A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen. Always wear the lap belt as low as possible and keep it snug.
Page 42: Lap/Shoulder Belt Untwisting Procedure
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. 1. Position the latch plate as close as possible to the anchor point. 2. At about 6 to 12 in (15 to 30 cm) above the latch plate, grasp and twist the belt webbing 180 degrees to create a fold that begins immediately above the latch plate.
Page 43: Automatic Locking Retractors (Alr) Mode - If Equipped
4. Turn the ignition switch to the ON/RUN position, but do not start the engine. Wait for the Seat Belt Reminder Light to turn off and then proceed to the next step. NOTE: You must perform the following steps within 60 seconds of turning the ignition switch to the ON/RUN position.
Page 44: Seat Belt Pretensioners - If Equipped
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Use The Automatic Locking Mode 1. Buckle the combination lap and shoulder belt. 2. Grasp the shoulder portion and pull downward until the entire belt is extracted. 3. Allow the belt to retract. As the belt retracts, you will hear a clicking sound.
Page 45: Seat Belts And Pregnant Women
Seat Belts and Pregnant Women We recommend that pregnant women use the seat belts throughout their pregnancy. Keeping the mother safe is the best way to keep the baby safe. Pregnant women should wear the lap portion of the belt across the thighs and as snug across the hips as possible.
Page 46: Driver And Passenger Supplemental Restraint System (Srs) - Airbags
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Driver and Passenger Supplemental Restraint System (SRS) - Airbags This vehicle is equipped with airbags for the driver and passenger as a supplement to the seat belt restraint systems. The driver’s airbag is mounted in the steering wheel.
Page 47 The airbags have a multistage inflator design. This allows the airbag to have different rates of inflation that are based on collision severity and occupant size. WARNING! • No objects should be placed over or near the airbag on the instrument panel, because any such objects could cause harm if the vehicle is in a crash severe enough to cause the airbag to inflate.
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Knee Impact Bolsters The Knee Impact Bolsters help protect the knees of the driver and the passenger, and position everyone for the best interaction with the airbags. While the seat belts are designed to protect the driver and passenger in many types of collisions, the airbags will deploy in certain frontal collisions depending on the severity and type of collision.
Page 49 − Passenger Airbag Disabled (PAD) Indicator Light − Flex Mat Here are some simple steps you can take to minimize the risk of harm from a deploying airbag: 1. An infant up to one year or approximately 20 lbs (9 kg) should never ride in the vehicle because in the event of a crash, the rear-facing child seat places them too close to the passenger airbag.
Page 50: Airbag Deployment Sensors And Controls
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 8. Read the instructions provided with your child re- straint to make sure that you are using it properly. 9. Read the instructions provided with your child safety seat or booster seat to make sure that you are using it properly.
Page 51 The Advanced Front Airbags will not deploy in all frontal collisions, including some that may produce substantial vehicle damage — for example, some pole collisions, truck underrides, and angle offset collisions. On the other hand, depending on the type and location of impact, Advanced Front Airbags may deploy in crashes with little vehicle front-end damage but that produce a severe initial deceleration.
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Ignoring the Airbag Warning Light in your instru- ment panel could mean you won’t have the airbags to protect you in a collision. If the light does not come on, stays on after you start the vehicle, or if it comes on as you drive, have the airbag system checked right away.
Page 53 vehicle to an authorized dealer for service. The Airbag Warning Light will turn on whenever there is a fault present, which can affect the operation of the airbag system. If there is a fault present in the OCS, both the PAD Indicator Light and the Airbag Warning Light will illuminate to show that the passenger airbag is turned off.
Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The passenger airbag will not be enabled for most any size child who is seated properly in the passenger seat and for most properly installed child restraint systems. However, under certain conditions, even with a properly installed child restraint system, the PAD Indicator Light may not be on, even though the airbag is disabled.
Page 55 proper airbag deployment. Do not make any modifica- tions to the passenger seat components, assembly, or to the seat cover. If the seat, trim cover, or cushion needs service for any reason, take the vehicle to your autho- rized dealer. Only manufacturer approved seat accesso- ries may be used.
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If a Deployment Occurs The airbags are designed to deflate immediately after deployment. NOTE: Front airbags will not deploy in all collisions. This does not mean something is wrong with the airbag system.
Page 57 WARNING! Deployed airbags and seat belt pretensioners cannot protect you in another collision. Have the airbags, seat belt pretensioners, and the front passenger seat belt retractor assembly replaced by an authorized dealer as soon as possible. Also, have the Occupant Restraint Controller System serviced as well.
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Do not attempt to modify any part of your ad- vanced airbag system. The airbag may inflate accidentally or may not function properly if modi- fications are made. Take your vehicle to an autho- rized dealer for any advanced airbag system ser- vice.
Page 59: Child Restraints
NOTE: If the speedometer, tachometer, or any engine related gauges are not working, the Occupant Restraint Controller (ORC) may also be disabled. The airbags may not be ready to inflate for your protection. Promptly check the fuse block for blown fuses. Refer to the label located on the inside of the fuse block cover for the proper airbag fuses.
Page 60: Things To Know Before Starting Your Vehicle
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infant and Child Restraints • Safety experts recommend rearward-facing in the vehicle until they are at least one year old and weigh at least 20 lbs (9 kg). Two types of child restraints can be used rearward-facing: infant carriers and “convertible”...
Page 61 The belt-positioning booster seat is for children weighing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly. If the child cannot sit with knees bent over the vehicle’s seat cushion while the child’s back is against the seat back, they should use a belt-positioning booster seat.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Improper installation can lead to failure of a child restraint. It could come loose in a collision. The child could be injured badly or killed. Follow the manu- facturer’s directions exactly when installing a child restraint.
Page 63 To attach a child restraint tether strap: 1. Move the seat forward. 2. Move the seatback to its full forward position. 3. Remove the child tether access cover by prying either side with a screwdriver or similar tool, as shown. Child Tether Access Cover THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 NOTE: While the child tether is in use, keep the access...
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. Move the seat to its farthest rearward position. Apply body pressure to the seat to be sure the seat adjusters have latched. 7. Return the seatback to an upright position. 8. Install the child restraint according to the manufactur- er’s directions.
Page 65: Break-In Recommendations
4. Tighten the lap portion of the belt and allow the excess webbing to retract back to the retractor. If it still does not make the child restraint secure, then secure the child restraint with the Child Restraint Tether Anchor. NOTE: Once the belt is in Automatic Locking Mode, you will not be able to pull any more of the webbing out of the retractor.
Page 66: Safety Tips
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Avoid excessive idling. • Check the engine oil level at every fuel fill. NOTE: A new engine will consume some oil during the first few thousand miles (kilometers) of operation. This should be considered a normal part of the break-in and not interpreted as a sign of difficulty.
Page 67: Exhaust Gas
Exhaust Gas WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO) follow these safety tips: Do not run the engine in a closed garage or in confined areas any longer than needed to move your vehicle in or out of the area.
Page 68: Vehicle
66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Safety Checks You Should Make Inside the Vehicle Seat Belts Inspect the belt system periodically, checking for cuts, frays, and loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Front seat belt assemblies must be replaced after a collision.
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 Door Latches Check for positive closing, latching, and locking. Fluid Leaks Check area under vehicle after overnight parking for fuel, engine coolant, oil, or other fluid leaks. Also, if gasoline fumes are detected or if fuel, power steering fluid, or brake fluid leaks are suspected, the cause should be located and corrected immediately.
Page 71: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Convertible Top Operation — If Equipped ..71 To Lower The Top ..... 71 To Raise The Top .
Page 72 70 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lights-On Reminder ....90 Battery Saver Feature — Exterior Lights ..90 Fog Lights .
Page 73: Convertible Top Operation - If Equipped
CONVERTIBLE TOP OPERATION — IF EQUIPPED WARNING! The convertible top does not provide the structural protection that a reinforced metal roof does, and the fabric top cannot be expected to prevent the ejection of the occupants of a vehicle in a collision. Therefore, it is important that all occupants wear their seat belts at all times when riding in a convertible.
Page 74 72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Depress the button located at the top of the latch and then pull the latch handle downward and rearward. Unlatching Convertible Top 4. Disengage the latch hook from the windshield receiver rod and then pull the latch all the way back to the detent stow position.
Page 75: To Raise The Top
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 73 9. Push the leading edge of the top downward to engage the downstack latch. 10. Close the trunk. To Raise the Top 1. Lower the window in each door at least one inch. 2.
Page 76 74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 5. Manually raise the convertible top until it meets the windshield header. Raising Convertible Top 6. Close the trunk. 7. From inside the vehicle, grasp the handles and pull the convertible top toward the windshield header. Then, push the latch handle forward so that the latch hook engages the windshield receiver rod.
Page 77: Convertible Top Boot Cover Installation - If Equipped
8. Ensure that the outboard locating pins are in their respective receiving holes in the windshield header and then push the latch handle forward all the way to close the latch. NOTE: Until the convertible top system has had ad- equate time to break-in, it may take a greater effort to engage the latch hook and close the latch.
Page 78 76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Slide the boot cover pocket over the front corner of the convertible top on the driver side of the vehicle. Then, stretch and slide the boot cover pocket over the front corner of the convertible top on the passenger side of the vehicle.
Page 79 6. On the passenger side of the vehicle, clip the tab under the trunk lid stop and on the outer edge of the quarter panel flange. Attaching Passenger Side Tab UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77 7. Push downward on the boot cover pocket to engage the inboard tab.
Page 80 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 8. On the driver side of the vehicle, clip the tab under the trunk lid stop and on the outer edge of the quarter panel flange. Attaching Driver Side Tab 9. Push downward on the boot cover pocket to engage the inboard tab.
Page 81 10. Push downward on the boot cover behind driver seat to lock down the boot cover. Locking Boot Cover UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79 11. Stretch and smooth out the boot cover from the rear of vehicle. 12. Close the trunk. 13.
Page 82: Convertible Top Boot Cover Removal And Storage
80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Convertible Top Boot Cover Removal and Storage 1. Open the trunk. 2. On the driver side of the vehicle, pull upward on the boot cover to disengage the inboard tab. Disengaging Driver Side Tab 3.
Page 83 4. On the passenger side of the vehicle, pull upward on the boot cover to disengage the inboard tab. Disengaging Passenger Side Tab 5. Unclip the tab under the trunk lid stop and on the outer edge of the quarter panel flange. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 81 Tab Under Trunk Lid Stop 6.
Page 84 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 7. Fold the outer edges of the boot cover inward. Folding Outer Edges 8. Fold the boot cover again. Folding Boot Cover 9. Place the boot cover into the bag and store it in the trunk or a secure dry area.
Page 85: Mirrors
MIRRORS Inside Day/Night Mirror Adjust the mirror to center on the view through the rear window. A pivot system allows for horizontal and verti- cal mirror adjustment. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).
Page 86: Power Mirrors
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The passenger side convex outside mirror will give a much wider view to the rear, and especially of the lane next to your vehicle. WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are.
Page 87: Seats
NOTE: When not in use, return the power mirror switch to the neutral (off) position to prevent accidental mirror movement. SEATS Seats are a primary part of the Occupant Restraint System of the vehicle. They need to be used properly for safe operation of the vehicle.
Page 88 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked.
Page 89: To Open And Close The Hood
TO OPEN AND CLOSE THE HOOD Two latches must be released to open the hood. 1. Reach into the lower right grille opening and pull the primary hood latch forward. Hood Release Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 2.
Page 90: Lights
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Assist props will raise the hood to a normal usage position. If greater access is required, the hood may be pushed up at the front, raising the hood beyond the initial opening height. CAUTION! •...
Page 91: Headlights And Parking Lights
Headlights and Parking Lights Turn the end of the multifunction lever to the first detent for parking light operation. Turn the end of the lever to the second detent for headlight operation. Multifunction Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 Headlight Time Delay This feature is particularly useful when exiting your vehicle in an unlit area.
Page 92: Daytime Running Lights
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Daytime Running Lights The fog lights will come on as Daytime Running Lights, whenever the ignition switch is ON, the headlights are off, and the parking brake is off. The headlight switch must be used for normal night time driving. NOTE: This feature is standard on all Canadian vehicles and cannot be disabled.
Page 93: Turn Signals
NOTE: The fog lights will only operate with the head- lights on low beam. Selecting high beam headlights will turn off the fog lights. Turn Signals Move the multifunction lever upward or downward and the corresponding turn signal indicator on the instru- ment panel will flash to show proper operation of the front and rear turn signal lights.
Page 94: High Beam/Low Beam Select Switch
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE High Beam/Low Beam Select Switch Pull the multifunction lever toward you to switch the headlights to high beam. Pull the lever a second time to switch the headlights back to low beam. Flash-to-Pass You can signal another vehicle with your headlights by lightly pulling the multifunction lever toward you.
Page 95 Courtesy/Reading Light Switches Courtesy lights are also found in the driver’s foot well, the passenger’s foot well, and in the liftgate on Coupe models. You can turn this light on and off from the dimmer control in the multifunction lever. This light is also controlled automatically by the Illuminated Entry system.
Page 96 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Instrument Panel Dimming With the parking lights or headlights on, rotate the dimmer control upward to increase the brightness of the instru- ment panel lights or rotate it down- ward to decrease the brightness of the instrument panel lights.
Page 97: Windshield Wipers And Washers
WINDSHIELD WIPERS AND WASHERS The windshield wiper/washer control lever is on the right side of the steering column. From the off position, push the windshield wiper/ washer control lever upward to the first detent past the intermittent DEL setting for low-speed wiper operation, or to the second detent past the intermittent DEL setting for high-speed wiper operation.
Page 98: Mist Feature
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Sudden loss of visibility through the windshield could lead to an accident. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with defroster before and during wind- shield washer use.
Page 99 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 WARNING! Do not adjust the steering column while driving. Adjusting the steering column while driving or driv- ing with the steering column unlocked, could cause the driver to lose control of the vehicle. Be sure the steering column is locked before driving your ve- hicle.
Page 100: Adjustable Pedals
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ADJUSTABLE PEDALS This feature allows the driver to move the clutch, brake and accelerator pedals about 3 in (72 mm) forward or rearward to allow for greater driving comfort. The ad- justable pedals switch is recessed into the knee bolster beneath the steering column.
Page 101: Adjustable Foot Rest
CAUTION! Do not place any article under the adjustable pedals or impede its ability to move as it may cause damage to the pedal controls. Pedal travel may become lim- ited if movement is stopped by an obstruction in the adjustable pedal’s path.
Page 102: Electrical Power Outlets
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Slide the pedal either forward or backward and rotate it upward or downward as desired. 4. Tighten the nut, being careful not to over tighten it. ELECTRICAL POWER OUTLETS Your vehicle is equipped with 12 Volt (13 Amp) power outlets that can be used to power cellular phones, small electronics and other low powered electrical accessories.
Page 103 Center Console Power Outlet NOTE: Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded the fuse protecting the system will need to be replaced. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 WARNING! To avoid serious injury or death: •...
Page 104: Console Features
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.). Eventually, if plugged in long enough, the vehicle’s battery will discharge sufficiently to degrade battery life and/or prevent the engine from starting.
Page 105: Storage
STORAGE A glove box storage compartment is located on the passenger side of the instrument panel. Glove Box Storage Compartment UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 Pull outward on the handle/latch to open this compart- ment. Opening Glove Box Storage Compartment...
Page 106: Rear Window Features
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE REAR WINDOW FEATURES Rear Window Defroster The rear window defroster button is located on the climate control panel. Press this button to turn on the rear window defroster and the heated outside mirrors (if equipped).
Page 107: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....107 Instrument Cluster Descriptions ... 108 Speedometer ..... . . 108 Message Center .
Page 108 106 UNDERSTANDING YOUR INSTRUMENT PANEL Electronic Serial Number/Sirius Identification Number (ESN/SID) ..130 Selecting Uconnect™ Multimedia (Satellite) Mode In RBB, RAH, REV And RBK Radios . . 130 Selecting Uconnect™ Multimedia (Satellite) Mode In RBP, RBU, RAZ, RB1 And RBQ Radios .
Page 109: Instrument Panel Features
INSTRUMENT PANEL FEATURES 1 — Air Outlet 2 — Sound System Speaker 3 — Main Message Center 4 — Fuel Gauge 5 — Auxiliary Message Center 6 — Tachometer UNDERSTANDING YOUR INSTRUMENT PANEL 107 7 — Speedometer/Odometer 8 — Oil Pressure Gauge 9 —...
Page 110: Instrument Cluster Descriptions
108 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS Speedometer Shows the vehicle’s speed in miles- per-hour (mph) and kilometers-per- hour (km/h). Odometer/Trip Odometer The odometer shows the total distance the vehicle has been driven. NOTE: U.S. Federal regulations require that upon trans- fer of vehicle ownership, the seller certify to the pur- chaser the correct mileage that the vehicle has been driven.
Page 111: Message Center
Liquid Crystal Display (LCD) Panel The LCD panel at the bottom of the speedometer displays specific messages for given conditions. These messages are as follows: • The words “DOOR AJAR” will display if a door is not closed completely. In addition, a single chime will sound if you move the vehicle when a door is not closed completely.
Page 112 110 UNDERSTANDING YOUR INSTRUMENT PANEL Front Fog Light Indicator This indicator will illuminate when the front fog lights are on. Anti-Lock Brake (ABS) Warning Light The amber Anti-Lock Brake Warning Light will turn on and stay on briefly as a bulb check when the ignition is first turned on.
Page 113 does not come on when turning the key from OFF/LOCK to ON/RUN, have the condition checked promptly. Certain conditions such as a loose or missing gas cap, poor fuel quality, etc., may illuminate the light after engine start. The vehicle should be serviced if the light remains on through several of your typical driving cycles.
Page 114 112 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Leaving the hazard flashers on for extended periods will wear down the battery. Airbag Warning Light This light will turn on for six to eight seconds as a bulb check when the ignition switch is first turned on.
Page 115 Electronic Throttle Control (ETC) Light This light will turn on briefly as a bulb check when turning on the ignition switch. It will also turn on while the engine is running to warn of a problem with the Electronic Throttle Control (ETC) system.
Page 116 114 UNDERSTANDING YOUR INSTRUMENT PANEL Accordingly, when the low tire pressure telltale illumi- nates, you should stop and check your tires as soon as possible and inflate them to the proper pressure. Driving on a significantly under-inflated tire causes the tire to overheat and can lead to tire failure.
Page 117 CAUTION! The Tire Pressure Monitor System (TPMS) has been optimized for the original equipment tires and wheels. The TPMS pressures have been established for the tire size equipped on your vehicle. Undesir- able operation or sensor damage may result when using replacement equipment that is not of the same size, type, and/or style.
Page 118: Gauges And Indicator Lights
116 UNDERSTANDING YOUR INSTRUMENT PANEL Gauges and Indicator Lights Tachometer This gauge shows engine speed in revolutions- per-minute (RPM) times 1,000. Avoid excessive engine speeds in any part of the red warning zone, particularly when driving downhill or in lower gears. Skip Shift Indicator Light This indicator is located in the Tachometer.
Page 119 Oil Temperature Gauge This gauge shows the oil temperature. The gauge pointer will likely show higher tempera- tures when driving in hot weather, up moun- tain grades, or in heavy stop and go traffic. If the red Warning Light remains on after the bulb check or turns on while driving, safely bring the vehicle to a complete stop and turn off the engine.
Page 120: Setting The Digital Clock
118 UNDERSTANDING YOUR INSTRUMENT PANEL Fuel Gauge This gauge shows the amount of fuel in the gas tank. The reaction time of the gauge has been slowed to avoid needle fluctuation during pe- riods of high G force cornering. Voltage Gauge This gauge shows the electrical system voltage.
Page 121: Clock Setting Procedure
Clock Setting Procedure 1. Turn the ignition switch to the ON/RUN or ACC position. 2. Using the point of a ballpoint pen or similar object, press either the H (HOUR) or M (MINUTE) button on the radio. The display will show the time. 3.
Page 122 120 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Power to operate the radio is supplied through the ignition switch. It must be in the ON or ACC position to operate the radio. PTY (Program Type) Pressing the INFO button once while in FM mode will turn on the PTY mode for five seconds.
Page 123 Program Type Radio Display Soft Rhythm and Blues Soft R&B Sports Sports Talk Talk Top 40 Top 40 Weather Weather By pressing the SEEK button when the PTY icon is displayed, the radio will be tuned to the next frequency station with the same selected PTY name.
Page 124 122 UNDERSTANDING YOUR INSTRUMENT PANEL Tuning Press the TUNE control up or down to increase or decrease the frequency. If you press and hold the button, the radio will continue to tune until you release the button. The frequency will be displayed and continu- ously updated while the button is pressed.
Page 125: Cd Player Operation
both AM and FM. This allows a total of 10 AM and 10 FM stations to be locked into memory. You can recall the stations stored in SET 2 memory by pressing the push- button twice. To Change from Clock to Radio Mode Press the TIME button to change the display between radio frequency and time.
Page 126 124 UNDERSTANDING YOUR INSTRUMENT PANEL Inserting The Compact Disc CAUTION! This CD player will accept only 4–3/4 in (12 cm) discs only. The use of other sized discs may damage the CD player mechanism. You may either insert or eject a disc with the radio OFF. If you insert a disc with the ignition ON and the radio OFF, the display will show the time of day.
Page 127: Cd/Dvd Changer Operation
RND — Random Play Press the RND button while the CD is playing to activate Random Play. This feature plays the selections on the compact disc in random order to provide an interesting change of pace. Press the SEEK button to move to the next randomly selected track.
Page 128 126 UNDERSTANDING YOUR INSTRUMENT PANEL The radio uses the following limits for file systems: • Maximum number of directory levels: 15 • Maximum number of files: 255 • Maximum number of folders: 100 • Maximum number of characters in file/folder names: •...
Page 129 MPEG Sampling Specification Frequency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio 24, 22.05, 16 Layer 3 ID3 Tag information for artist, song title and album title are supported for version 1 ID3 tags. ID3 version 2 is not supported by the radios.
Page 130: Operation Instructions
128 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - (CD Mode For MP3 Audio Play) SEEK Button (CD Mode For MP3 Play) Pressing the SEEK + button plays the next MP3 File. Pressing the SEEK button plays the beginning of the MP3 file.
Page 131: Uconnect™ Multimedia (Satellite Radio) - If Equipped
Operating Instructions - Uconnect™ Multimedia (Satellite Radio) Mode — (If Equipped) Refer to the Uconnect™ Multimedia (Satellite Radio) section of the Owner’s Manual. Operating Instructions - Video Entertainment System (VES)™ (If Equipped) Refer to 6 Disc CD/DVD Changer (RDV) section of the Owner’s Manual.
Page 132: Understanding Your Instrument Panel Electronic Serial Number/Sirius Identification Number (Esn/Sid)
130 UNDERSTANDING YOUR INSTRUMENT PANEL Electronic Serial Number/Sirius Identification Number (ESN/SID) The Electronic Serial Number/Sirius Identification Num- ber is needed to activate your Sirius Satellite Radio system. To access the ESN/SID, refer to the following steps: ESN/SID Access with RBB, RAH, REV and RBK Radios With the ignition switch in the ACCESSORY position and the radio OFF, press the Tape Eject or CD “EJT”...
Page 133: Selecting Uconnect™ Multimedia (Satellite) Mode In Rbp, Rbu, Raz, Rb1 And Rbq Radios
Selecting Uconnect™ Multimedia (Satellite) Mode in RBP, RBU, RAZ, RB1 and RBQ Radios Press the MODE button repeatedly until the word SIRIUS appears in the display. These radios will also display the following: • After three seconds, the current channel name and channel number will be displayed for five seconds.
Page 134: Using The Pty (Program Type) Button (If Equipped)
132 UNDERSTANDING YOUR INSTRUMENT PANEL erase any AM or FM pre-set memory stations. Follow the memory pre-set procedures that apply to your radio. Using the PTY (Program Type) Button (If Equipped) Follow the PTY button instructions that apply to your radio.
Page 135: Radio Antenna
• Dense tree coverage may interrupt reception in the form of short audio mutes. • Driving under wide bridges or along tall buildings can cause intermittent reception. • Placing objects over or too close to the antenna can cause signal blockage. RADIO ANTENNA The radio antenna is located in the windshield.
Page 136: Radio Operation And Cellular Phones
134 UNDERSTANDING YOUR INSTRUMENT PANEL RADIO OPERATION AND CELLULAR PHONES Air Conditioning and Heating System Under certain conditions, the cellular phone being on in your vehicle can cause erratic or noisy performance from your radio. This condition may be lessened or eliminated by relocating the cellular phone antenna.
Page 137 Blower Control Use this control to regulate the amount of air forced through the sys- tem in any mode you select. Turn the control clockwise to increase fan speed. Turn the control to the O (Off) position to shut off the fan and to prevent any outside air from entering the vehicle.
Page 138 136 UNDERSTANDING YOUR INSTRUMENT PANEL The mode settings are as follows: • Recirculation Control Air is recirculated inside the vehicle. You may choose between Bi-Level and Panel air outlets while in this mode. Use this mode to tempo- rarily block out any outside odors, smoke, or dust and to cool the interior rapidly upon initial start up in very hot or humid weather.
Page 139: Operating Tips
NOTE: The air conditioning compressor operates in this mode. This dehumidifies the air to help dry the wind- shield. To improve fuel economy, leave in the Defrost mode only when necessary. Air Conditioning Control With the fan control in the ON position, push the A/C button to turn on the air conditioning com- pressor.
Page 140 138 UNDERSTANDING YOUR INSTRUMENT PANEL • The blower air will heat faster in cold weather if you use only the low blower speeds for the first ten minutes of vehicle operation. • Use of the air Recirculation mode during winter months is not recommended because it may cause window fogging.
Page 141 UNDERSTANDING YOUR INSTRUMENT PANEL 139 Control Setting Suggestions for Various Weather Conditions...
Page 143: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ....144 Normal Starting ..... 144 If Engine Fails To Start .
Page 144 142 STARTING AND OPERATING Anti-Lock Brake System ....158 Tire Safety Information ....161 Tire Markings .
Page 145 MMT In Gasoline ....183 Materials Added To Fuel ....183 Fuel System Cautions .
Page 146: Starting Procedures
144 STARTING AND OPERATING STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct any other occupant to buckle their seat belt. WARNING! • Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons.
Page 147 NOTE: • You must disarm the security system in order to start the engine. Refer to “Security Alarm System” in “Things To Know Before Starting Your Vehicle” for further information. • Normal starting of either a cold or a warm engine does not require pumping or pressing the accelerator pedal.
Page 148: If Engine Fails To Start
146 STARTING AND OPERATING 6. Press the red ENGINE START button located on the instrument panel. Release the button when the engine starts. ENGINE START Button If Engine Fails to Start CAUTION! To prevent damage to the starter, do not crank the engine for more than 15 seconds at a time.
Page 149: After Starting
WARNING! (Continued) • Do not attempt to push or tow your vehicle to get it started. Unburned fuel could enter the catalytic converter and once the engine has started, ignite and damage the converter and vehicle. If the vehicle has a discharged battery, booster cables may be used to obtain a start from a booster battery or the battery in another vehicle.
Page 150 148 STARTING AND OPERATING Your vehicle is equipped with a high torque capacity dual disc clutch. The clutch pedal must be fully pressed to the floor during each shift. As you release the clutch pedal, lightly press the accelerator pedal. CAUTION! Failure to press the clutch pedal fully to the floor may cause increased shift efforts, and may result in dam-...
Page 151: Recommended Shift Speeds
into REVERSE with the ignition key OFF. This is normal operation of the transmission reverse inhibitor system. • Shifting gears during cold weather may require an increased effort until the transmission lubricant is warm. This is normal and not harmful to the transmis- sion.
Page 152: Skip Shift Indicator Light
150 STARTING AND OPERATING Skip Shift Indicator Light There are times when you must shift the transmis- sion directly from first gear into fourth gear instead of from first gear into second gear. This is to help you get the best possible fuel economy from your vehicle. This occurs when engine coolant is higher than 106°F (41°C), and vehicle speed is greater than 12 mph (19 km/h) but less than 20 mph (32 km/h), and engine speed is less than...
Page 153: Driving On Slippery Surfaces
DRIVING ON SLIPPERY SURFACES Acceleration WARNING! Rapid acceleration on slippery surfaces is dangerous. You could lose control of the vehicle and possibly have an accident. Accelerate slowly and carefully whenever there is likely to be poor traction (ice, snow, wet, mud, loose sand, etc.). Traction When driving on wet or slushy roads, it is possible for a wedge of water to build up between the tire and road...
Page 154: Driving Through Water
152 STARTING AND OPERATING DRIVING THROUGH WATER Driving through water more than a few inches/ centimeters deep will require extra caution to ensure safety and prevent damage to your vehicle. Flowing/Rising Water WARNING! Do not drive on or across a road or path where water is flowing and/or rising (as in storm run-off).
Page 155 CAUTION! (Continued) • Driving through standing water may cause dam- age to your vehicle’s drivetrain components. Al- ways inspect your vehicle’s fluids (i.e., engine oil, transmission/transaxle, axle, etc.) for signs of con- tamination (i.e., fluid that is milky or foamy in appearance) after driving through standing water.
Page 156: Power Steering
154 STARTING AND OPERATING POWER STEERING The standard power steering system will give you good vehicle response and increased ease of maneuverability in tight spaces. The system will provide mechanical steering capability if power assist is lost. If for some reason the power assist is interrupted, it will still be possible to steer your vehicle.
Page 157: Parking Brake
checked if a leak is suspected, abnormal noises are apparent, and/or the system is not functioning as antici- pated. Coordinate inspection efforts through an autho- rized dealer. CAUTION! Do not use chemical flushes in your power steering system as the chemicals can damage your power steering components.
Page 158 156 STARTING AND OPERATING To apply the parking brake, grasp the handle and pull it rearward until you feel resistance. To release the parking brake, grasp the handle and pull it slightly while pressing the button on the end of the handle. When the button drops into the handle (releasing the lock), guide the handle down- ward to its stop and then release the button and the handle.
Page 159: Brake System
BRAKE SYSTEM Your vehicle is equipped with dual hydraulic brake systems. If either of the two hydraulic systems loses normal capability, the remaining system will still function. However, there will be some loss of overall braking effectiveness. You may notice increased pedal travel during application, greater pedal force required to slow or stop, and potential activation of the “Brake System Warning Light.”...
Page 160: Anti-Lock Brake System
158 STARTING AND OPERATING Safe Operating Tips WARNING! To use your brakes and accelerator more safely, follow these tips: • Do not “ride” the brakes by resting your foot on the pedal. This could overheat the brakes and result in unpredictable braking action, longer stopping distances, or brake damage.
Page 161 NOTE: During severe braking conditions, a pulsing sensation may occur and a clicking noise will be heard. This is normal, indicating that the ABS is functioning. The ABS conducts a low-speed self-test at about 12 mph (20 km/h). If you have your foot lightly on the brake while this test is occurring, you may feel slight pedal movement.
Page 162 160 STARTING AND OPERATING WARNING! (Continued) • Pumping of the anti-lock brakes will diminish their effectiveness and may lead to an accident. Pumping makes the stopping distance longer. Just press firmly on your brake pedal when you need to slow down or stop. •...
Page 163: Tire Safety Information
Anti-Lock Brake Warning Light The “Anti-Lock Brake Warning Light” will turn on and stay on briefly as a bulb check when the ignition is first turned on. If the light does not turn on during starting, have it repaired promptly. This light also illuminates at vehicle start-up to indicate that the ABS self-check is in process.
Page 164 162 STARTING AND OPERATING NOTE: • P (Passenger) - Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. • European-Metric tire sizing is based on European design standards.
Page 165 Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm) 65 = Aspect ratio in percent (%)
Page 166 164 STARTING AND OPERATING Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 167: Tire Identification Number (Tin)
Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire. DOT = Department of Transportation —...
Page 168: Tire Terminology And Definitions
166 STARTING AND OPERATING Tire Terminology and Definitions Term B-Pillar Cold Tire Pressure Maximum Inflation Pressure Recommended Inflation Pressure Tire Placard Definition The vehicle B-Pillar is a structural member of the body located between the front and rear door (of a four-door vehicle) running from the sill to the roof.
Page 169: Tire Loading And Tire Pressure
Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire Placard Location STARTING AND OPERATING 167 Tire and Loading Information Placard Tire and Loading Information Placard This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry 3) tire size designed for your vehicle...
Page 170 168 STARTING AND OPERATING Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading Information placard and in the “Vehicle Loading”...
Page 171 available cargo and luggage load capacity is 650 lbs (295 kg) (since 5 x 150 = 750, and 1400 – 750 = 650 lbs [295 kg]). 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4.
Page 172 170 STARTING AND OPERATING...
Page 173: Tires - General Information
WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 174: Tire Inflation Pressures
172 STARTING AND OPERATING WARNING! (Continued) • Unequal tire pressures from one side of the ve- hicle to the other can cause the vehicle to drift to the right or left. • Always drive with each tire inflated to the recom- mended cold tire inflation pressure.
Page 175 CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap. This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure.”...
Page 176: Tire Pressures For High Speed Operation
174 STARTING AND OPERATING Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.
Page 177: Tread Wear Indicators
WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one. DO NOT spin your vehicle’s wheels faster than 30 mph (48 km/h) or for more than 30 seconds continuously when you are stuck, and do not let anyone near a spinning wheel, no matter what the speed.
Page 178: Life Of Tire
176 STARTING AND OPERATING Life of Tire The service life of a tire is dependent upon varying factors including, but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and the spare tire should be replaced after six years, regardless of the remaining tread.
Page 179: Tire Storage
WARNING! • DO NOT use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.
Page 180: Tire Chains
178 STARTING AND OPERATING TIRE CHAINS Due to limited clearance, tire chains are not recom- mended. CAUTION! Damage to the vehicle may result if tire chains are used. SNOW TIRES There are no snow tires that are compatible with the wheels on this vehicle.
Page 181: Tire Pressure Monitor System (Tpms)
STARTING AND OPERATING 179 Rotate the tires “side-to-side” as shown in the diagram. TIRE PRESSURE MONITOR SYSTEM (TPMS) Low Tire Indicator If tire pressure falls below 23 psi (159 kpa), the “Low Tire Pressure Telltale” in the Message Center will illuminate, a chime will sound, and the words “LOW TIRE”...
Page 182 180 STARTING AND OPERATING CAUTION! The Tire Pressure Monitor System (TPMS) has been optimized for the original equipment tires and wheels. The TPMS pressures have been established for the tire size equipped on your vehicle. Undesir- able operation or sensor damage may result when using replacement equipment that is not of the same size, type, and/or style.
Page 183: Fuel Requirements
If you experience these symptoms, try another brand of “premium” gasoline before considering service for the vehicle. Over 40 automobile manufacturers around the world have issued and endorsed consistent gasoline specifica- tions (the World Wide Fuel Charter, WWFC) which...
Page 184: Gasoline/Oxygenate Blends
182 STARTING AND OPERATING The manufacturer supports the use of reformulated gaso- lines. Properly blended reformulated gasolines will pro- vide excellent performance and durability of engine and fuel system components. Gasoline/Oxygenate Blends Some fuel suppliers blend unleaded gasoline with oxy- genates such as 10% ethanol, MTBE, and ETBE.
Page 185: Mmt In Gasoline
To fix a Non-FFV vehicle inadvertently fueled once with E-85 perform the following: • drain the fuel tank (see your authorized dealer) • change the engine oil and oil filter • disconnect and reconnect the battery to reset the engine controller memory More extensive repairs will be required for prolonged exposure to E-85 fuel.
Page 186: Fuel System Cautions
184 STARTING AND OPERATING Fuel System Cautions CAUTION! Follow these guidelines to maintain your vehicle’s performance: • The use of leaded gas is prohibited by Federal law. Using leaded gasoline can impair engine perfor- mance, or damage the emission control system. •...
Page 187: Carbon Monoxide Warnings
Carbon Monoxide Warnings WARNING! Carbon monoxide (CO) in exhaust gases is deadly. Follow the precautions below to prevent carbon monoxide poisoning: • Do not inhale exhaust gases. They contain carbon monoxide, a colorless and odorless gas, which can kill. Never run the engine in a closed area, such as a garage, and never sit in a parked vehicle with the engine running for an extended period.
Page 188 186 STARTING AND OPERATING NOTE: • When the fuel nozzle “clicks” or shuts off, the fuel tank is full. • The fuel tank filler tube has a restricting door about 2 inches (50 mm) inside the opening. If using a portable container to add fuel, it must have a flexible nozzle long enough to force open the restricting door.
Page 189: Trailer Towing
NOTE: • Tighten the gas cap until you hear a “clicking” sound. This is an indication that the gas cap is tightened properly. The “Malfunction Indicator Light” in the instrument cluster may turn on if the gas cap is not secured properly.
Page 191: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....190 If Your Engine Overheats ....190 TIREFIT Kit .
Page 192: Hazard Warning Flasher
190 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning flasher switch is on the top of the steering column, just behind the steering wheel. Hazard Warning Switch Press the switch to turn on the Hazard Warning flasher. When the switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.
Page 193: Tirefit Kit
• In city traffic — While stopped, put the transmission in NEUTRAL, but do not increase engine idle speed. • In city traffic — While moving, shift into the highest gear possible to reduce engine RPM. NOTE: There are steps that you can take to slow down an impending overheat condition: •...
Page 194: Tirefit Storage
192 WHAT TO DO IN EMERGENCIES TIREFIT Storage The TIREFIT kit is located in the trunk. TIREFIT Location TIREFIT Kit Components and Operation 1. Sealant Bottle 2. Pressure Gauge 3. Power Button 4. Mode Select Knob...
Page 195: Tirefit Usage Precautions
5. Power Plug and Cable 6. Air Pump Hose (Black) 7. Sealant Hose (Clear with Yellow Cap) 8. Accessory Storage Compartment Using the Mode Select Knob and Hoses Selecting Air Mode Turn the Mode Select knob (4) to this position for air pump operation only.
Page 196 194 WHAT TO DO IN EMERGENCIES the vehicle or tire and wheel components. Once the sealant dries, it can easily be peeled off and properly discarded. • For optimum performance, make sure the valve stem on the wheel is free of debris before connecting the TIREFIT kit.
Page 197 WARNING! (Continued) − If you are unsure of the condition of the tire or the wheel. • Keep TIREFIT away from open flame or heat source. • A loose TIREFIT kit thrown forward in a collision or hard stop could endanger the occupants of the vehicle.
Page 198: Sealing A Tire With Tirefit
196 WHAT TO DO IN EMERGENCIES Sealing a Tire with TIREFIT (A) Whenever You Stop to Use TIREFIT: 1. Pull over to a safe location and turn ON the vehicle’s Hazard Warning flashers. 2. Verify that the valve stem (on the wheel with the deflated tire) is in a position that is near to the ground.
Page 199 (C) Injecting TIREFIT Sealant into the deflated tire: • Always start the engine before turning ON the TIRE- FIT kit. NOTE: Manual transmission vehicles must have the parking brake engaged and the shifter in NEUTRAL. • After pressing the Power Button (3), the sealant (white fluid) will flow from the Sealant Bottle (1) through the Sealant Hose (7) and into the tire.
Page 200 198 WHAT TO DO IN EMERGENCIES If the sealant (white fluid) does flow through the clear Sealant Hose (7): 1. Continue to operate pump until sealant is no longer flowing through hose (typically takes 30 - 70 seconds). As the sealant flows through hose (7), the pressure gauge (2) can read as high as 70 psi (5 Bar).
Page 201 CAUTION! • The metal end fitting from Power Plug and Cable (5) may get hot after use, so should be handled carefully. • Failure to reinstall the Yellow Cap on the fitting at the end of the Clear Sealant Hose (7) can result in sealant contacting your skin, clothing, and the vehicle’s interior.
Page 202 200 WHAT TO DO IN EMERGENCIES If tire pressure is less than 19 psi (1.3 Bar) , the tire is too badly damaged. Do not attempt to drive the vehicle further. Call for assistance. If the tire pressure is 19 psi (1.3 bar) or higher: 1.
Page 203: Jump-Starting Procedures
4. Clean any remaining sealant from the TIREFIT hous- ing. 5. Position the new Sealant Bottle (1) to the housing so that the Clear Sealant Hose (7) aligns with the hose slot in the front of the housing and the alignment keys on the bottom of the bottle align with the alignment slots in the housing.
Page 204 202 WHAT TO DO IN EMERGENCIES WARNING! (Continued) • Battery fluid is a corrosive acid solution; do not allow battery fluid to contact eyes, skin, or cloth- ing. Do not lean over a battery when attaching clamps or allow the clamps to touch each other. If acid splashes in eyes or on skin, flush contami- nated area immediately with large quantities of water.
Page 205 Remote Jump-Start Connections 6. If you are jump-starting your vehicle, connect one end of a jumper cable to the positive (+) terminal on the booster battery. Connect the other end of the same cable to the remote jump-start positive post (+). WHAT TO DO IN EMERGENCIES 203 7.
Page 206 204 WHAT TO DO IN EMERGENCIES WARNING! • You should not try to start your vehicle by pushing or towing. • Do not connect the cable to the negative post of the discharge battery. The resulting electrical spark could cause the battery to explode. •...
Page 207: Freeing A Stuck Vehicle
FREEING A STUCK VEHICLE If your vehicle becomes stuck in mud, sand, or snow, it can often be moved by a rocking motion. Turn your steering wheel right and left to clear the area around the front wheels. Then shift back and forth between RE- VERSE and FIRST gear.
Page 208: Towing A Disabled Vehicle
206 WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE Do not tow with sling-type equipment. Only use flatbed equipment. Always comply with applicable state or local towing ordinances. CAUTION! Towing with equipment other than flatbed types may damage your vehicle.
Page 209: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 8.4L ... . . 209 Onboard Diagnostic System (OBD II) ..210 Emissions Inspection And Maintenance Programs ......211 Replacement Parts .
Page 210 208 MAINTAINING YOUR VEHICLE Hydraulic Clutch ....237 Rear Axle ......238 Appearance Care And Protection From Corrosion .
Page 211: Engine Compartment - 8.4L
ENGINE COMPARTMENT — 8.4L 1 — Coolant Pressure Cap 2 — Engine Oil Dipstick 3 — Power Distribution Center 4 — Remote Jump Start Positive Battery Post 5 — Brake Fluid Reservoir MAINTAINING YOUR VEHICLE 209 6 — Clutch Fluid Reservoir 7 —...
Page 212: Onboard Diagnostic System (Obd Ii)
210 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM (OBD II) To meet new government regulations and promote cleaner air, your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions and engine control systems.
Page 213: Emissions Inspection And Maintenance Programs
EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass an inspection of your vehicle’s emissions control system. Failure to pass could prevent vehicle registration. For states that require an Inspection and Mainte- nance (I/M), this check verifies the “Malfunction Indicator Light (MIL)”...
Page 214: Replacement Parts
212 MAINTAINING YOUR VEHICLE 4. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn OFF the ignition or start the engine. This means that your vehicle’s OBD II system is not ready and you should not proceed to the I/M station.
Page 215: Maintenance Procedures
your vehicle. Refer to these manuals before attempting any procedure yourself. NOTE: Intentional tampering with emissions control systems may void your warranty and could result in civil penalties being assessed against you. WARNING! You can be badly injured working on or around a motor vehicle.
Page 216: Engine Oil
214 MAINTAINING YOUR VEHICLE CAUTION! (Continued) • Your vehicle has been built with improved fluids that protect the performance and durability of your vehicle and also allow extended maintenance intervals. Do not use chemical flushes in these components as the chemicals can damage your engine, transmission, power steering or air condi- tioning.
Page 217 • Extensive engine idling • Driving in dusty conditions • Short trip driving of less than 10 miles (16.2 km) • More than 50% of your driving is at sustained high speeds during hot weather, above 90°F (32°C) NOTE: If ANY of these apply to you, then change your engine oil every 3,000 miles (5 000 km) or three months, whichever comes first, and follow “Maintenance Sched- ule B.”...
Page 218: Engine Oil Filter
216 MAINTAINING YOUR VEHICLE The engine oil filler cap also shows the recommended engine oil viscosity for your engine. For information on engine oil filler cap location, refer to “Engine Compart- ment” in “Maintaining Your Vehicle” for further information. Synthetic Engine Oils You may use synthetic engine oils provided the recom- mended oil quality requirements are met, and the recom- mended maintenance intervals for oil and filter changes...
Page 219: Engine Air Cleaner Filter
Engine Air Cleaner Filter For normal driving conditions, inspect and replace the engine air cleaner filter at the intervals shown on “Main- tenance Schedule A.” For vehicles driven frequently in dusty or under severe conditions, inspect and replace the engine air cleaner filter at the intervals shown on “Main- tenance Schedule B.”...
Page 220: Maintenance-Free Battery
218 MAINTAINING YOUR VEHICLE Maintenance-Free Battery The top of the maintenance-free battery is permanently sealed. You will never have to add water, nor is periodic maintenance required. The battery is located underneath an access panel inside the rear compartment on the left side of the vehicle. A remote battery terminal is located in the engine compart- ment for jump-starting.
Page 221 Battery Location MAINTAINING YOUR VEHICLE 219 WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Do not allow battery fluid to contact your eyes, skin, or clothing. Do not lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.
Page 222: Battery Save Feature
220 MAINTAINING YOUR VEHICLE CAUTION! • It is essential when replacing the cables on the battery that the positive cable is attached to the positive post and the negative cable is attached to the negative post. Battery posts are marked posi- tive (+) and negative (-) and are identified on the battery case.
Page 223 To Activate the Battery Save Feature 1. Insert the key into the ignition switch. 2. Cycle the ignition switch from OFF/LOCK to ACC four times. Leave the switch in the OFF/LOCK position after the fourth cycle. 3. Push the driver’s power door lock switch in the up direction.
Page 224: Air Conditioner Maintenance
222 MAINTAINING YOUR VEHICLE 2. Insert the key into the ignition switch. 3. Turn the ignition switch to the ON/RUN position. The Battery Save Feature will turn off. NOTE: If the ignition switch is NOT turned to ON/ RUN position, the Battery Save Feature will be enabled 45 seconds after the driver’s door is closed.
Page 225: Body Lubrication
WARNING! • Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- tioning system. Some unapproved refrigerants are flammable and can explode, injuring you. Other unapproved refrigerants or lubricants can cause the system to fail, requiring costly repairs. Refer to Section 3 of the Warranty Information Book, lo- cated on the DVD, for further warranty informa- tion.
Page 226: Windshield Wiper Blades
224 MAINTAINING YOUR VEHICLE concerned should be wiped clean to remove dust and grit; after lubricating excess oil and grease should be removed. Particular attention should also be given to hood latching components to insure proper function. When performing other underhood services, the hood latch, release mechanism and safety catch should be cleaned and lubricated.
Page 227: Exhaust System
reservoir at regular intervals. Fill the reservoir with windshield washer solvent (not engine coolant (anti- freeze) and operate the system for a few seconds to flush out the residual water. WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution.
Page 228 226 MAINTAINING YOUR VEHICLE CAUTION! The catalytic converter requires the use of unleaded fuel only. Leaded gasoline will destroy the effective- ness of the catalyst as an emissions control device and may seriously reduce engine performance and cause serious damage to the engine. Under normal operating conditions, the catalytic con- verter will not require maintenance.
Page 229 WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming in contact with your exhaust system. Do not park or operate your vehicle in areas where your exhaust system can contact anything that can burn.
Page 230: Cooling System
228 MAINTAINING YOUR VEHICLE Cooling System WARNING! • When working near the radiator cooling fans, disconnect each fan motor lead or turn the ignition switch to the OFF position. The fans are tempera- ture controlled and can start any time the ignition switch is in the ON position.
Page 231 Cooling System – Drain, Flush, and Refill If the engine coolant (antifreeze) is dirty or contains a considerable amount of sediment, clean and flush with a reliable cooling system cleaner. Follow with a thorough rinsing to remove all deposits and chemicals. Properly dispose of the old engine coolant (antifreeze).
Page 232 230 MAINTAINING YOUR VEHICLE CAUTION! (Continued) • This vehicle has not been designed for use with Propylene Glycol based engine coolant (anti- freeze). Use of Propylene Glycol based engine coolant (antifreeze) is not recommended. Adding Coolant Your vehicle has been built with an improved engine coolant (antifreeze) that allows extended maintenance intervals.
Page 233 Please note that it is the owner’s responsibility to main- tain the proper level of protection against freezing ac- cording to the temperatures occurring in the area where the vehicle is operated. NOTE: Mixing engine coolant (antifreeze) types will decrease the life of the engine coolant (antifreeze) and will require more frequent engine coolant (antifreeze) changes.
Page 234 232 MAINTAINING YOUR VEHICLE Disposal of Used Coolant Used ethylene glycol based engine coolant (antifreeze) is a regulated substance requiring proper disposal. Check with your local authorities to determine the disposal rules for your community. To prevent ingestion by ani- mals or children, do not store ethylene glycol based engine coolant (antifreeze) in open containers or allow it to remain in puddles on the ground.
Page 235: Brake System
If an examination of your engine compartment shows no evidence of radiator or hose leaks, the vehicle may be safely driven. The vapor will soon dissipate. • Do not overfill the coolant recovery bottle. • Check engine coolant (antifreeze) freeze point in the coolant bottle.
Page 236 234 MAINTAINING YOUR VEHICLE WARNING! Riding the brakes can lead to brake failure and possibly an accident. Driving with your foot resting or riding on the brake pedal can result in abnormally high brake temperatures, excessive lining wear, and possible brake damage. You would not have your full braking capacity in an emergency.
Page 237 WARNING! • Use only manufacturer’s recommended brake fluid. Refer to “Fluids, Lubricants, and Genuine Parts” in “Maintaining Your Vehicle” for further information. Using the wrong type of brake fluid can severely damage your brake system and/or impair its performance. The proper type of brake fluid for your vehicle is also labeled on the origi- nal factory installed hydraulic master cylinder reservoir.
Page 238: Manual Transmission
236 MAINTAINING YOUR VEHICLE WARNING! (Continued) • Do not allow petroleum based fluid to contami- nate the brake fluid. Brake seal components could be damaged, causing partial or complete brake failure. This could result in an accident. Change Brake Fluid Brake fluid will tend to absorb moisture from the atmo- sphere over time.
Page 239: Hydraulic Clutch
Hydraulic Clutch Master Cylinder – Clutch Fluid Level Check Check the fluid in the clutch master cylinder when performing underhood services. Clean the top of the master cylinder area before removing the cap. If necessary, add fluid to the reservoir. Do not overfill.
Page 240: Rear Axle
238 MAINTAINING YOUR VEHICLE Change Clutch Fluid Clutch fluid will tend to absorb moisture from the atmosphere over time. If the fluid becomes contaminated with water, clutch performance will deteriorate. There- fore, the clutch fluid must be changed at the intervals specified in “Maintenance Schedule.”...
Page 241 The following maintenance recommendations will enable you to obtain maximum benefit from the corrosion resistance built into your vehicle. Washing • Wash your vehicle regularly. Always wash your ve- hicle in the shade using MOPAR Car Wash or equiva- lent, or a mild car wash soap, and rinse the panels completely with clear water.
Page 242 240 MAINTAINING YOUR VEHICLE Convertible Top Care – Convertible Models Only Use a mild detergent to clean the top. Avoid heavy scrubbing and rinse with plenty of clean water. Allow to dry thoroughly before storage. Stain Repel Fabric Cleaning Procedure – If Equipped Stain Repel seats may be cleaned in the following man- ner:...
Page 243 Leather or Vinyl Seat/Trim Care and Cleaning Leather is best preserved by regular cleaning with a damp soft cloth. Small particles of dirt can act as an abrasive and damage the leather surface and should be removed immediately with a damp cloth. Stubborn soils can be removed easily with a soft cloth and MOPAR Total Clean or equivalent.
Page 244: Aero Group - If Equipped
242 MAINTAINING YOUR VEHICLE If the belts need cleaning, use MOPAR Total Clean or equivalent, a mild soap solution, or lukewarm water. Do not remove the belts from the vehicle to wash them. Replace the belts if they appear frayed or worn or if the buckles do not work properly.
Page 245 CAUTION! Use care when approaching parking blocks, tall speed bumps and garage curbs. These surfaces can damage your splitter. Use caution when driving up to sloped surfaces or over speed bumps. Approaching a speed bump or a slope at a slight angle may improve your clearance.
Page 246 244 MAINTAINING YOUR VEHICLE 2. Rear Wing Do not operate the vehicle with the rear wing removed. The aerodynamic balance of this set up is unstable and can cause a loss of control. Rear Wing WARNING! Use extra caution when closing the rear deck lid on the ARY convertible.
Page 247: Fuses
MAINTAINING YOUR VEHICLE 245 The rear wing is molded with unidirectional carbon fiber and painted in body color. Some patterned or linear conditions may be visible in the painted carbon fiber surfaces. This is also a normal result of the carbon fiber process.
Page 248 246 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description tridge Fuse Fuse 40 Amp — Blower Motor Green 40 Amp — Anti-Lock Brakes (ABS) Green Pump Feed/Starter 30 Amp — Body Control Module Pink (BCM) – Battery Feed 20 Amp — Amplifier Blue 30 Amp...
Page 249 Cavity Car- Mini- Description tridge Fuse Fuse 16, 17 — 20 Amp Power Outlet Yellow — 15 Amp Ignition Off Draw (IOD) Blue — 15 Amp Horn Blue — 15 Amp Air Conditioning (A/C) Blue Clutch Relay — 15 Amp Stop Light Switch Blue —...
Page 250: Mini-Power Distribution Center
248 MAINTAINING YOUR VEHICLE CAUTION! • When installing the Power Distribution Center cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the Power Distribution Center, and possibly result in an electrical system failure.
Page 251: Vehicle Storage
CAUTION! • When installing the Mini-Power Distribution Center cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the Power Distribution Center, and possibly result in an electrical system failure.
Page 252 250 MAINTAINING YOUR VEHICLE • Block the wheels. Do not apply the parking brake. • Cut blocks of plywood about the same size of the tires. Cover each block with indoor/outdoor carpeting and place them between the tires and concrete. This will prevent tire flat spotting.
Page 253: Replacement Bulbs
Check the battery every four to six weeks to ensure that the voltage is above 12.40 Volts. The voltage will drop more rapidly in hot temperatures. If battery voltage drops below 12.40 Volts, follow the battery recharge procedure in the Service Manual. NOTE: To help prevent the battery from discharging during shorter periods of inactivity, perform the follow- ing:...
Page 254 252 MAINTAINING YOUR VEHICLE LIGHT BULBS – Exterior (Convertible Models) Low/High Beam High Intensity Discharge (HID) Headlamp..Serviced at authorized dealer only Auxiliary High Beam Headlamp ..(HB3A) 9005XS Front Park/Turn Signal Lamp.
Page 255: Bulb Replacement
BULB REPLACEMENT Auxiliary High Beam Headlamp, Front Park/Turn Signal Lamp, Front Side Marker Lamp 1. Remove the push pin from the upper outer corner of the splash shield and remove the splash shield. MAINTAINING YOUR VEHICLE 253 2. Turn the appropriate bulb and socket assembly coun- terclockwise, and then pull it out of the headlamp assembly.
Page 256: High Intensity Discharge Headlamps (Hid)
254 MAINTAINING YOUR VEHICLE 3. Pull the bulb out of the socket assembly. 4. Push the replacement bulb into the socket assembly. 5. Reinstall the bulb and socket assembly into the head- lamp assembly, and then turn it clockwise. 6. Install the splash shield and push pin. High Intensity Discharge Headlamps (HID) The headlamps are a type of high voltage discharge tube.
Page 257: Front Fog Lamp
Front Fog Lamp 1. Remove the push pin from the upper outer corner of the splash shield and remove the splash shield. 2. Turn the bulb and socket assembly counterclockwise, and then pull it out of the front fog lamp assembly. MAINTAINING YOUR VEHICLE 255 3.
Page 258: Taillamp, Tail/Stop Lamp, Rear Marker Lamp
256 MAINTAINING YOUR VEHICLE Taillamp, Tail/Stop Lamp, Rear Marker Lamp 1. Open the trunk 2. Remove the two fasteners and then remove the access panel. 3. Turn the appropriate bulb and socket assembly coun- terclockwise, and then pull it out of the upper lamp assembly.
Page 259: Taillamp, Tail/Stop Lamp, Rear Marker Lamp (Coupe Models)
MAINTAINING YOUR VEHICLE 257 5. Push the replacement bulb into the socket assembly. 6. Reinstall the bulb and socket assembly into the upper lamp assembly, and then turn it clockwise. 7. Install the access panel and the two fasteners. 8. Close the trunk. Taillamp, Tail/Stop Lamp, Rear Marker Lamp (Coupe Models) For bulb replacement, see your authorized dealer.
Page 260 258 MAINTAINING YOUR VEHICLE 3. Remove the three upper lamp assembly retaining nuts. 4. Remove the three bulb and socket assemblies from the upper lamp assembly by turning them counterclockwise and then pulling them out of the upper lamp assembly.
Page 261: Backup Lamp
MAINTAINING YOUR VEHICLE 259 5. Remove the upper lamp assembly. 6. Turn the appropriate bulb and socket assembly coun- terclockwise, and then pull it out of the lower lamp assembly. 1 — Backup Lamp...
Page 262: Rear Turn Signal Lamp
260 MAINTAINING YOUR VEHICLE 2 — Rear Turn Signal Lamp 7. Pull the bulb out of the socket assembly. 8. Push the replacement bulb into the socket assembly. 9. Reinstall the bulb and socket assembly into the lower lamp assembly, and then turn it clockwise. 10.
Page 263: License Lamp
License Lamp 1. Open the trunk. 2. Turn the bulb and socket assembly counterclockwise, and then pull it out of the housing. MAINTAINING YOUR VEHICLE 261 3. Pull the bulb out of the socket assembly. 4. Push the replacement bulb into the socket assembly. 5.
Page 264: Fluid Capacities
262 MAINTAINING YOUR VEHICLE FLUID CAPACITIES Fuel (Approximate) Engine Oil with Filter 8.4 Liter Engine (SAE 5W-40, API Certified) Cooling System * 8.4 Liter Engine (MOPAR Engine Coolant/Antifreeze 5 Year/100,000 Mile Formula or equivalent) * Includes heater and coolant recovery bottle filled to MAX level. U.S.
Page 265: Fluids, Lubricants, And Genuine Parts
FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil Engine Oil Filter Spark Plugs Fuel Selection Fluid, Lubricant, or Genuine Part MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hy- brid Organic Additive Technology) or equivalent. For best performance and maximum protection under all types of operat- ing conditions, the manufacturer only recommends full synthetic engine oils that meet the requirements of Chrysler Material Standard MS-10725 and are approved to MB 229.3 or MB 229.5.
Page 266: Chassis
264 MAINTAINING YOUR VEHICLE Chassis Component Transmission Rear Axle Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product. MOPAR Synthetic Gear and Axle Lubricant SAE 75W-140 or equivalent, with Limited Slip Additive Friction Modifier.
Page 267: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..266 Maintenance Schedules ....266 Maintenance Schedule B ....269 Maintenance Schedule A .
Page 268 266 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type must be done at the times or mileages specified to ensure the continued proper functioning of the emissions control system. These and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
Page 269 NOTE: • If ANY of these apply to you then change your engine oil every 3,000 miles (5000 km) or three months, whichever comes first, and follow the maintenance recommendations in “Maintenance Schedule B” in this section. • If ANY of these apply to you, then flush and replace the engine coolant every 102,000 miles (170 000 km) or 60 months, whichever comes first, and follow the maintenance...
Page 270 268 MAINTENANCE SCHEDULES At Each Stop for Fuel • Check the engine oil level about five minutes after a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground will improve the accuracy of the oil level reading. Add oil only when the level is at or below the ADD or MIN mark.
Page 271 MAINTENANCE SCHEDULE B Follow “Maintenance Schedule B” if you usually operate your vehicle under one or more of the following condi- tions. • Day or night temperatures are below 32°F (0°C). • Stop and go driving. • Extensive engine idling. •...
Page 272 270 MAINTENANCE SCHEDULES Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect and replace the air cleaner filter, if necessary. Inspect the transmission fluid. Inspect the brake linings. Change the rear axle fluid. Change the brake fluid.
Page 273 Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect and replace the air cleaner filter, if necessary. Inspect and replace the PCV valve, if neces- sary. Change the transmission fluid. Inspect the transmission fluid.
Page 274 272 MAINTENANCE SCHEDULES Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect and replace the engine air cleaner fil- ter, if necessary. Inspect and replace the auto tension drive belt, if necessary. Change the transmission fluid.
Page 275 Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect and replace the air cleaner filter, if necessary. Inspect and replace the PCV valve, if neces- sary. Flush and replace engine coolant at 60 months, if not done at 102,000 miles.
Page 276 274 MAINTENANCE SCHEDULES Miles (Kilometers) Change the rear axle fluid. Change the brake fluid. Change the brake and clutch fluid. Lubricate the front and rear suspension ball joints. 57,000 60,000 63,000 66,000 (95 000) (100 000) (105 000) (110 000) (115 000) 69,000 72,000 (120 000)
Page 277 Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect and replace the air cleaner filter, if necessary. Inspect and replace the PCV valve, if neces- sary. Inspect and replace the auto tension drive belt, if necessary.‡...
Page 278 276 MAINTENANCE SCHEDULES Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect and replace the engine air cleaner fil- ter, if necessary. Replace the spark plugs. Replace the ignition cables. Flush and replace the engine coolant, if not replaced at 60 months.
Page 279 Miles (Kilometers) Inspect the transmission fluid. Inspect the brake linings. Change the rear axle fluid. Change the brake and clutch fluid. Change the brake fluid. Lubricate the front and rear suspension ball joints. MAINTENANCE SCHEDULES 277 93,000 96,000 99,000 102,000 (155 000) (160 000) (165 000) (170 000) (175 000) (180 000) 105,000 108,000...
Page 280 278 MAINTENANCE SCHEDULES Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect and replace the engine air cleaner filter, if necessary. Inspect and replace the PCV valve, if necessary. Flush and replace the engine coolant, if not replaced at 102,000 months.
Page 281 ‡ This maintenance is not required if previously replaced. Although not required, the manufacturer recom- mends reprogramming TPMS after rotating tires so sys- tem can relearn tire pressure sensor location. Refer to “Tire Pressure Monitor System (TPMS)” in “Starting and Operating”...
Page 282 280 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE A Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate the tires. Inspect and replace the engine air cleaner filter, if necessary. Inspect the transmission fluid. Inspect the brake linings. Change the rear axle fluid. Change the brake fluid.
Page 283 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate the tires. Inspect and replace the engine air cleaner filter, if necessary. Inspect and replace the PCV valve, if necessary. Flush and replace the engine coolant at 60 months, if not done at 102,000 miles.
Page 284 282 MAINTENANCE SCHEDULES Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate the tires. Inspect and replace the engine air cleaner filter, if nec- essary. Inspect and replace the PCV valve, if necessary. Inspect and replace the auto tension drive belt, if nec- essary.‡...
Page 285 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate the tires. Inspect and replace the engine air cleaner filter, if necessary. Inspect and replace the PCV valve, if necessary. Replace the spark plugs. Replace the ignition cables. Flush and replace the engine coolant, if not re- placed at 60 months.
Page 286 284 MAINTENANCE SCHEDULES Miles (Kilometers) [Months] Inspect the brake linings. Change the rear axle fluid. Change the brake and clutch fluid. Lubricate the front and rear suspension ball joints. ‡ This maintenance is not required if previously replaced. Although not required, the manufacturer recom- mends reprogramming TPMS after rotating tires so sys- tem can relearn tire pressure sensor location.
Page 287 WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Page 289: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle......289 Prepare For The Appointment .
Page 290 288 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....293 Department Of Transportation Uniform Tire Quality Grades ......295 Treadwear .
Page 291: Suggestions For Obtaining Service For Your Vehicle
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.
Page 292: Chrysler Group Llc Customer Center
290 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- solved with this process. • If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- ship.
Page 293: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its customer center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 294: Warranty Information (U.s. Vehicles Only)
292 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment when you purchased the vehicle. An authorized dealer has also made a major investment in facilities, tools, and training to assure that you are absolutely delighted with the ownership experience.
Page 295: In Canada
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your authorized dealer, and the manufacturer.
Page 296 294 IF YOU NEED CONSUMER ASSISTANCE vehicle, system, and/or components is written in straightforward language with illustrations, diagrams, and charts. • Diagnostic Procedure Manuals Diagnostic Procedure Manuals are filled with dia- grams, charts and detailed illustrations. These practi- cal manuals make it easy for students and technicians to find and fix problems on computer-controlled ve- hicle systems and features.
Page 297: Traction Grades
DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following tire grading categories were established by the National Highway Traffic Safety Administration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your vehicle.
Page 298: Department Of Transportation Uniform Tire Temperature Grades
296 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 299 INDEX...
Page 300 298 INDEX About Your Brakes ..... . . 157 ABS (Anti-Lock Brake System) ... . 110,158 Accessory Delay, Power .
Page 301 Jump Starting ......201 Keyless Transmitter Replacement (RKE) ..23 Location .
Page 302 300 INDEX Child Restraint Tether Anchors ....60 Circuit Breakers ......245 Clean Air Gasoline .
Page 303 Disposal Antifreeze (Engine Coolant) ....232 Door Locks ......25 Door Locks, Automatic .
Page 304 302 INDEX Engine Oil Viscosity ....215,262 Engine Oil Viscosity Chart ....215 Ethanol .
Page 305 Ethanol ......182 Filler Cap (Gas Cap) ....185 Gasoline .
Page 306 304 INDEX Heater ....... 134 High Beam Indicator ..... 109 High Beam/Low Beam Select (Dimmer) Switch .
Page 307 Lights ....... 66,88 Airbag ......50,56,66,112 Anti-Lock .
Page 308 306 INDEX Loading Vehicle Tires ....... 167 Locks ....... . . 25 Door .
Page 309 Trip ....... . 108 Oil, Engine ..... . . 214,262,263 Capacity .
Page 310 308 INDEX Windows ......28 Windows, Express Down ....22 Pregnant Women and Seat Belts .
Page 311 Safety Defects, Reporting ....292 Safety, Exhaust Gas ..... 31,65 Safety Information, Tire .
Page 312 310 INDEX Snow Tires ......178 Speedometer ......108 Starting .
Page 313 Replacement ......176 Rotation ......178 Safety .
Page 314 312 INDEX Vehicle Theft Alarm (Security Alarm) ..13 Vinyl Trim ......241 Viscosity, Engine Oil .
Page 315 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehicle’s electronic system to provide immunity to radio frequency signals. Mobile two-way radios and telephone equipment must be installed properly by trained person- nel. The following must be observed during installation. The positive power connection should be made directly to the battery and fused as close to the battery as possible.
Page 316 Chrysler Group LLC 10ZB27-126-AA First Edition Printed in U.S.A.

This manual is also suitable for:

2010 viper srt10

Dodge 2010 Viper Owner's Manual

Introduction 1

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Maintaining Your Vehicle

Table of Contents

If You Need Consumer Assistance

Quick Links

Chapters

Related Manuals for Dodge 2010 Viper

Summary of Contents for Dodge 2010 Viper
